BIGSTONE C500B-LCD Manual de usuario
C500B-LCD Instructions
Nanjing Bigstone Electronic & Technology co.,Ltd
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 1
content
About the User Manual....................................................................................................................... 2
Outlook and Size................................................................................................................................. 2
Material and Color...................................................................................................................... 2
Button Definition................................................................................................................................ 3
Function Summary..............................................................................................................................4
Function Summary......................................................................................................................4
Full View Area............................................................................................................................ 6
NORMAL VIEW AREA............................................................................................................ 6
Normal Operation................................................................................................................................7
1. ON/OFF...................................................................................................................................7
2. Current Display....................................................................................................................... 7
4. Speed Display......................................................................................................................... 7
5. Backlight Indicator..................................................................................................................8
6. 6KM/H Work...........................................................................................................................8
7. PAS Selection..........................................................................................................................9
8. PAS Level Selection................................................................................................................9
9. Error Code Indicator............................................................................................................... 9
10. User Setting Operation........................................................................................................10
11. Distance Indicator............................................................................................................... 21
12. Trip Time Indicator............................................................................................................. 22
13. Battery Indicator................................................................................................................. 22
14. MOBILE PHONE CHARGING INDICATOR..................................................................23
15. Cable Definition..................................................................................................................23
16. Auto Sleep after 5 Minutes................................................................................................. 24
Common Problems & Solutions....................................................................................................... 24
Quality & Warranty...........................................................................................................................24
Quality & Warranty：...............................................................................................................24
Other Items：............................................................................................................................25
Error Code Table............................................................................................................................... 25
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 2
About the User Manual
Dear users,
To ensure better performance of your e-bike, please read through the
C500B product introduction carefully before using it. We will inform you
all the details concisely （including hardware installation, setting and
normal operations）when using our display. Meanwhile, the introduction
will also help you solve possible confusion and malfunction.
Outlook and Size
Material and Color
C500B products are made of black ABS material and the bracket is
made of nylon material. Under the temperature of -20 to 60℃, the shell
material can ensure normal usage and good mechanical performance of
the products.
Dimension figure (unit: mm)
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 3
Button Definition
C500B has four buttons including ON/OFF 、SET 、UP and
DOWN.“ON/OFF” names to “ ”, “SET” names to “SET”; “UP”
names to “ ＋” and “DOWN” names to “－”.
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 4
Function Summary
Function Summary
C500B provides a wide range of functions and indicators to fit the
users’ needs. The indicated contents are as below.
1. ON/OFF
2. Current display
3. Speed display
4. KM/H & MPH
5. Backlight indicator
6. 6KM/H work
7. PAS selection
8 PAS level selection.
9. Error code indicator
10. SET operation
11. Distance indicator
11.1 Total distance (ODO)
11.2 Trip
11.3 Remaining distance (without this function by default)
12. Trip time indicator
13. Battery indicator
13.1 Battery residual capacity indicator
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 5
13.2 Battery voltage
13.3 Battery capacity percentage (without this function by default)
13.4 Battery charging and discharging times (without this function
by default)
14. Mobile phone charging indicator
15. Cable definition
16. Auto sleep after 5 minutes
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 6
Full View Area
NORMAL VIEW AREA
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 7
Normal Operation
1. ON/OFF
Hold ON/OFF and start the display. The display will provide power
for the controller. Hold ON/OFF again to open the backlight. With
display on, press ON/OFF for 2 seconds to turn off the power. With the
display off, there is no battery consumption. The leakage current is no
more than 2µA.
※The panel will go to sleep when the speed is 0 km/h for 5 minutes.
2. Current Display
That represents the discharging current of the controller currently,
each mark is 2A, six segments is >=12A.
4. Speed Display
The speed is as below, and user can select KM/H or MPH in
SET4.
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 8
5. Backlight Indicator
With the power on, click the ON/OFF and turn on the backlight.
Click it again and turn off the backlight.
※If the e-bike has headlight, the controller will turn on/off the
headlight at the same time of the backlight on/off (without this function
by default).
6. 6KM/H Work
Hold the DOWN for 2 seconds to get into 6km PAS work, and with
your hand off, the 6km PAS work is released. The display is as below.
www.bigstone-nj.com
Address：NO.38 Ningliu Road, Pukou District, Nanjing City, China
Tel：025-89618445
Fax：025 – 58849541
Email: [email protected]
page 9
7. PAS Selection
With the power on, Hold the UP for 2 seconds and turn on the Power
Assist System. Hold it again and turn off the Power Assist System.
8. PAS Level Selection
Click UP or DOWN to change the stages and output power ratio, the
default mode is mode 9 and it’s output power range from level 1 to level
9, the default value is level 0 .
9. Error Code Indicator
If there is something wrong with the electronic control system, the
display will flash at 1 HZ and show the error code automatically.
Different error code is corresponding with different error information.
See the last page Error code table for details.
