Belkin Wireless G Router Manual de usuario

F5D7000

Wireless G Desktop

Network Card

Connect your desktop computer to a

FAST wireless network

EN Manuals and/or Software are available in your local language:

FR Les manuels et/ou le logiciel sont disponibles en français :

DE Benutzerhandbuch und/oder Software gibt es in Ihrer Sprache:

NL Voor Nederlandstalige handleidingen en/of software kunt u terecht op:

ES Los manuales y/o el software están disponibles en la lengua local:

IT I manuali e/o il software nella propria lingua si trovano su:

www.belkin.co.uk/support

User Manual

2.4GHz • Wireless

802.11b

Ethernet

Wired

Mbps

10/100

Ethernet

Gigabit

Wired

Mbps

10/100/1000

Gigabit Ethernet

Mbps

2.4GHz • Wireless802.11g

Mbps

1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Advantages of a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . 1

Placement of your Wireless Networking Hardware for

Optimal Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Applications and Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Installing and Setting Up the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Step 1: Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Step 2: Install the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4 Using the Belkin Wireless Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

How to Access the Belkin Wireless Utility . . . . . . . . . . . . . . . . . . 12

Monitoring the Status of your Network Connection. . . . . . . . . . . 12

Configuring your Current Network Settings . . . . . . . . . . . . . . . . . 14

Securing your Wi-Fi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Finding Available Networks in your Area . . . . . . . . . . . . . . . . . . . 28

Setting Wireless Network Profiles. . . . . . . . . . . . . . . . . . . . . . . . . 29

Monitoring Data Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Table of Contents

Thank you for purchasing the Belkin Wireless G Desktop Network

Card (the Card). The Card features 802.11g technology, allowing you

to take advantage of wireless networking without using cables. The

Card works like a conventional network card, but without the wires.

The easy installation and setup will have you networking in minutes.

Please be sure to read through this User Manual completely, and pay

special attention to the section entitled “Placement of your Wireless

Networking Hardware for Optimal Performance”.

Advantages of a Wireless Network

• Mobility – you no longer need a dedicated “computer

room”—you can work on a networked laptop or desktop

computer anywhere within your wireless range

• Easy installation – Belkin Easy Installation Wizards make

setup simple

• Flexibility – set up and access printers, computers, and other

networking devices from anywhere in your home

• Easy Expansion – the wide range of Belkin networking products

let you expand your network to include devices such as printers

and gaming consoles

• No cabling required – you can spare the expense and hassle of

retrofitting Ethernet cabling throughout the home or office

• Widespread industry acceptance – choose from a wide range

of interoperable networking products

Introduction

section

Introduction

Placement of your Wireless Networking Hardware for

Optimal Performance

Your wireless connection will be stronger the closer your computer

is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the

same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access

point) and connected devices increases. This may or may not be

noticeable to you. As you move further from your wireless router (or

access point), connection speed may decrease. Factors that can

weaken signals simply by getting in the way of your network’s radio

waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might be

related to range or obstruction factors, try moving the computer to a

position between five and 10 feet from the wireless router (or access

point) in order to see if distance is the problem. If difficulties persist

even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating

at its maximum effectiveness, this checklist may help.

1. Placement of your Wireless Router or Access Point

Place your wireless router (or access point), the central connection

point of your network, as close as possible to the center of your

wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e. computers enabled by Belkin Wireless Notebook

Network Cards, Wireless Desktop Network Cards, and Wireless

USB Adapters):

• Ensure that your wireless router’s (or access point’s) antennas

are parallel to each other, and are positioned vertically (toward

the ceiling). If your wireless router (or access point) itself is

positioned vertically, point the antennas as much as possible in

an upward direction.

• In multistory homes, place the wireless router (or access point) on a

floor that is as close to the center of the home as possible. This may

mean placing the wireless router (or access point) on an upper floor.

• Try not to place the wireless router (or access point) near a

cordless 2.4GHz phone.

