Behringer B-Control NANO BCN44 Manual de usuario

Users manual

Version 1.0 March 2005

B-CONTROL NANO BCN44

CAUTION: To reduce the risk of electric

shock, do not remove the top cover (or the rear

section). No user servicea le parts inside; refer

servicing to qualified personnel.

WARNING: To reduce the risk of fire or

electric shock, do not expose this appliance to

rain and moisture. The apparatus should not e

exposed to dripping or splashing and no o jects

filled with liquids, such as vases, should e

placed on the apparatus.

This sym ol, wherever it appears,

alerts you to the presence of

uninsulated dangerous voltage

inside the enclosurevoltage that

may e sufficient to constitute a

risk of shock.

This sym ol, wherever it appears,

alerts you to important operating

and maintenance instructions in

the accompanying literature.

Please read the manual.

DETAILED SAFETY INSTRUCTIONS:

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean onl with dr cloth.

7) Do not block an ventilation openings. Install in accordance with the manufacturers instructions.

8) Do not install near an heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safet purpose of the polarized or grounding-t pe plug. A polarized plug has two blades

with one wider than the other. A grounding t pe plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for our safet . If the provided plug does not fit into our outlet, consult

an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularl at plugs, convenience receptacles,

and the point where the exit from the apparatus.

11) Onl use attachments/accessories specified b the manufacturer.

12) Use onl with the cart, stand, tripod, bracket, or table specified b the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injur

from tipping over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been

damaged in an wa , such as power suppl cord or plug is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normall , or

has been dropped.

15) CAUTION - These service instructions are for use b qualified service personnel onl . To reduce the risk

of electric shock do not perform an servicing other than that contained in the operation instructions unless

ou are qualified to do so.

IMPORTANT SAFETY INSTRUCTIONS

B-CONTROL NANO BCN44

TABLE OF CONTENTS

1. INTRODUCTION ......................................................................................................... 4

1.1 Before you get started ........................................................................................................ 4

1.1.1 Shipment ...................................................................................................................... 4

1.1.2 Initial operation ............................................................................................................ 4

1.1.3 Online registration .......................................................................................................4

2. CONTROL ELEMENTS AND CONNECTIONS .......................................................... 5

2.1 Additional fun tions ........................................................................................................... 9

2.1.1 Snapshot Send ............................................................................................................ 9

2.1.2 Single Preset Dump .................................................................................................... 9

2.1.3 Storing received Single Preset Dumps ....................................................................... 9

3. APPLICATION EXAMPLES ....................................................................................... 9

3.1 Software-Controller ............................................................................................................ 9

3.2 Hardware ontroller .........................................................................................................10

3.3 Multiple MIDI ontrollers .................................................................................................. 11

4. MIDI .......................................................................................................................... 11

4.1 LEARN fun tion ................................................................................................................ 13

5. SPECIFICATIONS .................................................................................................... 13

6. APPENDIX ................................................................................................................ 14

7. WARRANTY ............................................................................................................. 18

B-CONTROL NANO BCN44

1. INTRODUCTION

Thank ou for expressing our confidence in us b purchasing the B-CONTROL BCN44. The B-CONTROL

is an extremel versatile pocket-size MIDI controller. Despite its modest size, its numerous functions will

thoroughl impress ou.

Unlike with conventional MIDI controllers, our goal with the BCN44 was to offer an intuitive, flexible and

opticall appealing product that doesnt inhi it your creativity with miniature kno s and uttons. Therefore,

we have decided to go with a robust, clearl laid-out design consisting of freel programmable encoders and

buttons, extensive MIDI functions and the possibilit to work practicall an where. These are just some of the

outstanding B-CONTROL BCN44 characteristics that will be a lot of fun to use for a ver long time.

+The following users manual is esigne to help you get comfortable with this units control

elements, so that you can learn all of its functions. After carefully rea ing the users manual,

store it somewhere where you can easily fin it later, in case you nee to look something up.

1.1 Before you get started

1.1.1 Shi ment

The BCN44 was carefull packed at the factor to ensure secure transportation. Should the condition of the

cardboard box suggest that damage ma have taken place, please inspect the unit immediatel and look for

ph sical indications of damage.

+Damage units shoul NEVER be sent irectly to us. Please inform the ealer from whom

you acquire the unit imme iately as well as the transportation company from which you

took elivery of the unit. Otherwise, all claims for replacement/repair may be ren ere invali .

+To ensure optimal protection uring transportation, we recommen using a carrying case.

+Always use the original packaging to avoi amage ue to storage or shipment.

+Never let unsupervise chil ren play with your BCN44 or its packaging.

+Please ispose of all packaging materials in an environmentally frien ly manner.

