Behringer C-1U Manual de usuario

User Manual

C-1U

USB Studio Condenser Microphone

2C-1U User Manual

Terminals marked with this symbol

carry electrical current of sucient

magnitude to constitute risk

of electric shock. Useonly high-quality

commercially-available speaker cables

with ¼"TS plugs pre-installed. Allother

installation or modication should be

performed only by qualiedpersonnel.

This symbol, wherever it appears,

alerts you to the presence of

uninsulated dangerous voltage

inside the enclosure -voltage that may be

sucient to constitute a risk ofshock.

This symbol, wherever it appears,

alertsyou to important operating

and maintenance instructions in the

accompanying literature. Please read themanual.

Condenser microphones are

extremely moisture-sensitive.

Never use your microphone in close

proximity to water (e.g. bath tubs, wash basins,

sinks, washing machines, pools, etc.).

Caution

Always use the power

supply specied in the

operating instructions.

Caution

Take care not to drop your

microphone as this can lead to

severe damage. BEHRINGER assumes no liability

for any damage caused by the user.

After each use, wipe the

microphone down with a soft cloth

and place it back into its

protective casing (included with the

microphone). The small bag containing the

moisture-absorbing crystals should remain in

the casing to help keep your microphone dry.

Caution

Never dismount the screen holding

the capsule, as this can damage

the microphone! Never try to modify the printed

circuit board inside your C-1U! This can lead to

microphone damage that cannot be repaired.

Any such attempt will void the warranty.

In exceptional cases, external interference

(e.g. contact and electrostatic discharge) may

aect the functioning of the unit and result in

audio or functional impairment. In any such

case, please disconnect the unit briey from the

USB port and restart the application to return to

normal operation.

The sound quality may diminish within the

range of powerful broadcasting stations and

high-frequency sources. Increase the distance

between the transmitter and the device and use

shielded cables for all connections.

Important Safety

Instructions

3C-1U User Manual

LIMITED WARRANTY

Please register your new BEHRINGER

equipment right after your purchase by visiting

behringer.com and read the terms and conditions

of our warranty carefully.

LEGAL DISCLAIMER

TECHNICAL SPECIFICATIONS AND APPEARANCE

ARE SUBJECT TO CHANGE WITHOUT NOTICE.

THEINFORMATION CONTAINED HEREIN IS CORRECT

AT THE TIME OF PRINTING. ALL TRADEMARKS

ARE THE PROPERTY OF THEIR RESPECTIVE

OWNERS. MUSICGROUP ACCEPTS NO LIABILITY

FOR ANY LOSS WHICH MAY BE SUFFERED BY

ANY PERSON WHO RELIES EITHERWHOLLY OR IN

PART UPON ANY DESCRIPTION, PHOTOGRAPH OR

STATEMENT CONTAINED HEREIN. COLORS AND

SPECIFICATIONS MAY VARY FROM ACTUAL

PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD

THROUGH AUTHORIZED FULLFILLERS AND

RESELLERS ONLY. FULLFILLERSAND RESELLERS

ARE NOT AGENTS OF MUSICGROUP AND

HAVE ABSOLUTELY NO AUTHORITY TO BIND

MUSICGROUP BY ANY EXPRESS OR IMPLIED

UNDERTAKING OR REPRESENTATION. THIS MANUAL

IS COPYRIGHTED. NO PART OFTHIS MANUAL

MAY BE REPRODUCED OR TRANSMITTED IN

ANY FORM OR BY ANY MEANS, ELECTRONIC OR

MECHANICAL, INCLUDING PHOTOCOPYING AND

RECORDING OF ANY KIND, FOR ANY PURPOSE,

WITHOUT THE EXPRESSWRITTEN PERMISSION OF

MUSICGROUPIPLTD.

Trident Chambers,Wickhams Cay, P.O. Box 146,

Road Town, Tortola, British Virgin Islands

4C-1U User Manual

1. Directivity

Your C-1U features a capsule with a cardioid pickup pattern and is ideal for recording

individual instruments, vocals and speech. Cardioid pickup pattern means that the sound

produced by sources located in front of the mic is strongly picked up. It is often used

in recording situations, since this directivity pattern tones down the pickup of sounds

located to the back of the microphone.

To place the microphone correctly, the BEHRINGER logo needs to face the sound source

being recorded.

2. Mounting the Microphone

There is an adapter on your microphone that lets you mount it on mic stands with

either metric (Europe) or imperial-gauge threads (North America). First dismantle the

microphone from the stand mount adapter by detaching the ne-thread shoulder screw

at the bottom end of the microphone. Fasten the adapter onto the microphone stand,

place the microphone into it and tighten the screw again.

Basically, the microphone in the stand mount adapter should stand upright and face the

sound source at a right angle. The angle of the microphone to the sound source inuences

the sound of the recording; therefore, experiment with dierent positions until you

achieve the desired sound. To this end, you can rotate the mic in the stand mount adapter

by loosening the screw somewhat and tightening it again.

If necessary, you can bend the microphone out of its vertical position by using the hinge

on the microphone stand.

◊ Please make sure to handle the microphone shaft with attention and care

to avoid damaging the screw thread. In no situation should you ever apply

excessive force.

Of course, you can detach the C-1U from the stand mount adapter and attach it to a

commercially available suspension mount.

