BIXOLON SRP-QE302 Manual de instrucciones

Network Connection Manual

SRP-QE300/302

THERMAL RECEIPT PRINTER

Rev. 1.00

http://www.bixolon.com

Rev. 1.00

- 2 -

SRP-QE300/302

■

Table of Contents

1. Manual Information........................................................................................................3

2. Specifications ................................................................................................................3

3. How to Connect..............................................................................................................4

4. Ethernet Test by using Windows Test Page................................................................6

5. Factory Reset...............................................................................................................13

6. Troubleshooting...........................................................................................................15

Rev. 1.00

- 3 -

SRP-QE300/302

1. Manual Information

This Network manual provides information on the connection of network with the printer.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and

quality of all our products. In following, product specifications and/or user manual content

may be changed without prior notice.

2. Specifications

CATEGORIES

FEATURE

IMPLEMENTATION

LAN

Specification Interface 10/100 Base-T All in one(Auto detection)

Protocol

DHCP Client, HTTP, ARP, ICMP, IPv4 ,TCP, UDP

Rev. 1.00

- 4 -

SRP-QE300/302

3. How to Connect

1) Checking Network Setting

After the printer has finished booting, open the printer cover and press and hold the FEED

button for 5 seconds. This will cause the internal buzzer to buzz 5 times and enter the

interface setting confirmation mode. Then add the paper, close the cover, and check that

the following message is printed.

If the above message is printed, select Mode 1, and you will see the following LAN data.

(To select Mode 1, press the Feed button once quickly/ once long.)

Checking Interface Setting

0: Exit

1: LAN Information Print

2: LAN Factory Reset and Reboot Printer

3 or more: None

Select Modes by Feed button control

as below.

Step 1. Short-press as many times as

The mode number to choose.

Step 2. Long-press over 1 second.

*e.g. To choose Mode 2, press Feed

Button 3 times(short-short-long)

COVER OPEN LEVER

FEED BUTTON

Rev. 1.00

- 5 -

SRP-QE300/302

2) LAN Setting Values

Classification

Item

Remarks

Input Range

Network

Inactivity Time TCP connection hold time 0~3600 integer

IP Assignment

Method

IP Assignment Method DHCP/Manual

IP Address Printer IP IP Address

Subnet Mask Subnet mask IP Address

Gateway Default Gateway IP Address

For changing network setting values using Net configuration tool, Refer to ‘Net

configuration tool manual’.

Rev. 1.00

- 6 -

SRP-QE300/302

4. Ethernet Test by using Windows Test Page

You can use the Windows printer driver as shown below when there is no test program.

Operating systems that allow you to use the Windows printer driver are Windows, XP,

Server 2003, VISTA, 2008 Server, 7, 8, 10.

[Note]

-The Windows driver is included in the CD, and you can download the latest version

from our home page.

(www.bixolon.com)

1) Double-click the Windows Driver installation file.

2) Click Install

Rev. 1.00

- 7 -

SRP-QE300/302

3) Select Installation and click Next.

4) Select Model Name and click Next

Rev. 1.00

- 8 -

SRP-QE300/302

5) Select Ethernet and click Add TCP/IP Port

6) Enter the IP address and port number, and then click Next.

Rev. 1.00

- 9 -

SRP-QE300/302

7) Click Next

8) Click Next

Rev. 1.00

- 10 -

SRP-QE300/302

9) Click Next

10) Click Finish
