RELEASE NOTE

RELEASE NOTE FOR ROUTER F5D7230-4, FIRMWARE 2.00.04

DATE: JUNE 20TH 2003

6/20/2003 CONFIDENTIAL PAGE 1OF 3

These release notes describe features and caveats. The main code module for this release is compatible and

downloadable into the switch over the network using the TFTP protocol. Please refer to the Installation and User

Guide for a detailed description of the download procedure.

Refer to the Belkin User Guide for information about using the embedded web management capability of the

switch.

This version of software Belkin_2.00.04 supports the following models of the F5D7230-x product family:

•F5D7230-4

•F5D7130

Release notes for 2.00.04

BELKIN_2.00.04 ----- USA version router image (wireless channel 1—11)

BELKIN_AP_2.00.04 ----- USA version AP image (Wireless channel 1-11)

Bugs fixed:

1. Issue Summary: Latest wireless driver that complies with 802.11g and WPA standards.

-Fixed

2. Issue Summary: Parental Control : Refresh account sometimes does not work.

-Fixed

3. Issue Summary: Parental Control : Policy Violation Override does not work properly in 2.00.01

-Fixed

Release notes for 2.00.01

BELKIN_2.00.01 ----- USA version router image (wireless channel 1—11)

BELKIN_AP_2.00.01 ----- USA version AP image (Wireless channel 1-11)

Feature Enhancements:

1. Fully compliant with ratified 802.11g specifications.

2. WPA (Wi-Fi Protected Access) support added

Features not supported:

RELEASE NOTES SOFTWARE RELEASE 2.00.01

BELKIN COMPONENTS, INC.

6/20/2003 BELKIN CONFIDENTIAL PAGE 2OF 3

1. Using WPA security over wireless bridging (WDS) feature

Bugs fixed:

1. Issue Summary: 54g router: Router doesn't always display serial # in the home page with version 2.00.00 FW

-Fixed

Issue Summary: 54g Router: Cannot add MAC addresses on MAC filtering page with 2.00.00 FW

-Fixed

Issue Summary: 54g Router: Easy Install cannot program router for Static connection with 2.00.00 FW

-Fixed

Issue Summary: 54g router: User cannot see key generatedusing Passphrase WEP even before it's applied

-Fixed

Issue Summary: 54g router web interface login and logout produces brief error message

-Fixed

Issue Summary: 54g router: Cannot apply Wireless Security while in Acess Point mode

-Fixed

Issue Summary: 7010 -Wireless sub menu is inconsistent with the left hand menu list.

-Fixed

Issue Summary: 7230-4 : Textual GUI changes, errors...

-Fixed

Issue Summary: hen attempting to change the LAN IP address to a 172.X.X.X number a message is displayed

that only a non routable IP address can be used.

-Fixed to accept 172.16.0.0/12 as the non-routable IP

10.

Issue Summary: Under the heading Internet WAN the word Internet is incorrectly spelt.

-Fixed

11.

RELEASE NOTES SOFTWARE RELEASE 2.00.01

BELKIN COMPONENTS, INC.

6/20/2003 BELKIN CONFIDENTIAL PAGE 3OF 3

Issue Summary: Upon Clicking on the heading Wireless the wording encryption is listed, there is not any

heading for encryption this should be labeled Security.

-Fixed

12.

Issue Summary: Saving the router configuration does not give a download dialogue box asdescribed in the

manual, but instead open’s a text editor.

-Fixed

13.

Issue Summary: Upon logging out there is router source code visible.

-Fixed

14.

Issue Summary: When selecting the level of security (WPA/Web) there is no mention of theminimum or

maximum length of keys.

-Fixed

15.

Issue Summary: Change WPA-Radius Server to WPA (with Radius Server). And add the following text:

WPA (with server)

Advanced Setting -Wireless Protected Access using a server to distribute keys to the clients: This option requires

that a Radius server is running on the network.

-Fixed

16.

Issue Summary: Add a checkbox next to “Pre-shared Key (PSK)” entry that says “Obscure PSK”. It should be

unchecked by default. If the user checks it, thekey will be obscured.

-Fixed
