IMPORTANT NOTICE
This Manual contains important
safety instructions which must
be strictly followed when using
this equipment.
MODEL MINI-22
Automatic Feed Mixer Grinder
Operating Manual and Parts List
TABLE OF CONTENTS:
NOTICE TO OWNERS AND OPERATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE
SAFETY TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MOTOR WIRING AND ELECTRICAL REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . .
PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PARTS IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOVAL/INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATOR’S SIGNATURE PAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPTIONAL PNEUMATIC FOOT SWITCH IDENTIFICATION . . . . . . . . . . . . . . . . . .
1
2
3
4
5
15
16
19 - 21
24
4 & 5
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 - 11
12
15
14
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
THREE PHASE CONTROL PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
NOTICE TO OWNERS AND OPERATORS
BIRO’Sproductsaredesignedtoprocessfoodproductssafelyandefciently.Unlesstheoperatoris
properly trained and supervised, however, there is the possibility of a serious injury. It is the responsibility of
the owner to assure that this machine is used properly and safely, strictly following the instructions contained in
this Manual and any requirements of local law.
No one should use or service this machine without proper training and supervision. All operators should
be thoroughly familiar with the procedures contained in this Manual. Even so, BIRO cannot anticipate every
circumstance or environment in which its products will be used. You, the owner and operator, must remain alert
to the hazards posed by the function of this equipment, particularly the ROTATING GRINDING AUGER and
theROTATINGMIXINGPADDLE,whichcanseverelyinjureaninattentiveoperatoramputatingngersand
limbs. No one under eighteen (18) years of age should operate this equipment. If you are uncertain about a par-
ticular task, ask your supervisor.
This Manual contains a number of safe practices in the SAFETY TIPS section. Additional warnings are
placed throughout the Manual. Warnings related to your personal safety are indicated by:
OR
Warnings related to possible damage to the equipment are indicated by:
BIRO also has provided warning labels on the equipment. If any warning label, instruction label or
Manual becomes misplaced, damaged, or illegible, please contact your nearest Distributor or BIRO directly for
a replacement.
Remember, however, this Manual or the warning labels do not replace the need to be alert and to use
your common sense when using this equipment.
-NOTE-
“A copy of this manual is included with each MODEL MINI-22 MIXER GRINDER.
The descriptions and illustrations contained in this manual are not binding.
The manufacturer reserves the right to introduce any modication without updating
the manual.”
1
SAFETY TIPS
ROTATING GRINDING AUGER &
ROTATING MIXING PADDLE
TO AVOID SERIOUS PERSONAL INJURY
NEVER Touch This Machine without Training and Authorization by Your Supervisor.
NEVER Place Hands into Machine Input or Output Openings.
NEVER Open Machine During Operation.
ONLY Use a Qualied Electrician to Install According to Local Building Codes: Machine MUST
Be Properly Grounded.
ALWAYS Connect to Proper Voltage & Phase.
ONLY Install on a Level, Non-Skid Surface in a Clean, Well-Lighted Work Area Away from Children
and Visitors.
ALWAYS Lock Machine Casters After Moving This Machine.
NEVER Use This Machine For Non-Food Products.
NEVER Operate Machine With Product Mixer Safety Cover Opened, Removed, or Interlock Switch By-passed.
ALWAYS Turn Off, Unplug Machine From Power Source and Perform Lockout/Tagout Procedure to this
Machine BEFORE Attempting to Unjam or Unclog, Cleaning or Servicing.
NEVER Leave Machine Unattended While Operating.
NEVER Alter This Machine From its Original Form as Shipped From Factory. DO NOT Operate
Machine With Missing Parts.
PROMPTLY REPLACE Any Worn or Illegible Warning Labels.
ALWAYS Read Operation and Service Manual BEFORE Operating, Cleaning, or Servicing.
USE ONLY BIRO Parts and Accessories Properly Installed.
2
INSTALLATION
TO AVOID SERIOUS PERSONAL INJURY, PROPERLY INSTALL
EQUIPMENT IN ADEQUATE WORK AREA
ALWAYS Use Qualied Technician and Electrician for Installation.
ONLY Operate on a Solid, Level, Non-Skid Surface.
NEVER Operate Machine With Product Mixer Safety Cover Opened or Removed or Safety Switch By-Passed.
ALWAYS Connect to Proper Voltage & Phase.
ALWAYS Install Equipment in Work Area with Adequate Light and Space Away from Children and Visitors.
ALWAYS Lock Machine Casters After Moving Machine.
NEVER Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
NEVER Operate Without all Warning Labels Attached and Owner/Operator Manual Available to the
Operator.
UNCRATING AND SET UP
1. Read this Manual thoroughly before installation and operation. Do not proceed with installation and
operation if you have any questions or do not understand anything in this Manual. Contact your local
Distributor, or BIRO rst.
2. Remove all banding, shipping carton, and all equipment from inside the tub. Then take machine off
shipping pallet.
