BinTec BIANCA Manual de usuario

BIANCA/BRICK-X21

Getting Started

Version 1.0 March1999

Document #71020I

Notes:

This manual provides a description of an initial, first-time configura-

tion of the BIANCA/BRICK-X21 router with software version 4.9.3.

While every effort has been made to ensure the accuracy of all

information in this document, BinTec Communications AG assumes

no liability to any party for any loss or damage caused by errors or

omissions or by statements of any kind in this document.

The information in this manual is subject to change without no-

tice. For additions or changes to this document please refer to the

most recent version of this document which is available at BinTec’s

World Wide Web server at: http://www.bintec.de

BinTec and the BinTec logo are registered trademarks of BinTec

Communications AG. All other product names and trademarks are

the property of their respective companies.

any form or by any means – graphic, electronic, or mechanical – including photo-

copying, recording in any medium, taping, or storage in an information retrieval sys-

tems, without the prior written permission of the copyright owner.

BinTec Communications AG March1999

Getting Started

How to contact BinTec Communications

Ways to contact BinTec Telephone number or address

Telephone +49 911 96 73 0

FAX +49 911 688 07 25

Mail BinTec Communications AG

Südwestpark 94

D-90449 Nürnberg

GERMANY

WWW http://WWW.BinTec.DE

BIANCA/BRICK-X21

GETTING STARTED

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Software Installation . . . . . . . . . . . . . . . . . . . . . . . . .3

Installing the BRICK . . . . . . . . . . . . . . . . . . . . . . . . . .4

LED Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Gathering the Information . . . . . . . . . . . . . . . . . .8

Accessing the BRICK. . . . . . . . . . . . . . . . . . . . . . .9

Over Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . .10

Over LAN Interface . . . . . . . . . . . . . . . . . . . . . . .10

Over ISDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Additional Conﬁguration Possibilities. . . . . . . . .11

Conﬁguration with Setup Tool . . . . . . . . . . . . . . 13

Licenses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Setting up the LAN Interface . . . . . . . . . . . . . . .15

Setting up the ISDN Interface. . . . . . . . . . . . . . . 16

BIANCA/BRICK-X21 GETTING STARTED

Dialup Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Incoming Call Answering . . . . . . . . . . . . . . . . . . . 17

WAN Partner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

WAN Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

PPP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

IP Partner Conﬁguration . . . . . . . . . . . . . . . . . . . . 20

IP Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Leased Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

WAN Partner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

IP Partner Conﬁguration . . . . . . . . . . . . . . . . . . . . 24

IP Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Saving your Conﬁguration. . . . . . . . . . . . . . . . . .25

Testing your Conﬁguration . . . . . . . . . . . . . . . . . . .26

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .26

Getting the latest BRICK News and Software. .27

Setting up a BinTec Router in the UK. . . . . . . . . .29

Differences in the UK . . . . . . . . . . . . . . . . . . . . . .29

Multiple Subscriber Numbering (MSN) . . . . . . . . 29

Calling Line Identiﬁcation (CLIP) . . . . . . . . . . . . . 30

International ISDN Calls . . . . . . . . . . . . . . . . . . . . 30

Conﬁguring your BRICK . . . . . . . . . . . . . . . . . . . .30

Setup Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

SNMP Client Shell . . . . . . . . . . . . . . . . . . . . . . . . . 33

1BIANCA/BRICK-X21

Getting Started

Welcome!

Thismanualhasbeendesignedtohelpyouquicklyinstall

and conﬁgure your new router using Setup Tool.

First, we’ll provide a short list of the availablefeatures

on the BRICK, then we’ll cover installing the additional

software included with your BRICK.

Physically Installing the BRICK begins on page 4.

Conﬁguring the BRICK is divided into 3 steps and is

described beginning on page 7.

Finally, we’ll describe a few simple tests that you can

usetoverifythatyourconﬁgurationwassuccessful(p.26).

BIANCA/BRICK-X21 GETTING STARTED

Features

The BIANCA/BRICK-X21 is BinTec’s cost effective

and ﬂexible BRI/X.21 multiprotocol router, particularly

attractive for midrange communication environments.

The BIANCA/BRICK-X21 satisﬁes all the require-

ments of today’s LAN - WAN connections by combining

the functions of a Gateway, Router, Bridge, and Telematic

Server in a single, compact product.

The BRICK’s most important features include:

• SupportforTCP/IProuting,IPXrouting,andbridg-

ing.

• Remote CAPI services for many communications

applicationsunderWindows3.x,Windows95,Win-

dows 98 and Windows NT.

• Configuration via serial connection (V.24), telnet

(TCP/IP), isdnlogin (ISDN), separate SNMP man-

agers, or special Windows software (DIME

Browser).

• Integrated Firewall, using NAT (Network Address

Translation) and Access Lists.

• Accounting of ISDN and TCP/IP connections.

• FastEthernetinterfacewithauto-sensing10Base-T/

100BaseT (RJ45) port .

• Double-BRI ISDN interface with automatic detec-

tion/configuration of protocol settings.

• X.21 interface for directly accessing public X.25 net-

works.

• Windows and UNIX software for configuring and

administering the BRICK.

• HTTP and Java Status Monitors.

SOFTWARE INSTALLATION

Software Installation

Your BRICK includes several helper/utility programs for

Windows and UNIX.

BRICKware

for Windows BRICKware for Windows consists of the following

programs(for detailed information, pleasereferto the on-

line BRICKware for Windows documentation):

•DIME Tools – A set of tools for administering your

BRICK which includes: BootP Server,TFTP Manager,

Syslog Server,Time Server, and ISDN and CAPI Trace

Utility.

•DIMEBrowser–AnSNMPmanagerwithagraphical

user interface for administering your BRICK.

•BRICK at COM1/2 – Preconfigured Windows termi-

nal sessions for accessing your BRICK over your

computer’s serial ports.

•Remote CAPI clients for CAPI 1.1 and 2.0.

If you intend on conﬁguring your BRICK from a PC or

using it as a CAPI server for PC applications you should

install the software as explained in the online document

BRICKware for Windows.

RVS-COM RVS-COM for Windows 95 and Windows NT (Lite

Version) is an application that runs using the CAPI inter-

faceandprovidestelecommunicationsservices,suchasT-

Online (formerly Btx or Datex-J), Fax, Voice Mail, and Eu-

roﬁletransfer. Complete instructions can be found in the

online documentation included on the CD.

BRICKtools

for UNIX BRICKtools for UNIX includes a Euroﬁletransfer

server and client as well as ISDN and CAPI trace tools for

various UNIX platforms (refer to the Software Reference).

BIANCA/BRICK-X21 GETTING STARTED

Installing the BRICK

Select a ﬂat, stable location for your BRICK and connect

the included cables to the ports located on the back plane

as shown in the diagram below.

All the examples in this documentation are for the

BRICK-X21with aFastEthernetadapter(CM-100BT),one

ISDN adapter (CM-2BRI) and an X.21 adapter (CM-X21).

Note that the BRICK-X21 does not have a power switch.

The system will power up as soon as it is connected to

your power source. You may decide to wait until you’re

ready to access the BRICK before connecting the power

source.

Step 2

Connect your BRICK to your

ethernet’s cabling using the

UTP port.

Step 1

Connect the included laplink

cable to your terminal or

computer and the 9 pin serial

port.

Step 3

Connect the included ISDN

cable (RJ-45) to your BRICK’s

ISDNport(s) and yourISDNout-

let.

Step 5

Connect the power cord to

the BRICK-X21 and your local

power supply.

Step 4

Connect the included X.21

cable to your BRICK’s X.21

port and your X.21 outlet.
