Belkin PM01110EA Manual de usuario

ENGLISH

FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

ITALIANO

G WIRELESS

ROUTER

User Manual

PM01110ea F5D7234- 4

G Wireless Router

SECTIONS 12345678910Table of Contents

TABLE OF CONTENTS

Securing your Wi-Fi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

WEP Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Using Wi-Fi Protected Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

WPA Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Setting WPA/WPA2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Guest Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Using the Access Point Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Configuring the Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Setting MAC Address Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Enabling the DMZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Utilities Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Restarting the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

7 Manually Configuring Network Settings � � � � � � � � � � � � � � � � � � �86

8 Recommended Web Browser Settings � � � � � � � � � � � � � � � � � � � � 91

9 Troubleshooting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 93

10 Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 109

1 Introduction � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 1

Benefits of a Home Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Advantages of a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Placement of your Router for Optimal Performance . . . . . . . . . . . . . . . . .2

2 Product Overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Knowing your Router � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Setup Assistant Software System Requirements . . . . . . . . . . . . . . . . . . .7

4 Connecting and Configuring your Router � � � � � � � � � � � � � � � � � � 11

5 Alternate Setup Method � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 25

6 Using the Web-Based Advanced User Interface � � � � � � � � � � � �43

Changing LAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Viewing the DHCP Client List Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Configuring the Wireless Network Settings . . . . . . . . . . . . . . . . . . . . . . 46

G Wireless Router

SECTIONSTable of Contents 23456789101

INTRODUCTION

Thank you for purchasing the Belkin G Wireless Router (the Router). The following two short sections discuss the benefits of home

networking and outline best practices for maximizing your wireless home network range and performance. Please be sure to

read through this User Manual completely, and pay special attention to the section entitled “Placement of your Router for Optimal

Performance” on page 2.

Advantages of a Wireless Network

• Mobility – you’ll no longer need a dedicated “computer room”—now

you can work on a networked laptop or desktop computer anywhere

within your wireless range

• Easy installation – The Belkin Setup Assistant software makes setup

simple

• Flexibility – set up and access printers, computers, and other

networking devices from anywhere in your home

• Easy Expansion – the wide range of Belkin networking products lets

you expand your network to include devices such as printers and

gaming consoles

• No cabling required – you can spare the expense and hassle of

retrofitting Ethernet cabling throughout the home or office

• Widespread industry acceptance – choose from a wide range of

interoperable networking products

• Share one high-speed Internet connection with all the computers in

your home

• Share resources, such as files and hard drives among all the

connected computers in your home

• Share a single printer with the entire family

• Share documents, music, video, and digital pictures

• Store, retrieve, and copy files from one computer to another

• Simultaneously play games online, check Internet email, and chat

Benefits of a Home Network

G Wireless Router

SECTIONSTable of Contents 23456789101

INTRODUCTION

1� Wireless Router Placement

Place your Router, the central connection point of your network, as close

as possible to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless clients”

(i.e., computers enabled by Belkin Wireless Notebook Network Cards,

Wireless Desktop Network Cards, and Wireless USB Adapters):

• Ensure that your Router’s networking antennas are parallel to each

other, and are positioned vertically (toward the ceiling). If your Router

itself is positioned vertically, point the antennas as much as possible

in an upward direction.

• In multistory homes, place the Router on a floor that is as close

to the center of the home as possible. This may mean placing the

Router on an upper floor.

• Try not to place the Router near a cordless phone.

Important Factors for Placement and Setup

Your wireless connection will be stronger the closer your computer is

to your Router. Typical indoor operating range for wireless devices is

between 100 and 200 feet.

In the same way, your wireless connection and performance will degrade

somewhat as the distance between your Router and connected devices

increases. This may or may not be noticeable to you. As you move farther

from your Router, connection speed may decrease. Factors that can

weaken signals simply by getting in the way of your network’s radio waves

are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might be

related to range or obstruction factors, try moving the computer to a

position between five and 10 feet away from the Router in order to see if

distance is the problem. If difficulties persist even at close range, please

contact Belkin Technical Support.

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from functioning;

if you are concerned that your network is not operating at its maximum

effectiveness, this checklist may help.

Placement of your Router for Optimal Performance

G Wireless Router

SECTIONSTable of Contents 23456789101

INTRODUCTION

3� Cordless Phones

If the performance of your wireless network is impaired after attending to

the above issues, and you have a cordless phone:

• Try moving cordless phones away from the Router and your

wireless-enabled computers.

• Unplug and remove the battery from any cordless phone

that operates on the 2.4GHz band (check the manufacturer’s

information). If this fixes the problem, your phone may be interfering.

