Installation- and maintenance instruction

B45A 2.2

2Bentone

example Beispielexempel

3Bentone

General

Table of contents

1. General Information _____________________________________________ 4

2. Technical data B 45A 2,2 _________________________________________ 7

2.1 Dimensions B 45_____________________________________________ 7

2.2 Working ﬁeld B 45____________________________________________ 8

2.3 Setting of brake plate and air ﬂow ______________________________ 9

2.4 Recommended nozzle and pressure ____________________________ 9

2.5 Burner installation ____________________________________________ 9

2.6 Nozzle table________________________________________________ 10

2.7 Description B 45A 2.2 _______________________________________ 12

3. General instructions ____________________________________________ 14

3.1 General rules _______________________________________________ 14

4. Installation ____________________________________________________ 15

4.1 Handling and lifting instruktion ________________________________ 15

4.2 Acceptance inspection_______________________________________ 16

4.3 Preparations for installation ___________________________________ 16

4.4 Distribution of oil ____________________________________________ 16

4.5 Electrical connection_________________________________________ 16

4.6 Mount the burner on the boiler ________________________________ 17

4.7 Check oil line seals __________________________________________ 17

4.8 Air adjustment with damper motor _____________________________ 18

5. Burner installation______________________________________________ 19

5.1 Examples of basic setting B 45A2,2____________________________ 19

6. Burner servicing _______________________________________________ 21

6.1 Servicing the combustion assembly ___________________________ 21

6.2 Servicing air dampers _______________________________________ 22

6.3 Replacement of damper motor ________________________________ 23

6.4 Servicing the fan ____________________________________________ 24

6.5 Replacement of oil pump_____________________________________ 25

6.6 Vibration___________________________________________________ 26

7. Instructions Pump _____________________________________________ 27

7.1 SUNTEC A2L 65C - 75C ____________________________________ 27

8. Replacement of electrical components ___________________________ 33

9. Oil burner control ______________________________________________ 34

9.1 Wiring diagram ____________________________________________ 34

9.2 List of components__________________________________________ 35

9.3 Colour codes LMO14/24 _____________________________________ 36

9.4 Fault codes LMO14/24 ______________________________________ 36

10. Fault Location _______________________________________________ 37

10.1 Burner will not start__________________________________________ 37

10.2 Burner will not start after normal use ___________________________ 37

10.3 Delayed ignition_____________________________________________ 38

10.4 Noise in pump ______________________________________________ 38

10.5 Pump pressure _____________________________________________ 38

11. Log of ﬂue gas analysis_______________________________________ 39

12. Oil burners maintenance instructions __________________________ 40

4Bentone

1. General Information

This Installation and Maintenance manual:

• is to be regarded as part of the burner and must always be kept near

the installation site

• is intended for use by authorised personnel

• must be read prior to installation

• must be observed by all who work with the burner and associated

system components

• work with the burner may only be carried out by certiﬁed installers/

personnel

• Enertech AB is not liable for any typographical errors and reserves the

right to make design changes without prior notice.

• The burner may only be used for its intended purpose in accordance

with the product’s technical data.

• The burner may only be installed and operated by authorised

personnel.

• The product is packaged to prevent damage from occurring during

handling. Handle the product with care. Lifting equipment must be

used to lift larger packages.

• The products must be transported/stored on a level surface in a dry

environment, max. 80% relative humidity, no condensation.

Temperature -20 to +60 °C.

• Check that the burner is compatible with the boiler’s output range.

• The label information on the rating plate refers to the burner’s minimum

and maximum power.

• The power data on the type sign refers to the burner’s min. and max.

power.

• All components must be installed without being bent, twisted or

subjected to mechanical or thermal forces which can affect the

components.

• The burner must be installed so that it complies with local regulations

for ﬁre safety, electrical safety, and fuel distribution.

• Make sure when installing the equipment that there is enough space to

service the burner.

• Permitted ambient temperature during operation -0 to +60 °C. Max

80% relative humidity, no condensation.

• The installer must ensure that the room has adequate air supply.

• The room must comply with local regulations pertaining to its intended

use.

• The installation site must be free of chemicals.

• Burner pipes, fan wheels and air dampers may contain sharp edges.

• The surface temperature of the burner’s components can exceed 60

°C.

• Caution: The burner has moving parts, and there is risk of crushing

injuries.

165 105 01

5Bentone

• The electrical installation must be professionally carried out in

accordance with applicable high voltage regulations, as per Enertech’s

recommendations.

• Before servicing, shut off the fuel supply and turn off the power to the

burner.

• Leak checks must be performed during installation and servicing to

prevent fuel leakage.

