Belkin F9L1101 Manual de usuario

User Manual

F9L1101V2 8820-00785 Rev. B00

DUAL-BAND Wi-Fi®USB ADAPTER

N450 DB/N600 DB

TABLE OF CONTENTS

Introduction .............................................. 1

Benefits of a Home Network....................................1

Advantages of a Wireless Network ..............................2

Placement of your Wireless Networking Hardware for Optimal

Performance.................................................3

Overview................................................. 7

Product Features ............................................7

Applications and Advantages...................................8

Product Specifications ........................................9

System Requirements........................................10

Package Contents ...........................................10

Installing and Setting up the Adapter....................... 11

A. Installation Process for Windows Vista and 7 ..................11

B. Installation Process for Windows XP .........................18

Connecting to a Secure Wi-Fi®Network.........................24

Troubleshooting ......................................... 25

Information.............................................. 32

Thank you for purchasing the Belkin N450 DB/N600 DB Dual-Band Wi-Fi USB Adapter. Now you can take advantage of this

great new technology and gain the freedom to network your home and office computers wirelessly. This Adapter allows you to

connect a notebook or desktop computer to your network. Please be sure to read through this User Manual completely, and

pay special attention to the section titled, “Placement of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

 •Shareonehigh-speedInternetconnectionwithallthecomputersinyourhome

 •Shareresources,suchasfiles,andharddrivesamongalltheconnectedcomputersinyourhome

 •Shareasingleprinterwiththeentirefamily

 •Sharedocuments,music,video,anddigitalpictures

 •Store,retrieve,andcopyfilesfromonecomputertoanother

 •Simultaneouslyplaygamesonline,checkInternetemail,andchat

INTRODUCTION

Advantages of a Wireless Network

 •Mobility–you’llnolongerneedadedicated“computerroom”—nowyoucanworkona

networked laptop or desktop computer anywhere within your wireless range

 •Easyinstallation–BelkinEasyInstallationWizardsmakesetupsimple

 •Flexibility–setupandaccessprinters,computers,andothernetworkingdevicesfromanywhereinyourhome

 •Easyexpansion–thewiderangeofBelkinnetworkingproductsletyouexpandyour

network to include devices such as printers and gaming consoles

 •Nocablingrequired–youcansparetheexpenseandhassleofretrofittingEthernetcablingthroughoutthehomeoroffice

 •Widespreadindustryacceptance–choosefromawiderangeofinteroperablenetworkingproducts

INTRODUCTION

Placement of your Wireless Networking Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access point) and connected devices increases. This may or may not

be noticeable to you. As you move farther from your wireless router (or access point), connection speed may decrease. Factors that

canweakensignalssimplybygettinginthewayofyournetwork’sradiowavesaremetalappliancesorobstructions,andwalls.

Ifyouhaveconcernsaboutyournetwork’sperformancethatmightberelatedtorangeorobstructionfactors,try

moving the computer to a position between five and 10 feet from the wireless router (or access point) in order to see if

distance is the problem. If difficulties persist even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network performance, they will not prohibit your wireless network from

functioning;ifyouareconcernedthatyournetworkisnotoperatingatitsmaximumeffectiveness,thischecklistmayhelp.

INTRODUCTION

1. Placement of your Wireless Router (or Access Point)

Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

 •Ensurethatyourwirelessrouter’s(oraccesspoint’s)

antennas are parallel to each other, and are positioned

vertically (toward the ceiling). If your wireless router (or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

 •Inmultistoryhomes,placethewirelessrouter(or

access point) on a floor that is as close to the center

of the home as possible. This may mean placing the

wireless router (or access point) on an upper floor.

 •Trynottoplacethewirelessrouter(oraccess

point)nearacordless2.4GHzphone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:

 •Refrigerators

 •Washersand/ordryers

 •Metalcabinets

 •Largeaquariums

 •Metallic-based,UV-tintedwindows

 •Microwaves

If your wireless signal seems weak in some spots, make sure

thatobjectssuchasthesearenotblockingthesignal’spath

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have a cordless phone:

 •Trymovingcordlessphonesawayfromthewirelessrouter

(or access point) and your wireless-enabled computers.

 •Unplugandremovethebatteryfromanycordlessphonethat

operatesonthe2.4GHzband(checkmanufacturer’sinformation).

Ifthisfixestheproblem,yourphonemaybeinterfering.

 •Ifyourphonesupportschannelselection,changethechannel

on the phone to the farthest channel from your wireless network

aspossible.Forexample,changethephonetochannel1and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

Seeyourphone’susermanualfordetailedinstructions.

 •Ifnecessary,considerswitchingtoa

900MHzor5GHzcordlessphone.

4. Choose the “Quietest” Channel for your Wireless Network

In locations where homes or offices are close together, such

asapartmentbuildingsorofficecomplexes,theremaybe

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experimentwithmorethanoneoftheavailablechannelsin

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

 •VirtualPrivateNetwork(VPN)connections,often

used to connect remotely to an office network

 •The“BringYourOwnAccess”programfromAmerica

Online (AOL), which lets you use AOL through broadband

provided by another cable or DSL service

 •Mostonlinebankingwebsites

 •Manycommercialwebsitesthatrequireauser

name and password to access your account

Secureconnectionscanbeinterruptedbyacomputer’spower

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPN or AOL software, or by re-logging into the secure website.

Asecondalternativeistochangeyourcomputer’spower

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections,

VPNs,andAOL,pleasereviewsteps1–4intheprevious

pages to be sure you have addressed these issues.

Theseguidelinesshouldallowyoutocoverthemaximumpossible

area with your wireless router. Should you need to cover an even wider

area,wesuggesttheBelkinWirelessRangeExtender/AccessPoint.

For more information regarding our networking

products, visit our website at www.belkin.com/

networking or call Belkin Technical Support.

Product Features

TheAdaptercomplieswiththeIEEE802.11nspecificationto

communicate with other 802.11n-compliant wireless devices at up to

300Mbps*. The Adapter is also compatible with 802.11a/g devices

at 54Mbps as well as 802.11b products at 11Mbps. The Adapter can

operateonthesame2.4GHzfrequencybandas802.11b/gWi-Fi®

productsor5GHzfrequencybandas802.11aWi-Fiproducts.

 •2.4GHzor5GHzbandoperation

 •USB2.0interface,foroperationinvirtuallyany

computer with a USB 2.0 bus-power port

 •WPA,WPA2,64-bitWEP(WiredEquivalent

Privacy),or128-bitWEPencryption

 •Wirelessaccesstonetworkedresources

 •Datarateofupto300Mbps*(802.11n),54Mbps

(802.11a/g), or 11Mbps (802.11b)

 •Easyinstallationanduse

 •LEDpowerandnetworklink/activityindicator

OVERVIEW

Applications and Advantages

 •Wirelessroamingwithalaptoparoundthehomeoroffice

Offers the freedom of networking without cables

 •Connectionratesofupto300Mbps*

Provides immediate high-speed wireless connectivity

at home, work, and hotspot locations without

compromisingtheuseofexisting802.11b/gproducts

 •Compatibilitywith802.11a/b/gproducts

TheAdapterisbackward-compatiblewithexisting

Wi-Fi(IEEE802.11a/b/g)products

 •Difficult-to-wireenvironments

Enablesnetworkinginbuildingswithsolidorfinished

walls, or open areas where wiring is difficult to install

 •Frequentlychangingenvironments

Adapts easily in offices or environments that

frequently rearrange or change locations

 •SOHO(SmallOffice/HomeOffice)networkingneeds

Provides the easy and quick, small network

installation SOHO users need
