Global Technical Operations

gto.gnresound.com

Lautrupbjerg 7 • DK-2750 Ballerup • Denmark

E-Mail: [email protected]

Technical Manual

Beltone

Paris Platform BTE

Doc 0176160 rev. I

Page 2 of 19

Not subject to issue control when printed

Table of Contents

Form-Factor-Matrix..............................................................................................................3

Colour Overview..................................................................................................................4

Part List ......................................................................................................................... 5-10

Disassemble Procedure ....................................................................................................11

Replacing Toggle Cap .......................................................................................................12

Replacing Top HSG, Module, PB & Mic Cover..................................................................13

Replacing Bottom HSG with ID Plate ................................................................................14

Service & Postponement Procedure .................................................................................15

Connecting the Programming Adaptor ..............................................................................16

Programming Adaptor Clip ................................................................................................17

Test Equipment..................................................................................................................18

Testing ..............................................................................................................................19

Doc 0176160 rev. I

Page 3 of 19

Not subject to issue control when printed

Form-Factor-Matrix

Platform Product Name Model Data Sheet

Paris 60 BTE REACH 66 RCH66D 16649700

IDENTITY 66 IDT66D 16765400

Paris 70 BTE

REACH 76 RCH76D 16649800

REACH TBR (Tinnitus) 76 TBR76 16871900

IDENTITY 76 IDT76D 16765500

Paris 80 BTE REACH 86 RCH86D 16649900

IDENTITY 86 IDT86D 16765600

This Technical Manual serves to outline the service & postponement procedure for products listed in the form-factor-matrix below:

PARIS 60 PARIS 70 PARIS 80

Doc 0176160 rev. I

Page 4 of 19

Not subject to issue control when printed

RUBY

RED

PRECIOUS

WHITE

MAJESTIC

SILVER

PRECIOUS

BLACK

DOVE BLUE CHROME ROSE PINK BRONZE

BEIGE LIGHT GREY GREY BROWN CHARCOAL STONE SOFT BEIGE SOFT GREY SOFT STONE

Colour Overview

Doc 0176160 rev. I

Page 5 of 19

Not subject to issue control when printed

Description PARIS 60 PARIS 70 PARIS 80

CHILDLOCK, BLUE 16165801 15966401 15966401

CHILDLOCK, RED 16165800 15966400 15966400

THIN TUBE ADAPT 16187000 16187000 N/A

PIN Ø0.6 (Front) 15344200 16059700 16059600

PIN Ø0.6 (Rear) 16059800 15168000 16342400

PIN Ø0.6 (Bat door) 16059700 16059700 15344300

HOOK FILTER, 4 PCS 16166700 16166700 N/A

TONE TUBE ADULT (no lt) 16186700 16186700 16186700

TONE TUBE BABY (no lt) 16186900 16186900 16186900

TONE TUBE CHILD (no lt) 16186800 16186800 16186800

TONE TUBE ADULT (w/lt) 17044100 17044100 N/A

TONE TUBE BABY (w/lt) 17044300 17044300 N/A

TONE TUBE CHILD (w/lt) 17044200 17044200 N/A

PB CAP, SINGLE 15967300 15967300 15967300

PB CAP, DOUBLE N/A 15967400 15967400

AUDIO BOOT 18330400 18330500 18330600

PARIS 70/80

PB CAPS

(single & double)

PARIS 60

PB CAP (single)

4 pcs Hook Filter

p/n 16166700

Hook lter is to be mounted in

tone tubes for Paris 60 & 70 only

Tone tubes for PARIS 80 must

always be without lter

Part List

Colour markers

Doc 0176160 rev. I

Page 6 of 19

Not subject to issue control when printed

Description Part No

PROG. ADAPTOR 18041400

TEST FIXTURE 16695100

TEST FRAME 16902800

CS44 PROGRAMMING CABLE (R) 9022 907 69019

CS44 PROGRAMMING CABLE (L) 9022 907 69029

CLIP,PROGRAMMING ADAPTOR,RED 17736900

CLIP,PROGRAMMING ADAPTOR,BLUE 17736901

MEASSUREMENT TOOL 15200800

PIN REMOVAL TOOL 15502500

TOGGLE REMOVER (Paris 70/80) 16167000

Service modules are none serviceable at local site. Instead defective service modules must be returned to Global Repair Site

Part List

Service Modules (ASM FRAME, PROGRAMMED):

PARIS 60 PARIS 70 PARIS 80

RCH66D 16911600 RCH76D 16911800 RCH86D 16962000

IDT66D 16911700 IDT76D 16911900 IDT86D 16962100

TBR76 16912000

Pin removal tool

Measurement tool 15200800 for

both left and right side

Doc 0176160 rev. I

Page 7 of 19

Not subject to issue control when printed

HI Colour

Description

PARIS 60/70/80

Mic Cover

PARIS 60/70/80

Actuator PB

PARIS 70/80

Toggle VC

PARIS 70/80

VC Cover

PARIS 60

Batt Door

PARIS 70/80

Batt Door

BEIGE 16186100 16960100 16187500 16381900 16386400 16387400

GREY 16186101 16960101 16187501 16381901 16386401 16387401

LIGHT GREY 16186102 16960102 16187502 16381902 16386402 16387402

BROWN 16186103 16960103 16187503 16381903 16386403 16387403

CHARCOAL 16186104 16960104 16187509 16381910 16386419 16387419

STONE 16186105 16960105 16187505 16381905 16386405 16387405

SOFT BEIGE 16186100 16960100 16187500 16381900 16386406 16387406

SOFT GREY 16186101 16960101 16187501 16381901 16386407 16387407

SOFT STONE 16186105 16960105 16187505 16381905 16386408 16387408

PRECIOUS BLACK 16186106 16960106 16187506 16381906 16386409 16387409

PRECIOUS WHITE 16186107 16960107 16187507 16381909 16386410 16387410

MAJESTIC SILVER 16186121 16960107 16187507 16381909 16386411 16387411

BRONZE 16186106 16960106 16187506 16381906 16386412 16387412

DOVE BLUE 16186121 16960107 16187507 16381909 16386413 16387413

RUBY RED 16186121 16960107 16187507 16381909 16386414 16387414

ROSE PINK 16186121 16960107 16187507 16381909 16386415 16387415

CHROME 16186121 16960107 16187507 16381909 16386416 16387416

Note:

The description in left column is the colour description for the HI & Replacement Kits. In some cases an e.g. transparent Mic cover is used in vari-

ous HI colours and is therefore listed more than one time

Separate HSG parts are not nano coated

Part List - Housing Parts

Doc 0176160 rev. I

Page 8 of 19

Not subject to issue control when printed

HI Colour

Description

PARIS 60

HSG Bottom

PARIS 70

HSG Bottom

PARIS 80

HSG Bottom

PARIS 60

HSG Top

PARIS 70

HSG Top

PARIS 80

HSG Top

BEIGE 16184400 16184500 16184600 16187700 16187200 16187900

GREY 16184401 16184501 16184601 16187701 16187201 16187901

LIGHT GREY 16184402 16184502 16184602 16187702 16187202 16187902

BROWN 16184403 16184503 16184603 16187703 16187203 16187903

CHARCOAL 16184404 16184504 16184604 16187704 16187204 16187904

STONE 16184405 16184505 16184605 16187705 16187205 16187905

Note:

Only the above HSG parts are available as separate

spare parts. Parts in other colours must be ordered as

a replacement kit. The description in left column is the

colour description for the HI & Replacement Kits.

Separate HSG parts are not nano coated HSG Bottom HSG Top

Part List - Housing Parts

Doc 0176160 rev. I

Page 9 of 19

Not subject to issue control when printed

Replacement Kit - colour PARIS 60 PARIS 70 PARIS 80

BEIGE 16400000N 16400100N 16400200N

GREY 16400001N 16400101N 16400201N

LIGHT GREY 16400002N 16400102N 16400202N

BROWN 16400003N 16400103N 16400203N

CHARCOAL 16400004N 16400104N 16400204N

STONE 16400005N 16400105N 16400205N

SOFT BEIGE 16400006N 16400106N N/A

SOFT GREY 16400007N 16400107N N/A

SOFT STONE 16400008N 16400108N N/A

PRECIOUS BLACK 16400009N 16400109N N/A

PRECIOUS WHITE 16400010N 16400110N N/A

MAJESTIC SILVER 16400011N 16400111N N/A

BRONZE 16400012N 16400112N N/A

DOVE BLUE 16400013N 16400113N N/A

RUBY RED 16400014N 16400114N N/A

ROSE PINK 16400015N 16400115N N/A

CHROME 16400016N 16400116N N/A

Replacement kit contains:

- Top-housing

- Bottom housing

- Battery door

- Push-button cap/actuator

- VC toggle (PARIS 70/80)

- VC cover (PARIS 70/80)

- Mic Cover

- Housing Pins

Replacement kits are nano coated

Mounting the Replacement Kits:

Please refer to Doc 0173460:

WORKING INSTRUCTIONS,REPLACEMENT KITS, BELTONE PARIS BTE PLATFORM

Part List - Replacement Kit (nano coated)

Doc 0176160 rev. I

Page 10 of 19

Not subject to issue control when printed

THIN TUBE BLISTER PACKS

(5 tubes & 3 cleaning wires) Part No

THIN TUBE 2,0A,R,BLSTR 18628600

THIN TUBE 2,0B,R,BLSTR 18628700

THIN TUBE 2,1A,R,BLSTR 18628800

THIN TUBE 2,1B,R,BLSTR 18628900

THIN TUBE 2,2A,R,BLSTR 18629000

THIN TUBE 2,2B,R,BLSTR 18629100

THIN TUBE 2,3A,R,BLSTR 18629200

THIN TUBE 2,3B,R,BLSTR 18629300

THIN TUBE 2,-1B,R,BLSTR 18629400

THIN TUBE 2,0A,L,BLSTR 18629500

THIN TUBE 2,0B,L,BLSTR 18629600

THIN TUBE 2,1A,L,BLSTR 18629700

THIN TUBE 2,1B,L,BLSTR 18629800

THIN TUBE 2,2A,L,BLSTR 18629900

THIN TUBE 2,2B,L,BLSTR 18630000

THIN TUBE 2,3A,L,BLSTR 18630100

THIN TUBE 2,3B,L,BLSTR 18630200

THIN TUBE 2,-1B,L,BLSTR 18630300

THIN TUBE DOMES

Description Bag

(10 pcs)

Blister Pack

(8 pcs)

DOME,THNTUB/REC,SZ5,SM 18500800 18607100

DOME,THNTUB/REC,SZ7,MDM 18500900 18607200

DOME,THNTUB/REC,SZ10,LGE 18501000 18607300

DOME,THNTB/REC,TULIP,STD 18501100 18607400

DOME,THNTUB/REC,PWR,SM 18265100 18607500

DOME,THNTUB/REC,PWR,MDM 18265200 18607600

DOME,THNTUB/REC,PWR,LGE 18265300 18607700

Part List - Thin Tubes & Domes