Introduction

section

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices that

may emit radio “noise”, such as microwave ovens. Other objects that

can inhibit wireless communication can include:

• Refrigerators

• Washers and/or dryers

• Metal cabinets

• Large aquariums

• Metallic-based UV tinted windows

If your wireless signal seems weak in some spots, make sure that

objects such as these are not blocking the signal’s path between your

computers and wireless router (or access point).

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have your cordless phone:

• Try moving cordless phones away from the wireless router

(or access point) and your wireless-enabled computers.

• Unplug and remove the battery from any cordless phone

that operates on the 2.4GHz band (check the manufacturer’s

information). If this fixes the problem, the phone may

be interfering.

• If your phone supports channel selection, change the

channel on the phone to the furthest channel from your

wireless network as possible. For example, change the

phone to channel 1 and move your wireless router (or

access point) to channel 11. See your phone’s user manual

for detailed instructions.

• If necessary, consider switching to a 900MHz or 5GHz

cordless phone.

4. Choose the “Quietest” Channel for your Wireless Network

In locations where homes or offices are close together, such as

apartment buildings or office complexes, there may be wireless

networks nearby that can conflict with yours. Use the Site Survey

capabilities of your Wireless Utility to locate any other wireless

networks, and move your wireless router (or access point) and

computers to a channel as far away from other networks as possible.

Experiment with more than one of the available channels in order to

find the clearest connection and avoid interference from neighboring

cordless phones or other wireless devices.

Use the detailed information in the “Finding Available Networks in

your Area” section in this User Manual.

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

• Virtual Private Network (VPN) connections, often used to connect

remotely to an office network

• The “Bring Your Own Access” program from America Online

(AOL), which lets you use AOL through broadband provided by

another cable or DSL service

• Most online banking websites

• Many commercial websites that require a user name and

password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the VPN or

AOL software, or by re-logging into the secure website.

A second alternative is to change your computer’s power management

settings so it does not go to sleep; however, this may not be appropriate

for portable computers. To change your power management setting in

Windows, see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections, VPNs, and

AOL, please review steps 1-4 in the previous pages to be sure you

have addressed these issues.

These guidelines should allow you to cover the maximum possible area

with your wireless router. Should you need to cover an even wider

area, we suggest the Belkin Wireless Range Extender/Access Point.

For more information regarding our networking products, visit our

website at www.belkin.com/networking or call Belkin Technical Support.

Introduction

section

Introduction

Product Features

The Card complies with the IEEE 802.11g standard in order to

communicate with other 802.11g-compliant wireless devices at

54Mbps. The Card is compatible with all 802.11g devices as well as

other 802.11b products at 11Mbps. 802.11g products operate on the

same 2.4GHz frequency band as 802.11b Wi-Fi® products.

• 2.4GHz ISM (Industrial, Science, and Medical) band operation

• Integrated easy-to-use Wireless Utility

• PCI interface, for operation in virtually any desktop computer

• WPA, 64-bit WEP (Wired Equivalent Privacy), or 128-bit encryption

• Wireless access to networked resources

• Support for both Infrastructure and Ad-Hoc (peer-to-peer)

networking modes

• Easy installation and use

• External antenna

• Network link and activity link LED indicators

Overview

Applications and Advantages

• Wireless roaming with a desktop computer around the

home or office

Offers the freedom of networking—without cables

• Compatibility with 802.11b products

Provides seamless interoperability with existing Wi-Fi (IEEE

802.11b) products and with other products that display the

Wi-Fi mark

• Difficult-to-wire environments

Enables networking in buildings with solid or finished walls, or

open areas where wiring is difficult to install

• Frequently changing environments

Adapts easily in offices or environments that frequently rearrange

or change locations

• Temporary LANs for special projects or peak time

Sets up temporary networks (such as at trade shows, exhibitions,

and construction sites) on a short-term basis; also companies

that need additional workstations for a peak activity period

• SOHO (Small Office/Home Office) networking needs

Enables easy and quick small-network installation, a huge benefit to

SOHO users

Product Specifications

Host Interface 32-bit PCI

Power Consumption Tx/Rx peak 420/260mA @ 5VDC (max.)

