1
Chapter 1
Unpacking the Package
Check following items. If they are missing or damaged, consult your place of purchase
immediately.
Acer 211c color monitor Users manual
Power cord 15-pin D-SUB Macintosh adapter
signal cable (Optional)
?
Locate the model name and the serial number labeled on the back
of your monitor. Write down the related information of your
monitor and dealer in the space on page iii for future reference.
Unpacking the Package
:
2
Features
Super-fine Dot Pitch With 0.26mm super-fine dot pitch and anti-
static coating, Acer 211c color monitors
offer strikingly sharp and high resolution
image up to 1600 x 1200.
Wide Range AutoScan Horizontal frequency ranges from 30KHz to 107
KHz to support 1600 x 1600 @ 90Hz resolution.
Flicker-Free design for vertical frequency of up to
160Hz.
i key Pressing the i key, the monitor will automatically
(Fuzzy Auto calibrating) adjust displays size and position to the optimum.
No re-configuration or adjustment is needed
when a user changes display mode.
Low radiation Acer 211c is not only in compliance with
MPRII, but also meets strictest low radiation
regulations of MPRII and TCO95.
Users and Environment Acer 211c is produced by the ISO 14001
certified manufacturer, and in compliance
with the global environmental labelling
scheme -TCO95 which covers not only
standards regarding emissions,energy
efficiency, electrical and fire safety, but also
ergonomic qualities, and ecological
concerns.
Plug’n Play Compatibility Supporting VESA DDC I and DDC 2B
standards, Acer 211c is compatible with
Plugn Play feature of Window 95®/ 98®.
Chapter 1
:
3
Power Management
The Power management of this monitor complies with these
VESA power saving modes:
Mode Power Horizontal Vertical LED
Consumption Syne Sync
On Normal On On Green
Stand-by < 15 W Off On Amber
Suspend < 15 W On Off Amber
Off <5W Off Off Ambe Blinking
Overide Normal Off Off Green
Factory Preset Timings
Resolution Vertical Frequency Horizontal Frequency
(Hz) (KHz)
640 x 400 70 31.47
640 x 480 60 31.47
640 x 480 75 37.50
800 x 600 75 46.88
1024 x 768 75 60.02
1024 x 768 85 68.68
1280 x 1024 75 79.98
1280 x 1024 85 91.15
1600 x 1200 75 93.75
1600 x 1200 85 106
** All above timings are non-Interlace timings.
Unpacking the Package
:
4
Chapter 2
Chapter2
Installing the Monitor
This monitor is equipped with an autosensing universal compatible power supply for
voltage ranges 100-120/200-240V AC, 50~60Hz.. Please confirm the line voltage
designation at the rear panel of the monitor before connecting the machine.
1)
Make sure that the system power is turned off.
2) Please refer to the instructions below to connect the signal cable through D-SUB or
BNC.
3) Connect the power cord to the monitor and attach it to power source.
4) Turn on the computer and the monitor.
:
5
Connecting the Signal Cable
Your Acer 211c provides both D-SUB and BNC signal connectors. The
D-SUB or BNC signals can automatically be detected by its microprocessor.
✏Connecting through D-SUB signal connector
1) Make sure that the system power is turned off.
2) Connect the computer end of the D-SUB cable to the 15-pin output connector on
the video board of your computer.
3)Connect the monitor end of the D-SUB cable to the D-SUB receptacle on the back
of the monitor.
InstallingtheMonitor
:
6
Chapter 2
✏Connecting to An Apple
If you connect the monitor to an Apple Macintosh through a D-Sub cable, you need to
add the Macintosh adapter to connect the video signal port of your computer and the
monitor signal cable. Before connecting the adapter please refer to the user's guide of the
adapter to set the switches of the adapter.
:
7
InstallingtheMonitor
✏Connecting through BNC Signal Connector
1) Make sure that the system power is turned off.
2) Connect the computer end of the BNC cable to the output connector on the
video board of your computer.
3) Connect the monitor end of the BNC cable to the BNC receptacle on the
back of the monitor.
:
8
Chapter 3
lMenu key : enters or changes Main menus. There are three main menus.
lEnter key : enters sub-menus or selects items.
lExit key : goes back to main menus (auto save), or leaves OSD.
l& key :scrolls the light coloured bar up or down and represents
HOT KEY for brightness adjustment.
l&key : scrolls the light coloured bar left or right and represents
HOT KEY for contrast adjustment.
li key : is used for Fuzzy Automatic calibration adjustment.
Chapter 3
A Look at the Control Panel
:
9
Making Adjustments
i key (Fuzzy Auto Calibration )
Just push the i key, then the monitor will automatically adjust display's size
and position to the optimum. No re-configuration or adjustment is needed
when a user changes display mode.
The i key function is different from "Reset" function. "Reset" function for display's
geometry, size and position only works under the factory preset timings (please see
page 3). The i key function will work under "ANY" display timings which Acer
211c can support.
Hot Keys
Press or key to adjust contrast directly.
Press or key to adjust brightness directly.
A Look at the Control Panel
:
10
Chapter 3
OSD Operation
1) Press Menu key to enter or change Main menus (there are three main menus)
2) Press or keys to scroll light coloured bar to desired items.
3) Press Enter key to enter sub-menus.
4) Press ,(,) key to do the adjustments. If the sub-menu contains
multiple items. Press or keys to scroll light coloured bar to
desired items. Then press or key to adjust as required.
5) Press Exit key to save and return to main menus.
6) Press Exit key to save and leave OSD
?
Reset to the factory default settings, please see General Settings
Reset and Color Temperature Reset.
Main Menu 1 Display Control
This main menu includes six items. Scroll the light coloured bar to desired items and
press Enter to sub-menus.
