P16-D

16-Channel Digital ULTRANET Distributor

Features

• DistributionHubforP16-Iforsystemexpansion

• 1ULTRANETinputfeeds8ULTRANEToutputs(RJ-45)

• Providesbus-powerand16-channelsignal

transmissionforall8outputs

• UptosixP16-DULTRANETDistributorscanbe

combinedforatotalofforty-eightP16-MPersonal

Mixers

• StatusLEDindicatorsforRJ-45inputand8RJ-45

outputs

• Internalautorangepowersupplyformaximum

exibility(100-240V~),noise-freeaudio,superior

transientresponsepluslowpowerconsumptionfor

energysaving

• Extremelyruggedconstructionensureslonglifeeven

underthemostdemandingconditions

16-Channel Digital ULTRANET Distributor

P16-D

Ultranet Distributor

Digital Inputs / Outputs (Ultranet)

• Ultranet in 1 x RJ45

• Ultranet outputs 8 x RJ45

Power Supply /Voltage (Fuses)

• USA / Canada 120 V~, 60 Hz (T 1 A H 250 V)

• UK / Australia / Europe 220-240 V~, 50/60 Hz (T 1 A H 250 V)

• Korea / China 220-240 V~, 50/60 Hz (T 1 A H 250 V)

• Japan 100 V~, 50/60 Hz (T 1 A H 250 V)

Power consumption max. 40 W

Mains connection Standard IEC receptacle

Dimensions / Weight

• Dimensions (H x W x D) appr. 1.7 x 10 x 6.3"

appr. 44 x 254 x 160 mm (1U)

• Weight appr. 2.4 lbs / 1.1 kg

Overview Technical Specications

ThePOWERPLAYP16-DULTRANETDistributorextendsand

expandsthePOWERPLAYP16personalmonitorsystemby

duplicatingasinglelow-latency(<0.9ms),16-channel,24-

bitULTRANETsignalinto8identicaldigitaloutputs.These

8cloneddigitalsignalscantheneachbesenttoaP16-M

personalmixerorotherULTRANETdevice.

EachP16-DULTRANETDistributorreceivestheULTRANET

signalthroughasingleCAT5eRJ-45inputjack.TheP16-D

thenclonestheULTRANETsignalandsends8copiesback

outthroughtheunit's8ULTRANETRJ-45outputjacks.

InadditiontotheULTRANET16-channeldigitalsignal,

eachP16-Dalsosendsoutapowersignalthrougheach

ULTRANEToutput.Whenpoweroutletsarescarce,eachof

thesebus-powersignalscanbeusedtopoweraP16-M

mixer.EachoftheseP16-Mmixersthenallowseachuser

tocreatetheirownpersonal,customizedheadphoneor

monitormix.

WithinalargeULTRANETnetworkoriginatingfromaP16-I

InputModule,theP16-IInputModulecansendout6

identicalULTRANETsignals,eachwith16channelsof24-bit

audio,to6P16-Dhubs.EachP16-Dhubinturndistributes

8copiesofthesame16-channeldigitalsignalto8P16-M

DigitalMixers,foratotalof48P16-Mmixers.

TheP16-DalsoseamlesslyintegrateswiththeX32digital

mixer.TheX32'ssingleULTRANEToutputsignalcanbe

senttoasingleP16-DhubforfurtherdistributiontoP16-M

mixersoradditionalP16-Ddistributionhubs.

AspartofanULTRANETnetwork,theP16-Dsupportsa

completepersonalmonitoringsolutionforlive,studio,

orinstalledsoundapplications.

Dimensional Drawings

16-Channel Digital ULTRANET Distributor

P16-D

Block Diagram

P16-I

INPUT MODULE

P16-M DIGITAL

PERSONAL MIXER

P16-M DIGITAL

PERSONAL MIXER

ULTRANET

OUTPUTS

IEC POWER

CONNECTION

12345678

BUS-POWER SIGNAL

>incoming power signal - ignored

>outgoing power signal - only if P16-D is powered on

16-CHANNEL DIGITAL AUDIO SIGNAL

>incoming audio signal - distributed parallel to 8 outputs

>even if P16-D is powered OFF - audio signal distributed

POWERPLAY 16 P16-D

DIGITAL ULTRANET DISTRIBUTOR

ULTRANET IN

Copyright © 2012 MUSIC Group IP Ltd. All rights reserved. MIDAS, KLARKTEKNIK, BEHRINGER and BUGERA are part of the MUSIC Group (music-group.com).The information contained herein is correct at the time of printing.Technical speciﬁcations and

appearance are subject to change without notice. Colors and speciﬁcations may vary from actual product. MUSIC Group IP Ltd. accepts no liability for any damages or loss which may be suﬀered by any person who relies either wholly or in part upon any

description, photograph or statement contained herein. All trademarks are the property of their respective owners. Products are sold through authorized Fulﬁllers and Resellers only. Fulﬁllers and Resellers are not agents of MUSIC Group IP Ltd. or any of its

aﬃliates and subsidiaries, and have absolutely no authority to bind MUSIC Group IP Ltd. by any express or implied undertaking or representation. MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,Tortola, British Virgin Islands.

P16-D

16-Channel Digital ULTRANET Distributor

Dimensional Drawings

254.00 mm [10.0000 in]

43.81mm[1.7250in]

152.26 mm [5.9946 in]