1.1.2 Initial o eration

To avoid overheating, ensure adequate ventilation and never place our BCN44 on top of an amplifier or

near radiators.

The wall power unit included in the deliver supplies the power to our BCN44. It complies with all applicable

safet regulations.

1.1.3 Online registration

Please do remember to register our new BEHRINGER equipment right after our purchase b visiting

www.behringer.com (alternativel www.behringer.de) and kindl read the terms and conditions of our warrant

carefull .

BEHRINGER warrants all items purchased against defects in material or workmanship for one ear* from

date of purchase. Full terms of the warrant ma be found on our website at www.behringer.com (alternativel

www.behringer.de).

Should our BEHRINGER product malfunction, our goal is to have it repaired as quickl as possible. To

arrange for warrant service, please contact the retailer from whom the equipment was purchased. Should

our BEHRINGER dealer not be located in our vicinit , ou ma directl contact one of our subsidiaries.

Corresponding contact information is included in the original equipment packaging (Global Contact Information/

European Contact Information). Should our countr not be listed, please contact the distributor nearest ou.

A list of distributors can be found in the support area of our website (www.behringer.com).

Registering our purchase and equipment with us helps us process our repair claims quickl and efficientl .

Thank ou for our cooperation!

B-CONTROL NANO BCN44

2. CONTROL ELEMENTS AND CONNECTIONS

Fig. 2.1: BCN44s control elements

Use the left PRESET button to select the next preset down.

Use the right PRESET button to select the next preset up.

+To select presets more quickly, keep one of the preset buttons presse an simultaneously

turn one of the push enco ers. The new preset is active as soon as you release the preset key.

PANIC: This function restores the most important MIDI data back to their factor settings.

sPress both PRESET buttons simultaneousl . The unit resets as soon as the buttons are pressed.

sAfter the reset is complete, the unit automaticall resumes normal operation and the current preset is

shown in the displa .

When powering up the unit, the four-digit LED displa shows the current operating software version.

After that, the displa switches to displa ing the last selected preset. Each time ou change a setting

using an of the control elements, the LED shows this value change in real time. When in programming

mode, MIDI commands, program/channel numbers and parameter values are shown.

+A itional isplay functions are escribe un er .

Use the ST RE button to store presets.

sPress the STORE button. The button LED starts blinking.

sSelect the desired preset using the PRESET buttons or keep one of the PRESET buttons pressed and

B-CONTROL NANO BCN44

2. CONTROL ELEMENTS AND CONNECTIONS

simultaneousl turn one of the push encoders. The new preset number blinks in the displa .

sPress STORE again, and STORE LED and the displa stop blinking.

sIf ou want to overwrite the current preset, press the STORE button twice (step 2 is omitted).

sYou can cancel the store b pressing the EDIT/EXIT button.

+We have eliberately refraine from having an automatic store function. This way, in the

meantime you can assign a new MIDI comman to a control element without changing the

current preset. Shoul you then wish to restore the previous preset, briefly ial up another

preset an then switch back to the ol preset. Now, all the ata has been restore , inclu ing

the control element whose function ha previously been briefly reassigne .

The EDIT/EXIT button has two functions:

1. EDIT mode: To activate the EDIT mode, keep the EDIT/EXIT button pressed and actuate the desired

control element (push encoders through or buttons through ). After that, release

the EDIT/EXIT button. The EDIT mode is now activated for the selected control element and is shown

in the displa (e.g. E(ncoder) 3 > LED is lit or b(utton)1 > LED blinks).

To exit the EDIT mode, press the EDIT/EXIT button. The unit switches back into normal operating

mode.

+All EDIT mo e functions for particular controller types are liste in tables 6.3 an 6.4.

+There are two ifferent types of assignable control elements: CONTINUOUS (knobs) an

SWITCH (buttons). The correspon ing functions an setting options are escribe in tables

6.3 an 6.4.

+Please keep in min that 2 ifferent ata types can be assigne to a push enco er (either

continuous or switch-type).

+All the settings ma e here are store only temporarily! If you wish to store them permanently,

you will have to store them in a preset.

2. GLOBAL mode: All cross-functional settings that affect not onl presets but the whole unit are

made in this mode.

sKeep the EDIT/EXIT button pressed and then press the STORE button. You are now in the global

setup and can release both buttons.

sThe possible settings are listed in table 2.1:

Table 2.1: verview of GL BAL mode parameters

Global MIDI Receive Channel:

Your B-CONTROL receives program change commands on this channel. No program change commands

are received in the Off position.

B-CONTROL NANO BCN44

2. CONTROL ELEMENTS AND CONNECTIONS

Device ID Number:

You should onl change ID number if ou are using several NANOs and problems with recognizing the

correct unit occur during a S sEx dump.

