Behringer 2500 Series Manual de usuario

Quick Start Guide

MULTIMODE FILTER /

RESONATOR MODULE 1047

Legendary 2500 Series 12dB State

Variable Filter Module for Eurorack

Controls

(1) COARSE – Use this knob to dial in the general frequency

area you want for the high-pass threshold, low-pass

threshold, band-pass center frequency and notch lter

center frequency, then go to the FINE knob to rene the

frequency setting. The frequency set by the COARSE and

FINE knobs (“fc”) will be used simultaneously for every

lter in the module.

(2) FINE – Use this knob to rene and focus the frequency set

by the COARSE FREQUENCY knob.

(3) RESONANCE (NORM/LIM) – This sliding switch lets

you choose between normal resonance mode (NORM)

and limiting mode (LIM), which limits the height of a

lter’s resonant peak. The LIM setting prevents circuit

overload when focusing a lter on a strong harmonic or

fundamental frequency, especially at high Q settings on

the RESONANCE (Q) knob. In other situations, the LIM

setting can result in a very low output signal, and so the

NORM setting is usually preferred.

(4) RESONANCE (Q) – This knob controls the width/

smoothness and narrowness/sharpness of the lter

curves. At low Q settings, the lter curves are wider and

smoother, with a gentler eect on the sound (except for

the notch lter, which functions most eectively at low

Q settings). As you increase the Q setting, the lter curves

gradually become narrower and sharper, which can help

you to focus in on narrow frequency bands. At higher Q

settings, the various lters can produce resonant peaks

in the lter curves that boost some frequencies and may

require moving the RESONANCE (NORM/LIM) switch to

the LIM setting to prevent overloading the circuit (or the

INPUT attenuator knob can be turned down).

(5) F CV 1 – This knob adjusts the strength of the control

voltage signal coming in through the F CV 1 jack.

(6) F CV 2 – This knob adjusts the strength of the control

voltage signal coming in through the F CV 2 jack.

(7) NOTCH FEQUENCY/fc – Use this knob to oset the notch

lter’s center frequency (“fc”) set by the COARSE and FINE

frequency controls. For standard notch lter behavior, the

NOTCH FREQ/fc control should be set to “1” on the scale.

This standard setting can then be tweaked by moving the

NOTCH FREQ/fc knob very slightly around “1”. Also, if

higher Q values are added via the RESONANCE knob while

the notch lter is oset from fc, the higher Q values result

in a resonant peak at fc, with the notch at the point set by

the NOTCH FREQ/fc knob.

(8) INPUT – This knob adjusts the strength of the audio signal

coming through the INPUT jack.

(9) Q CV – This knob adjusts the strength of the Q control

voltage signal coming in through the Q CV jack.

(10) INPUT – Use this jack to route audio signals into the

module via cables with 3.5 mm connectors. You can also

route in a keyboard gate signal to “ring” the lter and

produce a unique percussive sound when you press a key.

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10) (11) (12) (13) (14) (15)

(17)

(16)

Knob Setting Eect

Full CCW Notch lter output becomes a

copy of the high-pass output

CCW to 1/4 Notch frequency shifts

signicantly below fc

CW to 4 Notch frequency shifts

signicantly above fc

Full CW Notch lter output becomes a

copy of the low-pass lter output

V 1.0

(11) F CV 1 – Use this jack to route external control voltage or

modulation signals for the lter frequency setting into the

module via cables with 3.5 mm connectors.

(12) F CV 2 – Use this jack to route external control voltage or

modulation signals for the lter frequency setting into the

module via cables with 3.5 mm connectors.

(13) Q CV – Use this jack to route external control voltage

signals for the RESONANCE (Q) setting into the module via

cables with 3.5 mm connectors.

(14) LP – This jack sends out the nal signal from the low-pass

lter via cables with 3.5 mm connectors.

(15) HP – This jack sends out the nal signal from the high-

pass lter via cables with 3.5 mm connectors.

(16) NOTCH – This jack sends out the nal signal from the

notch lter via cables with 3.5 mm connectors.

(17) BP – This jack sends out the nal signal from the band-

pass lter via cables with 3.5 mm connectors.

