Biostar P4M900 Micro 775 Manual de usuario

P4M900

All rights are reserved. No part of this publication may be reproduced, transmitted, transcribed,

stored in a retrieval system or translated into any language or computer language, in any form

or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise,

without the prior written permission of the company. Brands and product names are

trademarks or registered trademarks of their respective companies.

The vendor makes no representations or warranties with respect to the contents herein and

especially disclaim any implied warranties of merchantability or fitness for any purpose.

Further the vendor reserves the right to revise this publication and to make changes to the

contents herein without obligation to notify any party beforehand. Duplication of this

publication, in part or in whole, is not allowed without first obtaining the vendor’s approval in

writing.

Trademark

All the trademarks or brands in this document are registered by their respective owner.

Disclaimer

We make no warranty of any kind with regard to the content of this user’s manual. The content

is subject to change without notice and we will not be responsible for any mistakes found in

this user’s manual. All the brand and product names are trademarks of their respective

companies.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits of a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense. However, there is no guarantee

that interference will not occur in a particular installation.

CE Mark

The device is in accordance with 89/336 ECC-ENC Directive.

er: EG100

P4M900

VIA®P4M900 & VT8237R Plus

Support Socket 775

Intel®CoreTM 2 Duo/ Pentium®D/

Pentium®4/Celeron®D/ Celeron®Processor

User Manual

Enabling the Hyper-Threading Technology, your computer system is

required to have components as the following:

CPU: An Intel® Pentium®4 Processor with HT Technology

Chipset: An Intel®Chipset that supports HT Technology

BIOS: A BIOS that supports HT Technology must be enabled

OS: An operating system that supports HT Technology

For more information on Hyper-Threading Technology, go to:

http://www.intel.com/info/hyperthreading

Dimensions (Micro ATX form-factor):

210 mm x 244 mm ( W x L )

Operating System:

Windows®Vista (32 bit)/ XP/ 2000

Attention- Im

ortant Information

Follow the procedures below…

Troubleshooting Tips

Refer to other sections in this manual…

Things You Have To Know

0The images and pictures in this manual are for reference only and may vary from the

product you received depending on specific hardware models, third party components

and software versions.

0This mainboard contains very delicate IC chips. Always use a grounded wrist strap

when working with the system.

0Do not touch any IC chip, lead, connector or other components.

0Always unplug the AC power when you install or remove any device on the mainboard

or when confuguring pins and switches.

Packing List

P4M900 Mainboard

IDE Cable

SATA Cable

I/O Bracket

Mainboard Setup Driver & User Manual CD

Mainboard Quick Installation Guide

Symbols

Table of Contents

CHAPTER 1. GETTING STARTED ..................................................................1

INTRODUCTION....................................................................................................... 1

SPECIFICATION ....................................................................................................... 2

CONFIGURATION .................................................................................................... 5

Layout of P4M900........................................................................................... 5

HARDWARE INSTALLATION ................................................................................... 6

CPU Processor Installation.............................................................................. 6

Memory Installation: DIMM1/ DIMM2.......................................................... 7

Back Panel Configuration................................................................................ 9

Front Panel Headers: JW_FP, PWRLED, SPEAK ........................................ 11

Connectors ..................................................................................................... 12

Headers & Jumpers........................................................................................ 13

Audio Configuration...................................................................................... 14

Slots ............................................................................................................... 15

Power Supply Attachments............................................................................ 16

CHAPTER 2. BIOS SETUP............................................................................ 17

INTRODUCTION..................................................................................................... 17

MAIN MENU ......................................................................................................... 18

CHAPTER 3: SOFTWARE SETUP ............................................................... 20

SOFTWARE LIST ................................................................................................... 20

SOFTWARE INSTALLATION ................................................................................... 20

CHAPTER 4: TROUBLESHOOTING ............................................................ 24

APPENDIX I: SUPER 5.1 CHANNEL SETUP ............................................................ 27

APPENDIX II: RAID 0/ 1SETUP ............................................................................ 29

Mainboard P4M900

Chapter 1. Getting Started

Introduction

Thanks for choosing P4M900 Mainboard. It is based on VIA®P4M900 Northbridge chipset

and VIA®VT8237R Plus Southbridge chipset. In addition, the mainboard comprises integrated

the VIA® Chrome9TM HC IGP graphics optimized. It supports Intel®CoreTM 2 Duo/ Pentium®D/

Pentium®4/ Celeron®D/ Celeron®Processors with FSB (Front Side Bus) frequencies of 1066

MHz/ 800 MHz/ 533 MHz.