+Please keep in min that SysEx umps can only be receive on the evice ID number to

which they were sent!

System Exclusive Dump (SysEx):

B turning the VALUE 1 push encoder , ou can select whether onl the current preset (Single Dump) or

the entire 99 preset contents (All Dump) are sent as a S sEx dump. Pressing the push encoder once triggers

the dump.

To receive a S sEx dump, no adjustments on the unit whatsoever are necessar . If ou send a single preset

to the B-CONTROL, the data is stored in temporar memor and has to be stored into a preset if ou wish to

store it permanentl (see preset store function).

+ATTENTION: If you sen an All Dump to the B-CONTROL, the entire contents of its memory

are imme iately overwritten! You will not be aske to confirm your choice, an there is no

memory safeguar function!

sTo cancel a S sEx dump, press the EXIT button.

MIDI Merge:

With this function, incoming MIDI data are mixed with the BCN44 data at MIDI Out (see fig. 2.2).

Fig. 2.2: Routing with MIDI merge

To activate MIDI merge, turn the push encoder . The 4 push encoders labeled through are

used for sending MIDI data. These push encoders have two functions (turn and press), to which different

MIDI commands can be assigned.

When in EDIT mode, use CHANNEL to change the values set in tables 6.3 and 6.4.

When in EDIT mode, use PARAMETER to change the values set in tables 6.3 and 6.4.

When in EDIT mode, use VALUE 1 to change the values set in tables 6.3 and 6.4.

When in EDIT mode, use VALUE 2 to change the values set in tables 6.3 and 6.4. Each of the 4

buttons labeled through sends the programmed MIDI command.

+Note on using the buttons while in EDIT mo e: Keep the button presse an use the push

enco er locate above it to select a value. After that, release the button.

The TYPE button selects the t pe of MIDI data sent in EDIT mode.

The M DE button selects the Controller Mode for the selected MIDI data t pe function in EDIT mode

(see table 6.3 and 6.4).

B-CONTROL NANO BCN44

2. CONTROL ELEMENTS AND CONNECTIONS

The DISPLAY button is used for adjusting displa functions. When in normal operating mode, value changes

are displa ed in real time. You can deactivate this function in EDIT mode (see tables 6.3 and 6.4).

Use the LEARN button to activate the LEARN function in EDIT mode. Detailed information about the

LEARN function can be found in chapter 4.1.

Fig. 2.3: Rear-end connections and control elements

These are the MIDI connectors of our B-CONTROL. BCN44 parameter data are received on the MIDI

IN connector.

Data for controlling MIDI equipment can be sent via MIDI OUT. If MIDI MERGE was activated (see

), the MIDI data received, along with the control data of the BCN44, is sent to the MIDI UT

connector.

+Detaile information about MIDI an MIDI functions of your BCN44 can be foun in chapter 4.

The P WER switch turns the B-CONTROL on. The POWER switch should alwa s be in its Off

position whenever ou establish a connection to the mains.

+Please keep in min : The POWER switch oes not entirely separate the unit from the mains.

Please isconnect the power cor from the mains if you wont be using the unit for a while.

Power is provided via a two-pole connector. A matching mains adapter is included in deliver . A strain

relief for the mains cable is located next to the connector.

Alternativel , our BCN44 can also run on batteries. For battery operation ou will need to insert

three standard AA 1.5-Volt mignon batteries into the batter compartment located on the bottom side

of the unit (see ).

+When running on batteries, the BCN44 oes not show the current preset. If you nee to see

the current preset number while running on batteries, briefly press the EDIT/EXIT button.

+When you are not using your BCN44 for a long time, you efinitely nee to remove the

batteries!

The batter compartment is located at the bottom. To run our B-CONTROL on batteries, ou will need

3 AA 1.5 Volt mignon batteries.

The SERIAL NUMBER of our BCN44 is also located at the bottom.

B-CONTROL NANO BCN44

3. CONTROL ELEMENTS AND CONNECTIONS

2.1 Additional functions

2.1.1 Sna shot Send

A Snapshot Send sends all current Controller values, so that B-CONTROL settings are transmitted to the

MIDI device connected to it.

sWhile the EDIT/EXIT button is kept pressed, press the PRESET. The B-CONTROL will now send

the current settings of the controller values.

2.1.2 Single Preset Dum

In addition to the S sEx Dump function, this button combination can also send all settings of the current

presets:

sWhile the EDIT/EXIT button is kept pressed, press PRESET .

+Snapshot Sen an Single Preset Dump iffer in the type of ata being sent. With

Snapshot Sen , only the current control values are transmitte in or er to synchronize them

with the MIDI evice connecte . With Single Preset Dump, the entire contents of the current

preset inclu ing the current control element assignment are being sent. This function lets

you easily archive specific presets or swap them with other B-CONTROL users.