3. Install machine on a level, non-skid surface in a well-lighted work area away from children and
visitors.
4. This machine is complete except for knife and plate. There is a bowl shipping plug (cardboard) placed
in the output end of the grinding bowl to retain the grinding auger during shipment. REMOVE THE
BOWL SHIPPING PLUG AND THE GRINDING AUGER.
5. After checking and making sure the power supply is correct, plug in your machine.
NEVER OPERATE MACHINE WITH PRODUCT SAFETY COVER OPEN.
(Machine will not run with cover open or hopper removed.)
6.Machinemustbeproperlygrounded.Usequaliedelectriciantoinstallaccordingtolocalbuilding
codes.
3
MOTOR WIRING AND ELECTRICAL REQUIREMENTS
2. Connect leads to machine in a manner that will be approved by local electrical inspectors.
3. Rated voltage of the unit shall be identical with full supply voltage.
4. Voltage drop on the supply line shall not exceed 10% of full supply voltage.
5. The feederline conductor size in the raceway from the branch circuit to the unit must be correct to assure
adequate voltage under heavy starting and short overload conditions.
6. The feederline conductor shall only be used for the supply of one unit of the relevant horsepower. For
connections of more than one unit on the same feederline, a local electrician will have to be consulted to
determine the proper conductor size.
7. The size of the electrical wiring required from the power source to the Single phase mixer-grinder/chopper
is a MINIMUM OF No. 10 GAUGE WIRE.
8. The BIRO Manufacturing Company is not responsible for permanent wiring, connection or installation.
PRE-OPERATION AND AUGER ROTATION CHECK
ROTATION MUST ONLY BE CHECKED WITH THE
GRINDING AUGER REMOVED, otherwise serious irreparable
damage may occur to grinding components.
1. Turn the hand/foot selector switch to the hand position. Push the green start button. CHECK THE
ROTATION OF THE AUGER DRIVE SHAFT; ROTATION MUST BE COUNTER-CLOCKWISE as
indicatedbytherotationdecalafxedtothegrindingbowl.
2. If machine runs clockwise (backwards), it must be rewired to correct rotation, otherwise serious irreparable
damage may occur to the grinding components.
3. When supplied, check operation of optional pneumatic footswitch. Plug footswitch cord into female
coupling located on the same side as the operation controls. Move selector switch to foot. The machine will
operate with pressure on the footswitch bellow. Releasing the bellow stops the machine. The footswitch
operates the mix and grind together.
4. Insert auger assembly into grinding bowl, place knife (sharp edges out) onto the square end of the auger
assembly. The breaker plate slides over the worm knife drive pin, and is held from rotating by pins in the
grinder bowl. Install the retaining ring.
4
Three phasegrindersarewired208/220voltsunlessotherwisespecied.Besuremotorspecications
(voltage,cycle,phase)matchpowersupplyline.Besurevoltageisuptospecication.
The size of the electrical wiring required from the power source to the Three phase mixer-grinder/chopper
is a MINIMUM OF No. 12 GAUGE WIRE.
1. Single phasegrindersarewired208/220voltsunlessotherwisespecied.Besuremotorvariable
frequency drive parameters are adjusted for correct line voltage. Be sure to read line voltage for correct
parameter adjustment. See variable frequency drive manuals for parameter settings.
5. Check placement of all warning labels and be sure anyone who is to operate this MINI-22 MIXER
GRINDER has read and fully understands the operators manual. Machine is now ready for trained operators
to process product.
6.Usemeatdeectorattachedtogrindingbowltoeliminatemeatsplatter.
7. Contact your local distributor if you have any questions or problems with the installation or operation of this
machine.
5
OPERATOR’S NOTES
ONLY HAND TIGHTEN RETAINING RING
For best results, use knife and plate as a set. Do not operate machine for any
period of time without product in the grinding bowl. This will cause
heating and dulling of the knife and plate.
PARTS LOCATION
64040
Hopper Cover
64009
Hopper Assembly
53852
Paddle Lock
Arm Assembly
64001
Grinder Bowl
64048
Spurt Guard
A64041
Cart Assembly
PC175-1
Caster
64037
Hood Assembly
56300J-CPB
Female
coupling
metal type
Single phase
241-3-10
POWER
CORD
10-3
CR22S
Bowl Ring
Controls
see page 7
6
HNM46S
Hex Nut
2- Required
Three phase
241-4
POWER
CORD
12-4
64044
Bowl Mounting Stud
2- Required
64038
Rear Cover Panel
(NOT SHOWN)
64026
Lid Limit Switch
Located Inside Hood Assembly
Upper Left Side
7
Mini-22
Controls
42MC-Y73
Mix Start Button
42MC-Y74
Stop Button
42MC-Y73
Grind Start Button
64029 (Single Ph)
Hand/Foot
Selector Switch
EMG90668 (Three Ph)
Hand/Foot
Selector Switch
Hand/Foot
Selector Switch
Phase Specic
