Belkin USB Wireless Adapter Manual de usuario

Play USB WIRELESS ADAPTER

User Manual

8820ed00386_F7D4101_v1

English

Français

DEutsch

nEDErlanDs

Table Of Contents

Introduction ...............................................1

Benefits of a Home Network.................................... 1

Advantages of a Wireless Network .............................. 2

Placement of your Wireless Networking Hardware for Optimal

Performance................................................. 3

Overview..................................................7

Product Features ............................................ 7

Applications and Advantages .................................. 8

Product Specifications ........................................ 9

System Requirements........................................ 11

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Installing and Setting up the Adapter........................12

A. Installation Process for Windows Vista and 7 .................. 12

B. Installation Process for Windows XP .........................20

Connecting to a Secure Wi-Fi®Network ........................ 27

Troubleshooting ......................................... 28

Information.............................................. 35

FCC Statement.............................................. 35

Belkin International, Inc., Limited 2-Year Product Warranty .........38

INTRODUCTION

Thank you for purchasing the Belkin Play Wireless USB Adapter.

Now you can take advantage of this great new technology and gain

the freedom to network your home and office computers wirelessly.

This Adapter allows you to connect a notebook or desktop computer

to your network. Please be sure to read through this User Manual

completely, and pay special attention to the section titled, “Placement

of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

 

with all the computers in your home

 

all the connected computers in your home

 

 

 

 

INTRODUCTION

Advantages of a Wireless Network

 you’ll no longer need a dedicated “computer

room”—now you can work on a networked laptop or

desktop computer anywhere within your wireless range

  Belkin Easy Installation

Wizards make setup simple

 set up and access printers, computers, and

other networking devices from anywhere in your home

  the wide range of Belkin networking

products let you expand your network to include

devices such as printers and gaming consoles

 you can spare the expense and hassle

of retrofitting Ethernet cabling throughout the home or office

  choose from a

wide range of interoperable networking products

INTRODUCTION



Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer

is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the

same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access

point) and connected devices increases. This may or may not be

noticeable to you. As you move farther from your wireless router

(or access point), connection speed may decrease. Factors that

can weaken signals simply by getting in the way of your network’s

radio waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might

be related to range or obstruction factors, try moving the computer

to a position between five and 10 feet from the wireless router (or

access point) in order to see if distance is the problem. If difficulties

persist even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating

at its maximum effectiveness, this checklist may help.

INTRODUCTION



Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

 

antennas are parallel to each other, and are positioned

vertically (toward the ceiling). If your wireless router (or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

 

floor that is as close to the center of the home as possible. This may

mean placing the wireless router (or access point) on an upper floor.

 

point) near a cordless 2.4GHz phone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:













If your wireless signal seems weak in some spots, make sure

that objects such as these are not blocking the signal’s path

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have a cordless phone:

 

(or access point) and your wireless-enabled computers.

 

operates on the 2.4GHz band (check manufacturer’s information).

If this fixes the problem, your phone may be interfering.

 

on the phone to the farthest channel from your wireless network

as possible. For example, change the phone to channel 1 and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

See your phone’s user manual for detailed instructions.

 

900MHz or 5GHz cordless phone.



In locations where homes or offices are close together, such

as apartment buildings or office complexes, there may be

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experiment with more than one of the available channels in

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

 

used to connect remotely to an office network

 

Online (AOL), which lets you use AOL through broadband

provided by another cable or DSL service

 

 

name and password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPN or AOL software, or by re-logging into the secure website.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections,

VPNs, and AOL, please review steps 1–4 in the previous

pages to be sure you have addressed these issues.

These guidelines should allow you to cover the maximum possible

area with your wireless router. Should you need to cover an even wider



For more information regarding our networking products,

visit our website at 

or call Belkin Technical Support.





The Adapter complies with the IEEE 802.11n specification

to communicate with other 802.11n-compliant

wireless devices at up to 300Mbps*.



at 54Mbps as well as 802.11b products at 11Mbps.

The Adapter can operate on the same 2.4GHz

®products or 5GHz

frequency band as 802.11a Wi-Fi products.

 

 

computer with a USB 2.0 bus-power port

 

Privacy), or 128-bit WEP encryption

 

 



 

 

 



Applications and Advantages

 Wireless roaming with a laptop around the home or

 Offers the freedom of networking without cables

 Provides

immediate high-speed wireless connectivity at home,

work, and hotspot locations without compromising



 The Adapter is



  Enables networking

in buildings with solid or finished walls, or open

areas where wiring is difficult to install

 Adapts easily in offices

or environments that frequently rearrange or change locations

 Provides

the easy and quick, small network installation SOHO users need
