BiPAC 9800(N)

(802.11n) Fiber Optical Router

Quick tart Guide

Billion BiPAC 9800(N) (802.11n) Fiber Optical Router

-1-

Package Contents

BiPAC 9800(N) (802.11n) Fiber Optical Router

CD containing the on-line manual

Ethernet (RJ-45) cable

Three 2dBi detachable antennas (BiPAC 9800N only)

Power adapter

This Quick tart Guide

Warning

PLEA E READ THE QUICK TART GUIDE AND FOLLOW THE

TEP CAREFULLY. THI QUICK TART GUIDE WILL HELP YOU

IN TALL THE DEVICE PROPERLY AND AVOID IMPROPER U AGE.

IF YOU NEED MORE INFORMATION ON THI OFTWARE

CONFIGURATION, PLEA E REFER TO THE U ER MANUAL ON

CD-ROM.



Do not use the

router

in high humidity or high temperatures.

 Do not use the same power source for the router as other

equipment.

 Do not open or repair the case yourself. If the router is too hot,

turn off the power immediately and have it repaired at a qualified

service center.



Avoid using this

product

and all

accessories

outdoors.



Place the router on a stable surface.

 Only use the power adapter that comes with the package. Using a

different voltage rating power adaptor may damage the router.

Attention

Quick tart Guide

-2-

Hardware Overview

The Front LEDs

The Rear Ports

ingle C Port

Connect the

supplied power

adapter to this jack.

Press more than 1

second to restore

the device to its

default mode.

Connect your computer

to a LAN port using the

included Ethernet cable

(with RJ-45 cable).

When

the

power

on it will

lit green. When the system is

booting it will blink orange.

When the system is ready it

will be lit green. When system

boot fails or if in emergency

mode, it will be lit orange.

Lit orange when one of LAN

ports is connected to an

Ethernet device. Lit green when

the speed of transmission hits

1000Mbps; Lit orange when the

speed of transmission hits

10/100Mbps. Blinking when data

is transmitted/ received.

Lit green when the dev

ice is

connected to a broadband

connection device.

Blinking when data is

transmitted/received.

(BiPAC 9800N only)

Lit green when a wireless

connection is established.

Flash green when data is

transmitted/received.

Power ON/OFF

switch.

(BiPAC 9800N only)

Flash green when WP

configuration is in

progress. However, if WP

fails, the LED will only lit for

1 min before goes off.

(BiPAC 9800N only)

Connect the

detachable antenna.

Lit orange when WAN port fails

to get IP address. Lit green

when WAN port gets IP address

successfully. Lit off when the

device is in bridge mode or

when WAN connection absent.

(BiPAC 9800N only)

Push WP button to

trigger Wi-Fi Protected

etup

function.

Connect the fiber cable to the WAN port. There

are 2 options for single C interface:

100Base-BX and 1000Base-BX, and they do not

coexist. Please refer to the figures shown

below.

Billion BiPAC 9800(N) (802.11n) Fiber Optical Router

-3-

• 100BASE-BX: A single strand of optical fiber. Single-mode fiber is used. It

supports SC connector.

• 1000BASE-BX: A single strand of optical fiber. Single-mode fiber is used. It

supports SC connector.

Dual C Ports

Dual fiber AN interface is separated into single-mode and multi-mode.

•100BASE-LX/SMF: Two strands of optical fiber, one for receive (RX) and the

other for transmit (TX). Single-mode fiber is used. It supports SC connector.

•1000BASE-LX/SMF: Two strands of optical fiber, one for receive (RX) and

the other for transmit (TX). Single-mode fiber is used. It supports SC

connector.

•100BASE-FX/MMF: Two strands of optical fiber, one for receive (RX) and

the other for transmit (TX). Multi-mode fiber is used. It supports SC connector.

Connect the fiber cable to the WAN port. There are 3 options for

dual C interface: 100Base-LX/ MF, 1000Base-LX/ MF and

100Base-FX/MMF, and they do not coexist. Please refer to the

figures shown below.

