Belkin BASIC F7D1101AK Manual de usuario

User Manual

F7D1101ak 8820ak00382

Basic

WIRELESS USB ADAPTER

TABLE OF CONTENTS

Introduction ...............................................1

Benefits of a Home Network.................................... 1

Advantages of a Wireless Network .............................. 2

Placement of your Wireless Networking Hardware for Optimal

Performance................................................. 3

Overview..................................................7

Product Features ............................................ 7

Applications and Advantages .................................. 8

Product Specifications ........................................ 9

System Requirements ........................................ 11

Package Contents ........................................... 11

Installing and Setting up the Adapter........................12

A. Installation Process for Windows Vista and 7 .................. 12

B. Installation Process for Windows XP .........................20

Connecting to a Secure Wi-Fi®Network ........................ 24

Troubleshooting ......................................... 25

Technical Support ........................................... 31

Information.............................................. 32

FCC Statement.............................................. 32

Belkin International, Inc., Limited 3-Year Product Warranty.........34

INTRODUCTION

Thank you for purchasing the Belkin Basic Wireless USB Adapter.

Now you can take advantage of this great new technology and gain

the freedom to network your home and office computers wirelessly.

This Adapter allows you to connect a notebook or desktop computer

to your network. Please be sure to read through this User Manual

completely, and pay special attention to the section titled, “Placement

of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

• Share one high-speed Internet connection

with all the computers in your home

• Share resources, such as files, and hard drives among

all the connected computers in your home

• Share a single printer with the entire family

• Share documents, music, video, and digital pictures

• Store, retrieve, and copy files from one computer to another

• Simultaneously play games online, check Internet email, and chat

INTRODUCTION

Advantages of a Wireless Network

• Mobility – you’ll no longer need a dedicated “computer

room”—now you can work on a networked laptop or

desktop computer anywhere within your wireless range

• Easy installation – Belkin Easy Installation

Wizards make setup simple

• Flexibility – set up and access printers, computers, and

other networking devices from anywhere in your home

• Easy expansion – the wide range of Belkin networking

products let you expand your network to include

devices such as printers and gaming consoles

• No cabling required – you can spare the expense and hassle

of retrofitting Ethernet cabling throughout the home or office

• Widespread industry acceptance – choose from a

wide range of interoperable networking products

INTRODUCTION

Placement of your Wireless Networking

Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer

is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the

same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access

point) and connected devices increases. This may or may not be

noticeable to you. As you move farther from your wireless router

(or access point), connection speed may decrease. Factors that

can weaken signals simply by getting in the way of your network’s

radio waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might

be related to range or obstruction factors, try moving the computer

to a position between five and 10 feet from the wireless router (or

access point) in order to see if distance is the problem. If difficulties

persist even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating

at its maximum effectiveness, this checklist may help.

INTRODUCTION

1. Placement of your Wireless Router (or Access Point)

Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

• Ensure that your wireless router’s (or access point’s)

antennas are parallel to each other, and are positioned

vertically (toward the ceiling). If your wireless router (or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

• In multistory homes, place the wireless router (or access point) on a

floor that is as close to the center of the home as possible. This may

mean placing the wireless router (or access point) on an upper floor.

• Try not to place the wireless router (or access

point) near a cordless 2.4GHz phone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:

• Refrigerators

• Washers and/or dryers

• Metal cabinets

• Large aquariums

• Metallic-based, UV-tinted windows

• Microwaves

If your wireless signal seems weak in some spots, make sure

that objects such as these are not blocking the signal’s path

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have a cordless phone:

• Try moving cordless phones away from the wireless router

(or access point) and your wireless-enabled computers.

• Unplug and remove the battery from any cordless phone that

operates on the 2.4GHz band (check manufacturer’s information).

If this fixes the problem, your phone may be interfering.

• If your phone supports channel selection, change the channel

on the phone to the farthest channel from your wireless network

as possible. For example, change the phone to channel 1 and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

See your phone’s user manual for detailed instructions.

• If necessary, consider switching to a

900MHz or 5GHz cordless phone.