• If your phone supports channel selection, change the channel on

the phone to the farthest channel from your wireless network. For

example, change the phone to channel 1 and move your Router to

channel 11. See your phone’s user manual for detailed instructions.

• If necessary, consider switching to a 900MHz cordless phone.

2� Avoid Obstacles and Interference

Avoid placing your Router near devices that may emit radio “noise,”

such as microwave ovens. Dense objects that can inhibit wireless

communication include:

• Refrigerators

• Washers and/or dryers

• Metal cabinets

• Large aquariums

• Metallic-based, UV-tinted windows

If your wireless signal seems weak in some spots, make sure that objects

such as these are not blocking the signal’s path (between your computers

and Router).

G Wireless Router

SECTIONSTable of Contents 23456789101

INTRODUCTION

4. Choose the “Quietest” Channel for your Wireless Network

In locations where homes or offices are close together, such as apartment

buildings or office complexes, there may be wireless networks nearby that

can conflict with yours.

Use the Site Survey capabilities found in the wireless utility of your

wireless adapter or card to locate any other wireless networks that are

available (see your wireless adapter’s or card’s user manual), and move

your Router and computers to a channel as far away from other networks

as possible.

• Experiment with more than one of the available channels in order to

find the clearest connection and avoid interference from neighboring

cordless phones or other wireless devices.

• For Belkin wireless networking products, use the detailed Site

Survey and wireless channel information included with your Wireless

Network Card or Adapter. See your Network Card’s user guide for

more information.

These guidelines should allow you to cover the maximum possible area

with your Router. Should you need to cover an even wider area, we

suggest the Belkin Wireless G Universal Range Extender/Access Point.

5� Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and are

used where security is important. Secure connections include:

• Virtual Private Network (VPN) connections, often used to connect

remotely to an office network

• The “Bring Your Own Access” program from America Online (AOL),

which lets you use AOL through broadband provided by another

cable or DSL service

• Most online banking websites

• Many commercial websites that require a user name and password

to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The easiest solution

to avoid this is to simply reconnect by rerunning the VPN or AOL software,

or by re-logging into the secure website.

A second alternative is to change your computer’s power management

settings so it does not go to sleep; however, this may not be appropriate

for portable computers. To change your power management setting under

Windows, see the “Power Options” item in the Control Panel.

If you continue to have difficulty with secure connections, VPNs, and

AOL, please review the steps above to be sure you have addressed these

issues.

For more information regarding our networking products, visit our website

at www.belkin.com/networking.

G Wireless Router

SECTIONSTable of Contents 1 345678910

PRODUCT OVERVIEW

In minutes you will be able to share your Internet connection and network

your computers. The following is a list of features that make your new

Belkin G Wireless Router an ideal solution for your home or small office

network.

Works with Both PCs and Mac®Computers

The Router supports a variety of networking environments including Mac

OS®, 9.x, X v10.x, AppleTalk®, Linux®, Windows®98, Me, NT®, 2000, XP,

Vista®, and others. All that is needed is an Internet browser and a network

adapter that supports TCP/IP (the standard language of the Internet).

Front-Panel LED Display

Lighted LEDs on the front of the Router indicate which functions are in

operation. You’ll know at-a-glance whether your Router is connected to

the Internet. This feature eliminates the need for advanced software and

status-monitoring procedures.

Web-Based Advanced User Interface

You can set up the Router’s advanced functions easily through your web

browser, without having to install additional software onto the computer.

There are no disks to install or keep track of and, best of all, you can make

changes and perform setup functions from any computer on the network

quickly and easily.

Product Features

NAT IP Address Sharing

Your Router employs Network Address Translation (NAT) to share the

single IP address assigned to you by your Internet Service Provider while

saving the cost of adding IP addresses to your Internet service account.

SPI Firewall

Your Router is equipped with a firewall that will protect your network from a

wide array of common hacker attacks including IP Spoofing, Land Attack,

Ping of Death (PoD), Denial of Service (DoS), IP with zero length, Smurf

Attack, TCP Null Scan, SYN flood, UDP flooding, Tear Drop Attack, ICMP

defect, RIP defect, and fragment flooding.

Integrated 10/100 4-Port Switch

The Router has a built-in, 4-port network switch to allow your wired

computers to share printers, data and MP3 files, digital photos, and much

more. The switch features automatic detection so it will adjust to the speed

of connected devices. The switch will transfer data between computers

and the Internet simultaneously without interrupting or consuming

resources.