2.1.3 Storing received Single Preset Dum s

This function lets ou store individual presets that were sent b an external MIDI device.

sSend a Single Preset Dump via MIDI IN to our B-CONTROL.

sPress STORE; the LED blinks.

sUse PRESET to select a storage location.

sPress STORE again; the LED no longer blinks.

3. APPLICATION EXAMPLES

Your BCN44 can be used in man different wa s, the most common of which are shown and described in this chapter.

3.1 Software-Controller

When used as a software controller, the BCN44 can control an audio/MIDI software. These include, among

others, virtual instruments and effects units, sequencer software etc. It connects to a PC via the MIDI

connectors. Using an external USB MIDI interface, the MIDI signal can also be transmitted via USB. The

graphic on the next page shows how different devices need to be wired.

B-CONTROL NANO BCN44

3. APPLICATION EXAMPLES

Fig. 3.1: Software controller

3.2 Hardware controller

Generall speaking, the B-CONTROL can control an MIDI-capable hardware. This example shows a setup

with a MIDI ke board, a sound module and an effects unit. The effects unit is connected in series using the

MIDI THRU connector on the sound module, thus receiving the looped-through MIDI control data of the

BCN44. The ke data (note, pitch bend etc.) are mixed with the controller data of the BCN44, provided that

the MIDI Merge function (see ch. 2) is activated.

Of course, ou can also control the often hard-to-access sound parameters of a ke board in real time.

Connect MIDI OUT of the BCN44 to MIDI IN of our ke board.

Fig. 3.2: Hardware controller

Otros manuales para B-Control NANO BCN44

Otros manuales de Equipo de grabación de Behringer

Behringer

Behringer B-Control Fader BCF2000 Manual de usuario

Behringer

Behringer MODULIZER PRO DSP1224P Manual de usuario

Behringer

Behringer U-CONTROL UCA202 Manual de usuario

Behringer

Behringer B-Control Fader BCF2000 Manual de usuario

Behringer

Behringer B-Control Fader BCF2000 Manual de usuario

Behringer

Behringer Ultra-dyne Pro DSP9024 Manual de usuario

Behringer

Behringer Virtualizer Pro DSP1024P Manual de usuario

Behringer

Behringer Modulizer PRO DSP1200P Manual de usuario

Behringer

Behringer 2500 Series Manual de usuario

Behringer

Behringer SHARK DSP110 Manual de usuario

Behringer

Behringer ULTRAPATCH PRO PX3000 Manual de usuario

Behringer

Behringer B-CONTROL Instrucciones de funcionamiento

Behringer

Behringer Minibeat BEAT800 Manual de usuario

Behringer

Behringer Tube Composer T1952 Manual de usuario

Behringer

Behringer Xenyx 1222FX Manual

Behringer

Behringer VINTAGE PHASER VP1 Manual de usuario

Behringer

Behringer MIDI FOOT CONTROLLER FCB1010 Manual de usuario

Behringer

Behringer Virtualizer Pro DSP2024P Manual de usuario

Behringer

Behringer ULTRAFLEX PRO EX3200 Manual de usuario

Behringer

Behringer Virtualizer Pro DSP2024P Manual de usuario

Behringer

Behringer SHARK DSP110 Manual de usuario

Behringer

Behringer SUPER-X PRO CX2310 Manual de usuario

Behringer

Behringer DJ CONTROLLER CMD MICRO Manual de usuario

Behringer

Behringer BASS OVERDRIVE BOD400 Manual de usuario

Manuales populares de Equipo de grabación de otras marcas

KV2 Audio

KV2 Audio 500 Series Manual de usuario

Robotics Technologies

Robotics Technologies microBus-Cam II Manual de usuario

Seca

Seca 460 Manual de usuario

Cognex

Cognex MVS-8000 Series Manual de usuario

Mect

Mect MPNC006 Series Manual de usuario

Bad Caf

Bad Caf THE LEASH Manual de usuario

Strymon

Strymon NIGHTSKY Manual de usuario

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manual de usuario

Tews Technologies

Tews Technologies TPMC465 Manual de usuario

Honeywell

Honeywell Excel 50 Manual de usuario

SeaLevel

SeaLevel COMM+8.LPCI Manual de usuario

Arturia

Arturia AUDIOFUSE STUDIO Manual de usuario

Rukra

Rukra RK-1240 Manual de usuario

Samson

Samson SCOM Manual de usuario

Dynacord

Dynacord DPS260 Manual de usuario

Nice

Nice Core Manual de usuario

Pyle Pro

Pyle Pro PSS8 Manual de usuario

RF-System

RF-System TinyGate Manual de uso y cuidado