Power Connection

The MULTIMODE FILTER / RESONATOR MODULE 1047 module

comes with the required power cable for connecting to a standard

Eurorack power supply system. Follow these steps to connect

power to the module. It is easier to make these connections before

the module has been mounted into a rack case.

1. Turn the power supply or rack case power o and

disconnect the power cable.

2. Insert the 16-pin connector on the power cable into the

socket on the power supply or rack case. The connector has

a tab that will align with the gap in the socket, so it cannot

be inserted incorrectly. If the power supply does not have

a keyed socket, be sure to orient pin 1 (-12 V) with the red

stripe on the cable.

3. Insert the 10-pin connector into the socket on the back of

the module. The connector has a tab that will align with the

socket for correct orientation.

4. After both ends of the power cable have been securely

attached, you may mount the module in a case and turn on

the power supply.

Installation

The necessary screws are included with the module for mounting in

a Eurorack case. Connect the power cable before mounting.

Depending on the rack case, there may be a series of xed holes

spaced 2 HP apart along the length of the case, or a track that allows

individual threaded plates to slide along the length of the case.

The free-moving threaded plates allow precise positioning of the

module, but each plate should be positioned in the approximate

relation to the mounting holes in your module before attaching

the screws.

Hold the module against the Eurorack rails so that each of the

mounting holes are aligned with a threaded rail or threaded

plate. Attach the screws part way to start, which will allow small

adjustments to the positioning while you get them all aligned. After

the nal position has been established, tighten the screws down.

Filter Curves

Q=2

NORMAL MODE

LOWPASS RESPONSE

Q=½

16 Hz

16 KHzFc

16 Hz

16 KHzFc

Q=2

LIMIT MODE

Q=½

16 Hz 16 KHzFc

16 Hz

16 KHz

Q=2 NORMAL MODE

BANDPASS RESPONSE

Q=½

Q=2

LIMIT MODE

Q=½

16 Hz

16 KHzFc

16 Hz 16 KHzFc

Q=2 NORMAL MODE

HIGHPASS RESPONSE

Q=½

Q=2

LIMIT MODE Q=½

2MULTIMODE FILTER / RESONATOR MODULE 1047

Specications

Inputs

Input

Type 1 x 3.5 mm TS jack, DC coupled

Impedance 50 kΩ, unbalanced

Max input level +18 dBu

Frequency CV input 1

Type 1 x 3.5 mm TS jack, DC coupled

Impedance 50 kΩ, unbalanced

Max input level ±10 V

CV scaling 1 V/oct.

Frequency CV input 2

Type 1 x 3.5 mm TS jack, DC coupled

Impedance 50 kΩ, unbalanced

Max input level ±10 V

CV scaling 1 V/oct.

Q CV input

Type 1 x 3.5 mm TS jack, DC coupled

Impedance 50 kΩ, unbalanced

Max input level ±10 V

CV scaling 1 V doubles the Q factor

Outputs

Filter outputs (LP / HP / BP / Notch)

Type 4 x 3.5 mm TS jack, DC coupled

Impedance 1 kΩ, unbalanced

Max output level +18 dBu

Controls

Coarse frequency 1 x rotary knob, 31 Hz to 8 kHz

Fine frequency 1 x rotary knob, x1/2 to x2

Resonance (Q) 1 rotary knob, Q = 0.5 to >256

Resonance (Norm / lim) 2-way sliding switch

Normal / limiting, switchable

Frequency CV 1 / 2 attenuators 2 x rotary knob, -∞ to unity gain

Q CV attenuator 1 x rotary knob, -∞ to unity gain

Input attenuator 1 x rotary knob, -∞ to unity gain

Notch frequency/fc 1 x rotary knob, ±3 octave range

Power

Power supply Eurorack

Current draw 55 mA (+12 V), 45 mA (-12 V)

Physical

Dimensions 43 x 81 x 129 mm (1.7 x 3.2 x 5.1")

Rack units 16 HP

Weight 0.17 kg (0.37 lbs)

Fc/4 4FcFc

Q=2

NOTCH FREQ

= ¼

Q=½ Q=½

Fc/4 4FcFc

Q=2

NOTCH FREQ

= 1

Fc/4 4FcFc

Q=2

NOTCH FREQ

= 4

Notch Responses

3Quick Start Guide