4. Choose the “Quietest” Channel for your Wireless Network

In locations where homes or offices are close together, such

as apartment buildings or office complexes, there may be

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experiment with more than one of the available channels in

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

• Virtual Private Network (VPN) connections, often

used to connect remotely to an office network

• The “Bring Your Own Access” program from America

Online (AOL), which lets you use AOL through broadband

provided by another cable or DSL service

• Most online banking websites

• Many commercial websites that require a user

name and password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPN or AOL software, or by re-logging into the secure website.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections,

VPNs, and AOL, please review steps 1–4 in the previous

pages to be sure you have addressed these issues.

These guidelines should allow you to cover the maximum possible

area with your wireless router. Should you need to cover an even wider

area, we suggest the Belkin Wireless Range Extender/Access Point.

For more information regarding our networking products,

visit our website at www.belkin.com/networking

or call Belkin Technical Support.

OVERVIEW

Product Features

The Adapter complies with the IEEE 802.11g specification

to communicate with other 802.11g-compliant

wireless devices at up to 54Mbps*.

The Adapter is also compatible with 802.11n devices at

150Mbps as well as 802.11b products at 11Mbps.

The Adapter operates on the same 2.4GHz frequency

band as 802.11b/g Wi-Fi®products.

• 2.4GHz ISM (Industrial, Science, and Medical) band operation

• USB 2.0 interface, for operation in virtually any

computer with a USB 2.0 bus-power port

• WPA, WPA2, 64-bit WEP (Wired Equivalent

Privacy), or 128-bit encryption

• Wireless access to networked resources

• Data rate of up to 150Mbps* (802.11n), 54Mbps

(802.11g), or 11Mbps (802.11b)

• Easy installation and use

• LED power and network link/activity indicator

OVERVIEW

Applications and Advantages

• Wireless roaming with a laptop around the home or

office – Offers the freedom of networking without cables

• Connection rates of up to 150Mbps* – Provides

immediate high-speed wireless connectivity at home,

work, and hotspot locations without compromising

the use of existing 802.11b/g products

• Compatibility with 802.11b/g products – The Adapter is

backward-compatible with existing Wi-Fi (IEEE 802.11b/g) products

• Difficult-to-wire environments – Enables networking

in buildings with solid or finished walls, or open

areas where wiring is difficult to install

• Frequently changing environments – Adapts easily in offices

or environments that frequently rearrange or change locations

• SOHO (Small Office/Home Office) networking needs – Provides

the easy and quick, small network installation SOHO users need

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Adaptador de Belkin

Belkin

Belkin F8T001 Manual de usuario

Belkin

Belkin F8T031 - Bluetooth Wireless USB Printer Adapter Print... Manual de usuario

Belkin

Belkin F8T008 Manual de usuario

Belkin

Belkin F5U103-MAC Manual de usuario

Belkin

Belkin USB ADB Adapter F5U118-UNV Manual de usuario

Belkin

Belkin F6D4050 Manual de usuario

Belkin

Belkin SOUNDFORM CONNECT AUZ002 Manual de usuario

Belkin

Belkin G+MIMO Manual de usuario

Belkin

Belkin G+MIMO Manual de usuario

Belkin

Belkin F5U002 Guía

Belkin

Belkin USB/SCSI Adapter F5U115-UNV Manual de usuario

Belkin

Belkin F5L010 Manual de usuario

Belkin

Belkin Surf F7D1102 Manual de usuario

Belkin

Belkin F5D6050 Manual de usuario

Belkin

Belkin F7D7501v1 Manual de usuario

Belkin

Belkin Surf/Share F7D2101 Manual de usuario

Belkin

Belkin F7D2101AK 8820AK00384 Manual de usuario

Belkin

Belkin OmniView F1DE083 Manual de usuario

Belkin

Belkin USB/SCSI Adapter F5U115-UNV Manual de usuario

Belkin

Belkin F5D4075 - Powerline AV+ Starter Manual de usuario

Belkin

Belkin F5U004 Manual de usuario

Belkin

Belkin F1DN002A Manual de usuario

Belkin

Belkin F5D7051 Manual de usuario

Belkin

Belkin Bluetooth USB Adapter F8T012 Manual de usuario

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
