Behringer K-2 Manual de usuario

page 1 of 2

985-40000-01088 Rev.A

2021-02-03

Condential, for internal use only. Not to be reproduced.

Analog and Semi-Modular Synthesizer with

Dual VCOs, Ring Modulator, External

Signal Processor, 16-Voice Poly Chain and

Eurorack Format

Synthesizers and Samplers

K-2

User Support Bulletin

Calibration Procedure

Set the K-2 controls as shown.

Make sure your K-2 has been powered on for more than 30 minutes, and that it is in a place where the temperature will

not change drastically while performing the calibration.

Follow all steps in the order in which they are presented.

Introduction

The unit is carefully calibrated at the factory. The performance may change over time or due to environmental changes,

and the following recalibration procedures can be used to bring it back to its factory settings.

page 2 of 2

985-40000-01088 Rev.A

2021-02-03

Condential, for internal use only. Not to be reproduced.

page 2 of 2

Condential, for internal use only. Not to be reproduced.

Music Tribe accepts no liability for any loss which may be suered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.

Technical specications, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. Midas, Klark Teknik,

Lab Gruppen, Lake, Tannoy, Turbosound, TC Electronic, TC Helicon, Behringer, Bugera, Oberheim, Auratone and Coolaudio are trademarks or registered trademarks of Music Tribe Global

Synthesizers and Samplers

K-2

VCO PITCH Calibration

Press and hold “TRIG SW” while powering up to enter the testing mode. (In this mode, the ON LED will blink yellow).

The K-2 has an internal calibration routine to calibrate the pitch of the VCO.

Press and hold “TRIG SW,” and then set the “FILTER1/2” switch. The ON LED will light yellow, indicating that the

VCO calibration has begun.

Wait until the ON LED changes color:

- Green indicates that the calibration was successful.

- Red indicates calibration failure. If this occurs, turn o the power and repeat from Step1.

Restart the unit.

End of Procedure