Quick tart Guide

-4-

FP Port

A cage for SFP (Small Form-Factor Pluggable) transceiver- 100BASE or

1000BASE optical convector.

* Note 1: For WP configuration, please refer to the WP section of User Manual.

* Note 2: Please refer to the instructions on the label of the outer box or on the bottom of the

device to get the specification of your router

Install the Mini

GBIC module into the FP cage.

Connect the

fiber cable to the fiber port of Mini-GBIC module. We offer 2

types of FP interfaces: 100Base- FP and 1000Base- FP, and

they do not coexist. Please refer to the figure shown below.

Attention

Note that apply 100Base

module into

the

device

with 100Base- FP WAN interface. imilarly, ensure that

apply 1000Base FP module into the device with

1000Base- FP WAN interface. Please find the exact

WAN interface on the label of outer box or on the

bottom of device for the specification of your router.

Billion BiPAC 9800(N) (802.11n) Fiber Optical Router

-5-

Hardware Connection

Hardware Installation

1. Power Connection

Plug the supplied power adapter into the wall jack and the

other side to the router.

Please note that the plug type may differ according to country.

Quick tart Guide

-6-

2. LAN Connection

Connect the supplied RJ-45 Ethernet cable to one of the Giga Ethernet ports, and

the other side to the PC’s Ethernet interface.

3. Fiber Connection

Please follow the illustrations below to connect the fiber cable or module and the

router.

a) BX

Insert the single fiber cable into the BX jack of the router.

Warning

Please do not look steadily at the fiber port when

you connect the fiber, because the invisible light

may harm your vision.

Attention

The type of fiber interface varies from device models

provided by your I P. Please find the exact WAN

interface on the label of outer box, or label of the

bottom of device for the specification of your device.

And follow the instructions of hardware installation

corresponded to the device specification.

Billion BiPAC 9800(N) (802.11n) Fiber Optical Router

-7-

b) LX/ FX

Insert the dual fiber cable into the TX and RX jacks separately of the router.

c) FP

Set the Mini-GBIC module in the SFP port of your device, and then connect the

fiber cable to the module.

Connecting to the Router

1. Open the web browser and type http://192.168.1.254 in the browser's address box. This

number is the default IP address for this router. Press Enter.

2. A username and password window will appear. The default username and password are

admin and admin. Press OK to proceed.

3. You will get a status report web page and main menu screen.

Please see the relevant sections of user manual for detailed instructions on how to configure

your router.

Quick tart Guide

-8-

Troubleshooting

1. None of the LEDs lit when the router is turned on.

Examine the connection between the router and the adapter. If the problem persists, most

likely it is due to the malfunction of your hardware. Please contact your service provider or

Billion for technical support.

2. You have forgotten your login username and/or password.

Try the default username & password (please refer to User Manual). If this fails, restore your

router to its default setting by pressing the reset button for 1~2 seconds.

3. Cannot PING any PC on LAN.

Examine the Ethernet LEDs on the front panel. The LED should be on for the port that has a

PC connected. If it does not light, check to see whether the cable between your router and

the PC is properly connected. Make sure you have first uninstalled your firewall program

before troubleshooting.

4. Fail to make fiber connection.

Ensure the fiber cable or the mini-GBIC module has been connected correctly and the fiber

cable has not become damaged or bent. Ensure that you apply right fiber cable(s) into right

port(s) and right SFP module into right device as well. If the problem persists, Please contact

your service provider or Billion for technical support.

Product upport and Contact Information

Most problems can be solved by referring to the Troubleshooting section in the User Manual. If

you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer

where you purchased this product.

Contact Billion

WORLDWIDE

http://www.billion.com

Billion Product Registration

Billion is committed to before and after sales customer services. You will get the most out of your Billion's products

after registration. Please register online at http://www.billion.com/register to receive valuable services and support

from us.

BiPAC 9800(N)

V1.0