Operating Temperature 32—185 degrees F (0—85 degrees C)

Storage Temperature -40—194 degrees F (-40—90 degrees C)

Humidity (Max. 95% (non-condensing)

Typical Operating Range 100 to 200 ft. (30 to 60m)

Overview

section

Overview

(a) Link LED

Lights up when the Card links to a wireless network

(b) Activity LED

Lights up and flashes when the Card is active

Fits securely into your computer’s PCI slot

System Requirements

• PC-compatible desktop computer with one available PCI slot

• Windows® 98SE, Me, 2000, XP

Package Contents

• Wireless G Desktop Network Card

• Quick Installation Guide

• Installation Software CD

• User Manual

(c)

(b) (a)

Step 1 Install the Software

Important note: INSTALL THE SOFTWARE BEFORE INSERTING THE CARD.

1.1 Insert the Installation Software CD into your CD-ROM drive.

1.2 The Belkin Setup Utility screen will automatically appear (may take

15–20 seconds to appear). Click “Install” from the setup menu, then

click “Click here” to start the Easy Install Wizard.

Note: If the Setup Utility screen does not appear within 20 seconds,

access your CD-ROM by double-clicking on the “My Computer”

icon and double-click on the CD-ROM drive that the installation CD

has been placed in. Double-click on the folder named “Files”, then

double-click on the icon named “setup.exe”.

Installing and Setting Up the Card

1.3 Click “Next” to install the software.

Otros manuales para Wireless G Router

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tarjeta de red de Belkin

Belkin

Belkin F5D8013 v3 Manual de usuario

Belkin

Belkin F5D5010 Manual de usuario

Belkin

Belkin F5D76314 Manual de usuario

Belkin

Belkin F5D8013v4 Manual de usuario

Belkin

Belkin F5D6001 Manual de usuario

Belkin

Belkin F8T006-PC Manual de usuario

Belkin

Belkin F5D6020 Manual de usuario

Belkin

Belkin F5D7010v7 Manual de usuario

Belkin

Belkin F5D7010 Manual de usuario

Belkin

Belkin F6D301 Manual de usuario

Belkin

Belkin DESKTOP CARD F5D7001 Manual de usuario

Belkin

Belkin F5D6050 Manual de usuario

Belkin

Belkin F5D7000H Manual de usuario

Belkin

Belkin F5D7000 Manual de usuario

Belkin

Belkin PM00730EA Manual de usuario

Belkin

Belkin F5D8055 Manual de usuario

Belkin

Belkin F5D6050 Manual de usuario

Belkin

Belkin F5D6001 Manual de usuario

Belkin

Belkin Wireless G Router Manual de usuario

Belkin

Belkin F5D6060 Manual de usuario

Belkin

Belkin VISION N1 Manual de usuario

Belkin

Belkin F6D3010 Manual de usuario

Belkin

Belkin F5U008-MAC Manual de usuario

Belkin

Belkin F5D9010uk Manual de usuario

Manuales populares de Tarjeta de red de otras marcas

FirstComm

FirstComm OBiWiFi5G Manual de usuario

Sun Microsystems

Sun Microsystems Interface Adapter Manual de usuario

TRENDnet

TRENDnet TU2-ETG Manual de usuario

YASKAWA

YASKAWA SI-EN3 Manual de usuario

Paradyne

Paradyne BitStorm 2600 IP DSLAM Manual de usuario

3Com

3Com EtherLink 3C509B Manual de usuario

TRENDnet

TRENDnet TEG-PCITX Manual de usuario

Cisco

Cisco MC16E Manual de usuario

Delta Electronics

Delta Electronics Braking Modules VFDB Series Manual de usuario

TwinMOS

TwinMOS Booming Manual de usuario

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Manual de usuario

Buffalo

Buffalo AirStation WLI-PCM-L11GP Manual de usuario

National Instruments

National Instruments NI 9234 Manual de usuario

Hama

Hama 49276 Manual de usuario

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Manual de operación

Compaq

Compaq Wireless LAN 100 Manual de usuario

Bose

Bose PowerMatch Dante Manual de usuario

TRENDnet

TRENDnet TEG-PCITXR Manual de usuario