Universal Plug-and-Play (UPnP) Compatibility

UPnP (Universal Plug-and-Play) is a technology that offers seamless

operation of voice messaging, video messaging, games, and other

applications that are UPnP-compliant.

G Wireless Router

SECTIONSTable of Contents 1 3456789102

PRODUCT OVERVIEW

Support for VPN Pass-Through

If you connect to your office network from home using a VPN connection,

your Router will allow your VPN-equipped computer to pass through the

Router and to your office network.

Built-In Dynamic Host Configuration Protocol (DHCP)

Built-In Dynamic Host Configuration Protocol (DHCP) on-board makes

for the easiest possible connection of a network. The DHCP server will

assign IP addresses to each computer automatically so there is no need

for a complicated networking setup.

Setup Assistant

The Setup Assistant takes the guesswork out of setting up your Router.

This automatic software determines your network settings for you and

sets up the Router for connection to your Internet Service Provider (ISP).

In a matter of minutes, your Wireless Router will be up and running on the

Internet.

NOTE: Setup Assistant software is compatible with Windows 2000, XP,

Vista, and Mac OS X v10.4 and v10.5. If you are using another operating

system, the Wireless Router can be set up using the Alternate Setup

Method described in this User Manual (see page 25).

Integrated 802�11g Wireless Access Point

802.11g is an exciting new wireless technology that achieves data rates up

to 54Mbps, nearly five times faster than 802.11b.

MAC Address Filtering

For added security, you can set up a list of MAC addresses (unique client

identifiers) that are allowed access to your network. Every computer has

its own MAC address. Simply enter these MAC addresses into a list using

the Web-Based Advanced User Interface and you can control access to

your network.

G Wireless Router

SECTIONSTable of Contents 12 45678910

KNOWING YOUR ROUTER

Package Contents

• Belkin G Wireless Router

• Quick Installation Guide

• Belkin Setup Assistant CD with User Manual

• Belkin RJ45 Ethernet Networking Cable

• Power Supply

System Requirements

• Broadband Internet connection such as a cable or DSL modem with

RJ45 (Ethernet) connection

• At least one computer with an installed network interface adapter

• TCP/IP networking protocol installed on each computer

• RJ45 Ethernet networking cable

• Internet browser

Setup Assistant Software System Requirements

• A PC running Windows 2000, XP, or Vista, or a Mac computer

running Mac OS X v10.4 or v10.5

• Minimum 512MB RAM

• Internet browser

The Router has been designed to be placed on a desktop. All of the

cables exit from the rear of the Router for better organization and utility.

The LED indicators are easily visible on the front of the Router to provide

you with information about network activity and status.

G Wireless Router

SECTIONSTable of Contents 12 45678910

KNOWING YOUR ROUTER

(6)

(1)

(2)

(3)

(4)

(5)

1. Modem LED

2. Power LED

3. Security LED

4. Wireless LED

5. Internet LED

6. Wired LEDs (1 – 2 – 3 – 4)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Belkin

Belkin

Belkin VISION N1 Manual de usuario

Belkin

Belkin F7D4401 Manual de usuario

Belkin

Belkin INVENTEL CONFIG XP Instrucciones de montaje

Belkin

Belkin Surf F7D2301 Manual de usuario

Belkin

Belkin Share Manual de usuario

Belkin

Belkin TSG-UK-1-001 Guía de referencia

Belkin

Belkin F5D7233 - Wireless G Travel Router Manual de usuario

Belkin

Belkin F5D5230-F Manual de usuario

Belkin

Belkin SURF N300 Manual de usuario

Belkin

Belkin F9K1117V2 Manual de usuario

Belkin

Belkin F9K1007V1 Manual de usuario

Belkin

Belkin GO N300 DB Manual de usuario

Belkin

Belkin WIRELESSBRIDGE GERMAN Guía de inicio rápido

Belkin

Belkin High Speed ADSL2+ Manual de usuario

Belkin

Belkin 802.11g Wireless Ethernet Bridge Manual de usuario

Belkin

Belkin F5D8232-4 Manual de usuario

Belkin

Belkin F5D5230U4-V1.20.003 Manual de instrucciones

Belkin

Belkin Wireless G Router Manual de usuario

Belkin

Belkin F5D5230-4 Instrucciones de instalación y mantenimiento

Belkin

Belkin Home Base F5L049ea Manual de usuario

Belkin

Belkin F9K1002V1 Manual de usuario

Belkin

Belkin N Wireless Manual de usuario

Belkin

Belkin Surf Manual de usuario

Belkin

Belkin F7D1301 V1 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
