BHCnav NAVA 200 Manual de usuario
Owner’s Manual
1
Introduction
Thank you for purchasing NAVA handheld
GPS. NAVA is lightweight, compact,
rugged, reliable positioning and navigation
assistant to your outdoor activities. This
manual provides you the instructions to
use NAVA 200, 300, 400, and 600.
If you have further questions, please refer
to our website: Http://www.BHCnav.com
or contact us at Email:
NAVAsales@BHCnav.com and
NAVAsupport@BHCnav.com
Features of NAVA Series
Excellent GPS performance: With
its high-sensitivity, SBAS-enabled
GPS receiver, NAVA locates your
position quickly and precisely and
maintains its GPS location even in
heavy cover and deep canyons.
Long battery life: Powered by two
AA batteries, NAVA can work for up
to 15 hours. Powered by special
Li-ion battery, NAVA can work for
up to 25 hours.
User data compatibility: Export and
import user data from gpx, shp, kml,
dxf, csv to NAVA proprietary format.
Built-in Sensors (NAVA600): The
built-in 3-axis E-compass provides
you the bearing even when you stand
still, and its barometer
Owner’s Manual
2
pinpoints air pressure. Also, you can
use the thermometer to know
temperature conditions.
User POI icons: You can design your
own POI icons and load it to NAVA
unit.
Multi-power source: NAVA GPS
can be powered by 2xAA, Lithium,
USB, vehicle power adapter, AC
adapter.
Micro SD expandable: Uses a Micro
SD card to enlarge the storage
memory up to 4G. The card slot is
located inside the waterproof battery
compartment, so you don't have to
worry about getting it wet.
Lightweight and compact: NAVA is
lightweight and compact —the
perfect size for all your travels.
Basemap, city detail map, topo map
support: NAVA supports built-in
basemap and city detail/topo map on
the Micro SD card
Waterproof: IPX7.
Readable under sunlight: 65k
colors Transflective TFT LCD
Fast data transfer: USB 2.0
Drop resistance: 1.5m drop from
all 6 edges.
Owner’s Manual
3
Optional Accessories
For a complete list of available accessories
and maps for use with the NAVA GPS,
please refer to the BHCnav website:
Http://www.BHCnav.com
Manual Conventions
In this manual, small arrows () indicate
that you should highlight a series of items
on the screen using the ROCKER key, and
press in to ENTER after each item.
Owner’s Manual
4
Table of Contents
Introduction .............................1
Features of NAVA Series........................ 1
Optional Accessories.............................. 3
Manual Conventions.............................. 3
Getting Started.........................5
Key Functions........................................ 5
Installing the Batteries........................... 6
Turning the NAVA On and Off ..............7
Acquiring GPS Satellite Signals............ 7
Adjusting the Backlight......................... 7
Basic Operation .......................8
Waypoints .............................................. 8
Finding................................................. 12
Tracks................................................... 15
Routes.................................................. 17
Main Pages.............................19
GPS Status Page .................................. 19
Map Page............................................. 20
Compass Page...................................... 21
Weather Page (NAVA600 only)........... 23
Trip Computer Page............................. 23
Main Menu Page.................................. 24
Setting Page......................................... 24
USB Setting Page ................................ 25
Tools Page............................................ 27
Area Calculation.................................. 29
Coordinate System Setting .................. 29
Appendix.................................30
Specifications ...................................... 30
Connecting NAVA to Your Computer.. 33
Installing a Micro SD Card.................. 33
Declaration of Conformity................... 34
Owner’s Manual
5
Getting Started
Key Functions
Owner’s Manual
6
Installing the Batteries
The NAVA operates on two AA batteries or
special Li-ion batteries
(NAVA300/400/600).
To install AA batteries:
1. Remove the battery cover by turning
the D-ring counter-clockwise and
pulling the cover.
2. Insert the AA batteries, observing
the proper polarity.
To install special Li-ion batteries:
1. Remove the battery cover from the
back of the unit. Turn the D-ring
counter-clockwise and pull the cover.
2. Insert the Li-ion batteries.
Warning:Remove the batteries when you
do not plan to use the unit for long period.
Stored waypoint, trail, route data is not lost
when batteries are removed.
+
+
Pull
Owner’s Manual
7
Turning the NAVA On and Off
To turn the NAVA on, press and hold the
POWER key for more than 2 seconds. To
turn the NAVA off, press and hold the
POWER key for more than 2 seconds，
when the unit is on.
Acquiring GPS Satellite Signals
Before the NAVA can find your current
location and start navigation, you must
acquire GPS signals.
To quickly acquire GPS satellite signals:
1. Go outdoors to an open area, away
from tall buildings and trees.
2. Turn the NAVA on. Acquiring satellite
signals is automatic.
Please refer GPS Status Page (p.19) to
check the status of GPS satellite.
Adjusting the Backlight
1. When the NAVA is on, Press and
quickly release POWER key to open
the Backlight page.
2. Press right on the ROCKER key to
increase the brightness, press left to
decrease the brightness.
3. Press NEXT/EXIT key to close the
Backlight page.
Owner’s Manual
8
Basic Operation
This section explains basic operations you
can perform with your NAVA, including
creating and using waypoints, tracks,
routes, and using the Find Menu.
Waypoints
Waypoints are locations or landmarks you
record and store in your GPS. You can
mark a waypoint at your current location
on the map, or enter coordinates to create a
waypoint. You can add waypoints to routes
and navigate to a saved waypoint.
Marking Your Current Location
1. Press and release the MARK key.
2. To accept the waypoint with the
default information, select Save, and
press the ENTER key.
OR
To change waypoint name and note on
the Mark page, select the appropriate
field and press the ENTER key to
open the on-screen keypad. After
entering and confirming your changes,
select OK, and press ENTER key.
Owner’s Manual
9
Marking a Waypoint on the Map Page
1. On the Mark page, select Map.
2. On the Map Page, use the ROCKER
key to move the pointer ( )to the
location where you want to mark a
waypoint.
3. Press and quickly release ENTER to
capture the pointer location. If the
location captured contains no
information, a “No waypoint found,
add a waypoint?” message appears.
Select Yes to save the new waypoint.
Editing a Waypoint Attribution
You can edit a waypoint to change its icon,
name, coordinates, elevation and note.
1. Press and release the FIND key.
2. Select Waypoint.
3. Select the waypoint you want to edit,
and press ENTER key.
4. Make changes by highlighting each
field. Use the waypoint icon chart,
on-screen keypad and the ROCKER
key to enter new data.
Owner’s Manual
10
Deleting a Waypoint
1. Press and release the FIND key.
2. Select Waypoint.
3. Select the waypoint you want to
delete, and press ENTER key.
4. Press the MENU key, select Delete
Waypoint from submenu.
Warning: When you delete a waypoint,
you cannot recover it from the unit.
Moving a Waypoint on the Map Page
1. Press FIND key Waypoint.
2. Select the waypoint you want to
move, and press ENTER key.
3. Select Map to show the waypoint on
the map.
4. Press ENTER key to select the
Waypoint that you want to move.
5. Use ROCKER key to move the
pointer to a new location, and press
ENTER key.
6. Select OK to save the new waypoint.
Calculating Current Location By
Averaging
1. When NAVA acquires good GPS fix,
press MARK key AVG.
2. NAVA will average the location’s
longitude, latitude, altitude
automatically.
3. Press ENTER key, and Save the
waypoint.
Note: If NAVA doesn’t acquire GPS fix,
AVG button is disabled.
