Bellfires Derby Guía de configuración
INSTALLATION INSTRUCTIONS AND INSTRUCTIONS FOR USE
Gas fires with closed combustion system
Original Bell-series - Retro Bell-series
Horizon Bell Medium / Small-series - Corner Bell Small L/R
Vertical Bell-series - View Bell-series
Bellfires wishes you many cosy evenings with your new Bellfires gas fire
This document is an essential part of your gas fire.
Read it carefully before installation and use of the
gas fire and keep it in a safe place!
www.tapis.pl
3
Bellfires English
Instructions for use and installation instructions
BELLFIRES GAS FIRES WITH CLOSED COMBUSTION SYSTEM:
Original Bell - series:
Derby (DY)
Derby II (DY II)
Jersey (JY)
Flat Bell (FB)
Topsham (TS)
Topsham Tunnel (TST)
York (YK)
Kent (KT)
Retro Bell - series:
Retro Bell Intermediate (RBI)
Retro Bell Small (RBS)
Horizon Bell Medium / Small - series:
Horizon Bell Medium (HBM)
Horizon Bell Small (HBS)
Horizon Bell Small Tunnel (HBST)
Corner Bell - series:
Corner Bell Small L/R (CBS - L/R)
Vertical Bell - series:
Vertical Bell Large (VBL)
Vertical Bell Large Tunnel (VBLT)
Vertical Bell Small (VBS)
View Bell - series:
View Bell Small (VWBS)
View Bell Vertical (VWBV)
4
Bellfires English
Instructions for use and installation instructions
5
Bellfires English
Instructions for use and installation instructions
CONTENTS
Page
1. WARRANTY TERMS ................................................................................. 7
2. INSTRUCTIONS FOR USE ....................................................................... 9
3. INSTALLATION INSTRUCTIONS .............................................................. 22
4. MAINTENANCE ......................................................................................... 60
5. FAULTS ...................................................................................................... 61
6. ELECTRICAL DIAGRAM ........................................................................... 62
7. DIMENSIONS ............................................................................................ 63
8. TECHNICAL DETAILS/REGULATIONS .............................................
..
..... 73
9. REPLACEMENT PARTS LIST ..................................................
......
.......... 85
10. DISPOSAL OF PACKAGING AND APPLIANCE
......................................
. 88
6
Bellfires English
Instructions for use and installation instructions
7
Bellfires English
Instructions for use and installation instructions
Bellfires gas fire
Warranty
Bellfires guarantees the quality of the supplied hearth and the quality of the
materials used.
This warranty runs for a period of twelve (12) months from first use of the hearth
and covers defects which are a result of construction faults or the failure of
component parts.
Bellfires has an obligation under the terms of this warranty (at its discretion) not
to charge for the replacement of any component parts.
Note: The following aspects are not covered under the terms of the warranty:
- defects arising which are attributable in whole or in part to:
a Not paying due heed to installation, operating and maintenance
instructions
b Fitting/installation or repair by third parties (including the buyer)
c Heat cracks arising in the jacket due to normal heating
d Discolouration in the ironwork as a result of heat transfer
- the grate, the thermocouple and the glass of the product
Should you wish to claim under the warranty,
please contact your dealer.
Please carefully retain your invoice with this warranty!
Your Bellfires dealer: Date of installation:
Bellfires
Hallenstraat 17
NL-5531 AB Bladel
Tel. + 31 497 339200 Fax. + 31 497 339210
1. WARRANTY TERMS
∇
8
Bellfires English
Instructions for use and installation instructions
9
Bellfires English
Instructions for use and installation instructions
2 INSTRUCTIONS FOR USE
2.1 INTRODUCTION
Congratulations on your purchase of this modern Bellfires gas fire. This quality product
will provide you with many years of enjoyment due to the flame effect and warmth that
it provides. Please read the instructions for use carefully before using the appliance for
the first time. Keep this booklet in a safe place.
2.2 BUILT-IN PROTECTION OF THE APPLIANCE
The appliance is fully protected by means of a thermo-electric pilot light shut off in the
event of a gas escape from the main burner.
2.2.1 Safety
Do not place embers, vermiculite granules, wood logs or pebbles
against the pilot light burner. Make sure that the pilot flame can
burn at all times freely over the main burner. Only in this way is
proper ignition of the main burner ensured.
Ignoring these directions could lead to a dangerous situation.
It is essential that the appliance, the complete concentric flue
system and the outlet are cleaned and inspected annually by a
recognised fitter/gas specialist. The safe operation of the appliance
will thus remain guaranteed.
See for additional instructions Chapter 4: Maintenance.
If the pilot flame goes out for any reason, wait for 5 minutes before
attempting to re-light it.
The gas fire must never be used with the door open or the door
glass removed.
Never place flammable material on the ceramic log set.
The filling of the main burner with embers, vermiculite granules,
wood logs and pebbles may not under any circumstances be
changed or added to.
Do not place easily-flammable materials, such as nylon clothing or
flammable liquids, in the vicinity of the gas fire.
10
Bellfires English
Instructions for use and installation instructions
“OFF” POSITION
IGNITION POSITION
CONTROL KNOB
BURNER CONTROL RANGE
Ensure at all times that children and other people who are not
aware of the operation of the gas appliance are only in the vicinity
of the appliance exclusively under supervision.
Use a fireguard to protect the people and children mentioned
above against possible burns.
2.3 OPERATING YOUR GAS FIRE - GENERAL
Read these instructions carefully before lighting the fire!
The gas fire can be operated with a pilot light that burns continuously. The ignition and
control knob is located at the bottom of the front of your gas fire or outside the gas fire
in a special box (supplied). If the control knob is fitted to the front of the gas fire, the gas
fire frame must be removed to access the knob.
The pilot light is situated in the front of the burner, behind a cowl. Should the pilot light
go out, you must wait five (5) minutes before attempting to re-ignite the fire.
Important
Once the fire is lit, it must burn at maximum for approx. 10 minutes to allow the chimney
to come up to temperature.
2.4 HAND CONTROL
The burner is operated using the control knob. Select the required setting and the
burner will then burn at this setting until it is changed.
Figure 1: Gas regulator block BM 733
