Beta Three Rs12 Manual de usuario

ED-B3-MA-070604-004

USER MANUAL

Rs12

CONTENTS

FEATURES

ACOUSTIC CHARTS

INSTALLATION

DIMENSIONS

SPECIFICATION

LIMITED WARRANTY

SMS-YXSJ-Rs12-ED 3-EN

Rs12

LF 12" 1

HF 34mm 1

55Hz-20kHz

95dB

1.8kHz

FEATURES

SPECIFICATION

Transducers

Sensitivity(1m/1W)

Frequency Response(-3dB)

Crossover Point

Two transducers two way full range plastic speaker with coaxial horn, computerized stimulation design

12 inch woofer and 34 mm compression driver

HF horn is mounted on the LF axis

Used for full range sound reinforcement and can be used as ground monitor speaker

Apply to monitor, conference system and small scale performance

Flexible installation according to actual application

6.5

NL4 2 1+ 1-

15.5kg

18.5kg

440 374 542mm

490 420 608mm

THD

Net Weight

Gross Weight

Dimensions(W D H)

Packing Dimensions(W D H)

Rated Impedance

DC Iimpedance

Input Connectors

300W

Power(RMS)

Power(Program)

Power(Peak)

600W

1200W

SPL(1m)

MAX. SPL(1m)

120dB

126dB

40 90

Dispersion H V 90 40 @

SMS-YXSJ-Rs12-ED 3-EN

20 50 100 200 500 1k 2k 5k 10k 20k20 Hz

110.0

dBSPL

100.0

90.0

80.0

60.0

70.0

252

180

108

- 36

- 108

D e g

Rs12

FREQUENCY RESPONSE /PHASE RESPONSE

PHASE RESPONSE

FREQUENCY RESPONSE

IMPEDANCE RESPONSE

SMS-YXSJ-Rs12-ED 3-EN

Rs12

- 10

- 15

- 20

- 25

2 00 50 0

2K 5K 1 0K 2 0K1 50 Hz

3.0

6.0

10.0

- 5

WATERFALL

THD

20 50 100 200 500 1k 2k 5k 10k 20k20 Hz

110.0

dBSPL

100.0

90.0

80.0

60.0

70.0

252

180

108

- 36

- 108

D e g

Frequency Response 2nd Distortion 3rd Distortion

SMS-YXSJ-Rs12-ED 3-EN

Rs12

DIMENSION

Back view

374mm

542mm

440mm

Side view

Front view

INSTALLATION

Top view

SMS-YXSJ-Rs12-ED 3-EN

84mm

135mm

If malfunction occurs during the specified warranty period from the date of original purchase,

the product will be repaired or replaced without charge by Elder Audio.

The Limited Warranty doesnot apply to:

(a)exterior finish or appearance;

(b)certain specific items described in the individual product data sheet or owner's manual;

(c)malfunction resulting from use or operation of the product other than as specified in the

individual product data sheet or owner's manual;

(d)malfunction resulting from misuse or abuse of the product;

(e)malfunction occurring at any time after repairs have been made to the product by anyone

other than Elder Audio Service or any of its authorized service representatives.

To obtain warranty service, customer must deliver proof of purchase of the product in the form

of a bill of sale or receipt invoice.

Rs12 Speakers and Speaker Systems are guaranteed against malfunction due to defects in

materials or workmanship for a period of three (3) years from the date of original purchase. The

Limited Warranty does not apply to burned voice coils or malfunctions such as cone and/or coil

damage resulting from improperly designed enclosures. Additional details are included in the

Limited Warranty statement.

Rs12 Accessories are guaranteed against malfunction due to defects in materials or workman

ship for a period of one (1) year from the date of original purchase. Additional details are included

in the Limited Warranty statement. .

Rs12 Flying Hardware (including enclosure-mounted hardware and rigging accessories) is

guaranteed against malfunction due to defects in materials or workmanship for a period of one

(1) year from the date of original purchase. Additional details are included in the Limited Warranty

statement.

LIMITED WARRANTY

Specifications are subject to change without notice.

Rs12

SMS-YXSJ-Rs12-ED 3-EN

www.elderaudio.com