• Care should be taken by the installer to ensure that no electrical cables

or fuel lines are crushed or otherwise damaged during installation or

servicing.

• If the boiler is equipped with an access hatch, this must be equipped

with a hatch opening switch connected to the burner's safety system.

• When in operation, the burner’s noise level can exceed 85 dBA.

Use hearing protection.

• The burner must not be put into operation without proper safety and

protection devices.

• A Class BE ﬁre extinguisher is recommended.

• It is forbidden to alter thedesign or use accessories which have not

been approved by Enertech in writing.

• Prior to operation, the following points must be checked:

-ﬁtting and installation work has been completed and approved

-electrical installation has been correctly performed

-ﬂue gas ducts and combustion air ducts are not blocked

-all actuators and control and safety devices are in working order and

correctly set

6Bentone

Components Service life – Recommended

replacement

Service life – Recommended

replacement Operating cycles

Control system 10 years 250,000 cycles

Pressure switch 10 years 250,000 cycles

Flame guard 10 years 250,000 cycles

UV ﬂame sensor 10000 hrs N/A

Damper motor 500 000 cycles

Contaktor 10 years 500,000 cycles

Burner 1 year 3000 hrs

Filter 1 year 3000 h Change

Oilhose 1 year control/change

Nozzle 1 year change 3000h Change

Electrods 1 Year Change /cleaning 3000h Change /cleaning

Brake plate 1 Year Change /cleaning 3000h Change /cleaning

Motor 1 year 3000 hrs

Cuppling chaft 1 year control/change 3000h control/change

Fan wheel “1 Year Change when dirty /

unbalance”

“3000h Change when dirty /

unbalance”

The burner and its components must be recycled according to applicable regulations.

Burner servicing schedule

Servicing must be carried out once a year or after 3000 hours of operation

Component replacement intervals

Delivery check

• Make sure everything is delivered and the goods have not been

damaged during transit.

• If something is wrong with a delivery, report it to the supplier.

• Transport damage must be reported to the shipping company.

7Bentone

165 105 77

* Min. recommended distance to ﬂoor.

2. Technical data B 45A 2,2

The burner is intended for:

• Light oil, B10 heating oil/biofuel blend (as deﬁned in DIN V51603-6)

and is used for:

• Water heating generators

• Hot air generators (these require LMO 24 255 C2E)

2.1 Dimensions B 45

A Ø B Ø C D E F G H I *J

B 45A2 240/340 159 134 480 252 328 335 262 515 200

IAD

øB

øC

8Bentone

2.2 Working ﬁeld B 45

8,5-45,5 kg/h

101-540 kW

2.2.1 Electric Speciﬁcation

Burner correspond to IP 20

Type Motor Complete

burner

Sound

B 45 450W 230V

50/60Hz 10µF

230V 3,3 A

50Hz

84 dBA ± 0,5

dBA

9Bentone

2.4 Recommended nozzle and pressure

Nozzle: 45° Solid/semisolid

60° Solid/semisolid

80° Solid/semisolid

Pump pressure 10 bar (8-25 bar) depending on pump model

2.5 Burner installation

2.5.1 Hole patten

Make sure the hole pattern on the boiler is designed for burner ﬂange.

Combustion

device

d1d2d3

B 45A 2 ø (135) 165 M14 ø (200) 224-270

Because of the various boiler types with varying furnace geometries and

furnace loads, it is impossible to commit to a certain scattering angle or a

speciﬁc distribution pattern.

It should be noted that the scattering angle and distribution pattern changes

with pump pressure.

!*NB It is important that

the spark does not strike

against the brake plate or

nozzle

2.3 Setting of brake plate and air ﬂow

a b c d

B45A 2 3,5-4,0 7,0-9,0 2,0-3,0 5,0-6,0

10 Bentone

Pump pressure bar

The table applies to oil with a viscosity of 4.4 mm 2/s at a density of 830 kg/m 3..

