Belkin F5U271 Manual de usuario

Hi-Speed USB 2.0 Media

Reader & Writer with

3-Port Hub

F5U271eaUser Manual

Transfer data and connect USB

peripherals with one device

2 EN

Introduction .............................................................1

Reader Features ..................................................................... 2

Hub Features ..........................................................................3

Hub Speciﬁcations .................................................................4

System Requirements ............................................................5

Package Contents ..................................................................5

Media Insertion .......................................................................6

Installation Procedure for Windows .........................7

Connecting USB Devices to the Hub ................................... 10

Safe Removal of Media Cards and Readers ....................... 10

Uninstalling your Reader ...................................................... 11

Installation Procedure for Mac OS .......................... 12

Connecting USB Devices to the Hub ................................... 14

Accessing Files and Data ..................................................... 14

Safe Removal of Digital Flash Media Cards ........................ 14

Uninstalling your Reader ...................................................... 15

Information ........................................................... 16

Table of Contents

___

EN 1

Congratulations

Thank you for purchasing the Belkin Hi-Speed USB 2.0 Media Reader &

Writer with 3-Port Hub (the Reader). This innovative product reads the

following popular flash-memory formats.

• CompactFlash® Type I and Type II / CompactFlash® Extreme Card

• IBM® Microdrive™

• SmartMedia™

• SmartMedia™ RAM Card

• Secure Digital / Mini SD*/ SDHC

• MultiMediaCard / RSMMC (Reduced Size MultiMediaCard)* / High Speed

MultiMedia Card

• XD Picture Card

• Memory Stick® / Memory Stick Duo™*,

• Memory Stick Pro™ / Memory Stick Pro Duo™*,

• Memory Stick MagicGate™ / Memory Stick MagicGate Duo™*

(non-secure mode only)

• MultiMedia Card 4.0

• Memory Stick MagicGate Pro™*

• Memory Stick Select Function card

• High Speed Memory Stick

• Memory Stick Ultra II

*Requires use of adapter included with media card

Please visit our website www.belkin.com for the most updated

compatibility list.

Introduction

2 EN

___

1The Reader features a built-in Hi-Speed USB 2.0 3-Port Hub. It enables

you to connect USB devices with a critical advantage over traditional USB

2.0 hubs. That is its implementation of the new “Quad TT” architecture,

which enables each of the Hub’s three downstream ports to deliver a full

12Mbps of USB bandwidth for low- and full-speed devices, while providing

total support for Hi-Speed USB 2.0 devices. This is especially important

when connecting multiple, bandwidth-intensive, full-speed devices such as

USB webcams, speakers, scanners, and external storage devices.

In addition to Readers, Belkin manufactures an entire line of USB and PC

accessories. Please visit belkin.com for details.

Reader Features

• Easy transfer of data between slots

• Quick and easy access to digital photos, MP3s, and other digital files

• Functionality as a removable media storage device

• Bus- or self-powered; no power supply required in most circumstances

• Plug-and-Play, hot swap capability

• Drag-and-drop file transfer

• Custom drive icon support using the included driver

• Manufacturer’s Lifetime Warranty

___

Introduction

EN 3

Hub Features

• Compliant with Universal Serial Bus Specification 2.0

(data rate 1.5/12/480Mbps)

• Backward-compatible with Universal Serial Bus Specification 1.1

(data rate 1.5/12Mbps)

• Compatible with Windows® 98 SE, Me, 2000, XP and Vista

• Approved by USB Implementers Forum (USB-IF)

• Plug-and-Play support

• Support for hot swapping of USB devices

• Overcurrent detection and protection

• Individual port-status indicator LEDs

• Three 480Mbps downstream ports

• Bus- or self-powered

• Compatibility with USB 1.1 and USB 2.0 devices

Introduction

4 EN

___

1Hub Specifications

Upstream Ports (1)

Downstream Ports (3)

Per-Port Voltage DC +5V

Per-Port Current 500mA (max)

Power Mode Self-powered/bus-powered

Operating Temperature 5ºC ~ 40º C

Storage Temperature -20º C ~ 60º C

Enclosure ABS plastic

Power Supply Output: DC 5V 2.0A

Plug Size: 3.5mm (outer)

1mm (center)

Plug Polarity: Center positive

USB Hub Port-Status LED Color Definitions:

Off No USB device present

Red USB device installed and initialized

Reader Status LED Color Definitions

Off Normal state

Flashing Red Data being transferred

___

Introduction

EN 5

System Requirements

• Computer with available USB port (USB 2.0 port for Hi-Speed mode)

• Windows 98 SE, Me, 2000, XP, or Vista

• Mac OS® 9.x or Mac OS X v10.1.2* or higher (custom icons not

supported in OS X)

*Hi-Speed USB 2.0 is supported in OS X v10.2.8 and above.

Package Contents

• Belkin Hi-Speed USB 2.0 Media Reader & Writer with 3-Port Hub

• USB Device Cable

• Power Supply

• User Manual

• Installation CD

Introduction

6 EN

___

1Media Insertion

To prevent damage to your Reader and/or media card, be sure to insert

the media card correctly into the Reader. See the drawings below that

illustrate the proper orientation for insertion of your media card.

Important Note: The Reader uses a combination slot designed to

accommodate both XD Picture Card and SmartMedia card formats.

Only a single card may be plugged into the combination slot at any time.

___

EN 7

IMPORTANT NOTE: DO NOT PLUG READER INTO COMPUTER

UNTIL INSTRUCTED TO DO SO

Windows 98 SE, Me, 2000, XP, Vista

Driver Installation

1. Insert the Belkin Driver Installation CD.

a) After a few moments, the setup application will appear on

your computer screen.

b) If the setup application does not appear, double-click “My

Computer”, and then click on your CD-ROM drive icon. This

will load the setup application’s main page.

2. Click the “Install Driver” button.

3. The “InstallShield Wizard” will now start. Click “Next” on each of the

screens that are displayed, and then click “Finish”. Now, restart your

computer to complete the driver installation process.

Important Operating System Notes:

a) Windows Me, XP and Vista offer native support for mass-storage

devices. It is not necessary to install the Belkin driver in order

to use the Reader. However, if you wish to take advantage of the

custom drive icons, the driver must be installed. Note: Custom Icon

support is currently unavailable for Vista.

b) Windows 2000 also offers native support for mass-storage devices,

but in versions prior to Service Pack 3, does not support “multi-

LUN” devices. If the Belkin driver is not installed in Windows 2000

versions prior to Service Pack 3, only the CompactFlash slot will be

available. Furthermore, if you wish to take advantage of the custom

drive icons, the driver must be installed.

Installation Procedure for Windows

8 EN

___

c) Windows 98 SE does not support mass-storage devices; therefore,

the Belkin driver must always be installed.

Hardware Installation

Important Note: Please do not connect any USB devices to the Hub’s

ports until the installation process has been completed.

1. Plug the AC adapter into a wall outlet or surge suppressor. Plug

the DC connector into the DC power jack found on the rear of the

Reader.

Note: The hub may be used without the power supply with

most USB devices.

2. Plug the flat end (USB-A connector) of the provided USB device

cable into the downstream port of your computer, or downstream

port of another hub. Plug the small end (USB-B mini-B connector)

into the USB-B mini-B connector on the back of the Reader.

Important Note: The Reader must be connected to a USB 2.0-compliant

host in order to function in Hi-Speed mode (480Mbps data rate). If the Hub

is connected to a USB 1.1-compliant host, it will operate only in low-speed

or full-speed mode (1.5Mbps/12Mbps).