The P4M900 provides two DIMM (Dual In-Line Memory Modules) sockets which allowing you

to install 240-pin, unbuffered non-ECC, DDRII 667/ DDRII 533/ DDRII 400 SDRAMs. It also

allows you installing a total memory capacity of 4 GB.

This mainboard provides one PCI-E x16 slot for use with a graphics card. There is also one

PCI-E x1 slot provided for use with a PCI-E x1 compatible expansion card. Two standard PCI

slots for use with standard PCI expansion cards are also allowed.

The P4M900 provides one floppy disk drive connector that can be used with 360KB/ 720KB/

1.2MB/ 1.44MB/ 2.88MB drive. It also has two IDE connectors for hard drives supporting Ultra

ATA 133/ 100/ 66/ 33 IDE devices. In addition, the onboard Serial ATA comes with two SATA

connectors, which the interface can provide up to 1.5 Gb/s transmit speed and also support

RAID 0/ 1 mode <See Appendix II>.

The onboard AC’ 97 Audio CODEC (VT1616) supports high quality performance 6-channel

audio play (Super 5.1 Channel Audio Effect) <See Appendix I>.

The P4M900 also comes with an onboard 10/100 Mbps Ethernet LAN chip. There is a LAN

port on the back panel of your case that you can directly plug into an Internet cable.

There are maximal eight USB2.0/ 1.1 ports which can be set up on this mainboard.

All the information (including hardware installation and software installation) in this manual are

for reference only. The contents in this manual may be updated without notice. The company

will not assume any responsibility for any errors or mistakes within.

Mainboard P4M900

Specification

CPU:

Support Socket 775

Support Intel®CoreTM 2 Duo/ Pentium®D/ Pentium®4/ Celeron®D/ Celeron®

Processors

Support Hyper-Threading Technology

Support 1066 MHz/ 800 MHz/ 533 MHz FSB (Front Side Bus) Frequencies

Chipset:

Northbridge Chipset – VIA®P4M900

Southbridge Chipset – VIA®VT8237R Plus

I/O Controller – Fintek®F71805FG

AC’97 Audio Codec – VIA®VT1616

LAN Controller – VIA®VT6103L

Memory:

Two DIMM sockets

Supports unbuffered & non-ECC DDRII 667/ 533/ 400 SDRAM

Supports a total memory capacity of up to 4 GB

Onboard AC’97 Audio Codec (VT1616):

High performance Codec with high S/N ratio (>90 db)

Compliant with AC’ 97 2.3 specification

Supports 6-channel playback capability (Super 5.1 Channel Audio Effect)

Supports 3D stereo enhancement

Slots:

Two PCI-Express interface slots for graphics cards and expansion cards:

1. One PCI-E x16 slot: supports up to x16 mode with 4 GB/s one-way bandwidth

2. One PCI-E x1 slot: supports up to x1 mode with 250 MB/s one-way bandwidth

Two PCI slots with 133 MB/s one-way bandwidth per channel for expansion cards

FDD Connector:

Supports one FDD connector to set up to two floppy disk drives

Mainboard P4M900

Supports 360KB/ 720KB/ 1.2MB/ 1.44MB/ 2.88MB

IDE Connector:

Two IDE connectors

Supports up to four IDE devices

Supports Ultra ATA 33/66/100/133

Supports high capacity hard disk drives

Serial ATA Connector:

Two SATA connectors

Supports SATA 1.0 specification with transmit speed up to 1.5 Gbps

Supports SATA RAID 0/ 1

One SATA connector can only support one SATA HDD

Onboard LAN Chip:

10/100 Mbps Ethernet LAN supported

I/O facility Connectors

Supports one PS/2 mouse port and one PS/2 keyboard port

One multi-mode Parallel Port is capable to support as the following:

1. Standard & Bi-direction Parallel Port

2. Enhanced Parallel Port (EPP)

3. Extended Capabilities Port (ECP)

Supports one serial port (COM1)

Supports one VGA port (=D-Sub)

Universal Serial Bus:

Four onboard USB 2.0/ 1.1 ports

Two front USB headers come with this mainboard for additional four USB ports

Support a maximum of eight USB ports to connect USB compliant devices

BIOS:

Phoenix-Award™ BIOS

Support APM1.2

Support ACPI 2.0 power management

Mainboard P4M900

Green Function:

Supports Phoenix-Award™ BIOS power management function

Supports system-wake-from-power-saving-mode by keyboard or mouse touching

Shadow RAM:

Integrated memory controller provides shadow RAM functionality and supports ROM

BIOS

Flash Memory:

Supports flash memory functionality

Supports ESCD functionality

Hardware Monitor Function:

Monitors CPU & System Fan Speed

Monitors CPU Temperature

Monitors CPU & Memory Voltage

Mainboard P4M900

Configuration

Layout of P4M900

Mainboard P4M900

Hardware Installation

This section will assist you in quickly installing your system hardware. Wear a wrist ground

strap before handling components. Electrostatic discharge may damage the system’s

components.

CPU Processor Installation

This mainboard supports Intel®CoreTM 2 Duo/ Pentium®D/ Pentium®4/ Celeron®D/ Celeron®

Processors using a Socket 775. Before building your system, we suggest you to visit the Intel

website and review the processor installation procedures. http://www.intel.com

CPU Socket 775 Configuration Steps:

1. Locate the CPU socket 775 on your

mainboard and nudge the lever

away from the socket as shown.

Then lift the lever to a 140-degree

angle (A). Next, lift up the iron cover

(B).

2. There are 2 distinctive marks

located near the corners of the

socket on the same side as the lever

as shown (C). Match these marks

with the marks on the CPU and

carefully lower the CPU down onto

the socket (D).

3. Replace the iron cover and then

lower the lever until it snaps back

into position (E). This will lock down

the CPU (F).

4. Smear thermal grease on the top of the CPU. Lower the

CPU fan onto the CPU/CPU socket and secure it using

the attachments or screws provided on the fan. Finally,

attach the fan power cord to the CPUFAN header.

Attention

DO NOT touch the CPU pins in case they are damaged. Also, make sure

that you have completed all installation steps before powered on the

system. Finally, double-check that the cooling fan is properly installed and

the CPU fan power cord is securely attached, in case your CPU and other

sensitive components are damaged because of high temperatures.

Otros manuales para P4M900 Micro 775

Tabla de contenidos

Otros manuales de Placa madre de Biostar

Biostar

Biostar GF7050V-M7 Guía del usuario

Biostar

Biostar TB360-BTC D+ Manual de usuario

Biostar

Biostar H77MU3 Manual de usuario

Biostar

Biostar TA970 Guía del usuario

Biostar

Biostar T41-A7 - BIOS Guía del usuario

Biostar

Biostar P4TSE Pro Manual de usuario

Biostar

Biostar M7 VIF Manual de usuario

Biostar

Biostar P4M80-M7 Guía del usuario

Biostar

Biostar M7VKF Manual de usuario

Biostar

Biostar M7VIZ Guía del usuario

Biostar

Biostar A770L3 - BIOS Manual de usuario

Biostar

Biostar G31-M7 Guía del usuario

Biostar

Biostar M7VIG Pro D Guía del usuario

Biostar

Biostar B560MH-E 2.0 Manual de usuario

Biostar

Biostar TA760G M2+ Guía del usuario

Biostar

Biostar A780L3L Guía del usuario

Biostar

Biostar TA870U3+ Guía del usuario

Biostar

Biostar K8T89-A7 Manual de usuario

Biostar

Biostar TA970XE Guía del usuario

Biostar

Biostar GAMING Z170W Manual de usuario

Biostar

Biostar TA785-A3 - BIOS Manual de usuario

Biostar

Biostar Hi-Fi A85W Guía del usuario

Biostar

Biostar A55MLC2 Guía del usuario

Biostar

Biostar A780L3C Guía del usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