Gph 9 11

kg/h kW Mcal/h kg/h kW Mcal/h

0,85 3,00 36 31 3,32 39 34

1,00 3,53 42 36 3,90 46 40

1,10 3,88 46 39 4,29 51 44

1,20 4,24 50 43 4,68 55 48

1,25 4,40 52 45 4,88 58 50

1,35 4,76 56 48 5,27 62 54

1,50 5,29 63 54 5,85 69 60

1,65 5,82 69 59 6,44 76 66

1,75 6,18 73 63 6,83 81 70

2,00 7,06 84 72 7,81 93 80

2,25 7,94 94 81 8,78 104 89

2,50 8,82 105 90 9,76 116 99

2,75 9,71 115 99 10,73 127 109

3,00 10,59 126 108 11,71 139 119

3,50 12,35 146 126 13,66 162 139

4,00 14,12 167 144 15,62 185 159

4,50 15,88 188 162 17,57 208 179

5,00 17,65 209 180 19,52 231 199

5,50 19,42 230 198 21,47 255 219

6,00 21,18 251 216 23,42 278 239

6,50 22,94 272 234 25,37 301 259

7,00 24,71 293 252 27,33 324 279

7,50 26,47 314 270 29,28 347 298

8,00 28,24 335 288 31,23 370 318

8,50 30,00 356 306 33,18 393 338

9,00 31,77 377 324 35,14 417 358

kg/h kW Mcal/h

3,61 43 37

4,24 50 43

4,67 55 48

5,09 60 52

5,30 63 54

5,73 68 58

6,36 75 65

7,00 83 71

7,42 88 76

8,49 101 86

9,55 113 97

10,61 126 108

11,67 138 119

12,73 151 130

14,85 176 151

16,97 201 173

19,10 226 195

21,22 251 216

23,34 277 238

25,46 302 260

27,58 327 281

29,70 352 303

31,83 377 324

33,95 403 346

36,07 428 368

38,19 453 389

kg/h kW Mcal/h

3,87 46 39

4,56 54 46

5,01 59 51

5,47 65 56

5,70 68 58

6,15 73 63

6,83 81 70

7,52 89 77

7,97 94 81

9,12 108 93

10,26 122 105

11,39 135 116

12,53 148 128

13,67 162 139

15,95 189 163

18,23 216 186

20,51 243 209

22,79 270 232

25,07 297 256

27,49 326 280

29,63 351 302

31,91 378 325

34,19 405 349

36,47 432 372

38,74 459 395

41,02 486 418

2.6 Nozzle table

Tabla de contenidos

Otros manuales de Quemador de Bentone

Bentone

Bentone BFG 1 H2 Biogas Especificaciones técnicas

Bentone

Bentone BG 700i M Especificaciones técnicas

Bentone

Bentone BF 1 KS Especificaciones técnicas

Bentone

Bentone B 40 A2.2 Especificaciones técnicas

Bentone

Bentone BG550 Series Especificaciones técnicas

Bentone

Bentone BG 450 M Especificaciones técnicas

Bentone

Bentone BG 450-2 Especificaciones técnicas

Bentone

Bentone B 30 A2.2 Especificaciones técnicas

Bentone

Bentone B 30 A Especificaciones técnicas

Bentone

Bentone B 55-2 FAME Especificaciones técnicas

Bentone

Bentone B 55-2 Especificaciones técnicas

Bentone

Bentone BENTOFLEX ST 120 KAV Especificaciones técnicas

Bentone

Bentone B 45i A2.2H J/K Especificaciones técnicas

Bentone

Bentone BG 550 M LN Especificaciones técnicas

Bentone

Bentone BG 400 Manual de usuario

Bentone

Bentone B55 Especificaciones técnicas

Bentone

Bentone BF1 Series Especificaciones técnicas

Bentone

Bentone BG 650i M J/K IP54 Especificaciones técnicas

Bentone

Bentone B 40 A2.2 RME Especificaciones técnicas

Bentone

Bentone B 55-3R Especificaciones técnicas

Bentone

Bentone BF 1 FUV RME Especificaciones técnicas

Bentone

Bentone B55 Especificaciones técnicas

Bentone

Bentone B 45 A2.2H Especificaciones técnicas

Bentone

Bentone BENTOFLEX ST 146 B30A Especificaciones técnicas

Manuales populares de Quemador de otras marcas

Riello

Riello RS 28/M Guía de inicio rápido

True Induction

True Induction TI4B Manual de usuario

Weishaupt

Weishaupt WG20 Series Manual de usuario

Carolina Cooker

Carolina Cooker M116672 Manual de usuario

Riello

Riello RX 500 S/PV Manual de instrucciones

Unigas

Unigas HTP2000 Manual de usuario

baltur

baltur BT 250 DSG 4T Manual de usuario

muenkel design

muenkel design round burner Manual de usuario

Ecoflam

Ecoflam Multicalor 170.1 Manual de usuario

baltur

baltur BT 14 DSGW Manual de usuario

artisan

artisan Art-SB1 Guía

Riello

Riello P 140 T/G Guía de inicio rápido

AESYS

AESYS TurboFire II Manual de usuario

Riello

Riello RG1RKD Guía de inicio rápido

IKEA

IKEA GRILLSKÄR Manual de usuario

RUSTA

RUSTA SAREK Manual de usuario

PROPOINT

PROPOINT 8933657 Manual de usuario

baltur

baltur TBL 1000 ME Manual de referencia