5C-1U User Manual

3. Installing the Microphone

3.1 Technical requirements

Your C-1U microphone comes with a USB connector. The audio signal is sent from the

microphone to the computer through this connection. At the same time the computer uses

the USB connection to supply the microphone with the necessary power. A connection is

made by using the included USB cable with type-B connector.

◊ Use only the included cable to ensure an optimal signal quality and a reliable

power supply.

To operate the C-1U, your computer needs to meet the following system requirements:

3.2 Initial operation

Before you can use your C-1U, connect it to a free USB port on your computer.

For initial operation of your C-1U, complete the following steps:

1) Power up your computer.

2) Connect your C-1U to a free USB port on your computer.

◊ Your operating system automatically installs the required drivers.

3) Select the C-1U as input source in your preferred audio software application.

Windows:

4) Adjust the recording level as required, using the Windows Volume Control panel.

(Shortcut: Loudspeaker icon found in the taskbar)

PC Mac

Intel or AMD CPU, 1GHz or higher G4/G5, 800 MHz or higher

minimum 512 MB RAM minimum 512 MB RAM

USB 2.0 interface USB 2.0 interface

Windows XP/Vista Mac OS X 10.3.9 (Panther) or higher

6C-1U User Manual

Mac OS:

5) Adjust the recording level as required, using Audio Midi Setup in Mac OS.

◊ Your C‑1U is now ready for use.

Complete the following steps should you want to use your C-1U by default in

other applications:

Windows:

• Select the C-1U in the pull-down menu of Sound recording by clicking

on Sounds and Audio Devices in the Control Panel and then clicking the tab Audio

Mac OS:

• Select C-1U as Default Input found under the tab Audio Devices in Audio Midi Setup

of Mac OS

4. Using the Microphone

To get the sound you want, try changing the mic position relative to the sound source or

even move the microphone around in the recording room of your studio. Adjusting the

angle at which walls face the sound source can also be helpful. Only when the desired

basic sound has been achieved, should you start to use equalizers and signal processors,

if any at all (remember: less is often more!).

Due to the extremely linear frequency response and the high sonic resolution of your C-1U,

there is no need for high-frequency “EQing” that can heavily inuence the signal and

unnecessarily increase the noise level. The C-1U provides that much-desired transparency

which often gets lost during recording and mixing.

7C-1U User Manual

20.0

10.0

0.0

-10.0

-20.0

20.0 100.0 1000.0 10k 20k Hz

Frequency response

0˚ 20˚

40˚

60˚

80˚

100˚

120˚

140˚

160˚

180˚

200˚

220˚

240˚

260˚

280˚

300˚

320˚

340˚

1 kHZ

Polar pattern

8C-1U User Manual

Transducer type condenser, 16mm (0.63'')

Polar pattern cardioid

Frequency response 40Hz to 20kHz

Max. SPL (1%THD@1kHz) 136dB

Connector USB connector type B

Power supply 5V, max.50mA (via USB)

Physical/Weight

Dimensions  shaft:2.1", length:6.7"

 shaft:54mm, length:169mm

Weight (net) approx.1.17lbs / 0.53kg

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may

be made from time to time to existing products without prior notice. Specifications and appearance may differ from those

listed or illustrated.

5. Specications

FEDERAL COMMUNICATIONS COMMISSION

COMPLIANCE INFORMATION

Responsible Party Name: MUSIC Group Services US Inc.

Address: 18912 North Creek Parkway,

Suite 200 Bothell, WA 98011,

USA

Phone/Fax No.: Phone: +1 425 672 0816

Fax: +1 425 673 7647

C-1U

complies with the FCC rules as mentioned in the followingparagraph:

This equipment has been tested and found to comply with the limits for a ClassB digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the followingmeasures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician forhelp.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

Important information:

Changes or modications to the equipment not expressly approved by MUSIC Group can void the user’s

authority to use the equipment.

C-1U

We Hear You

Otros manuales para C-1U

Tabla de contenidos

Otros manuales de Micrófono de Behringer

Behringer

Behringer DUAL DIAPHRAGM CONDENSER MICROPHONE B-2 PRO Manual de usuario

Behringer

Behringer C-3 Manual de usuario

Behringer

Behringer T-1 Manual de usuario

Behringer

Behringer XM1800S Manual de usuario

Behringer

Behringer XM1800S Manual de usuario

Behringer

Behringer C-3 Manual de usuario

Behringer

Behringer B-5 Manual de usuario

Behringer

Behringer C-1U Manual de usuario

Behringer

Behringer B-2 Pro Manual de usuario

Behringer

Behringer SINGLE DIAPHRAGM CONDENSER MICROPHONES C-4 Manual de usuario

Behringer

Behringer XM1800S Manual de usuario

Behringer

Behringer BC1200 Manual de usuario

Behringer

Behringer ULTRAVOICE XM2000S Manual de usuario

Behringer

Behringer C-1 Manual de usuario

Behringer

Behringer T-1 Manual de usuario

Behringer

Behringer STUDIO CONDENSER MICROPHONES C-2 Manual de usuario

Behringer

Behringer GO VIDEO KIT Manual de usuario

Behringer

Behringer C-2 Manual de usuario

Behringer

Behringer T-47 Manual de usuario

Behringer

Behringer BIGFOOT Manual de usuario

Behringer

Behringer ULTRALINK ULM100USB Manual de usuario

Behringer

Behringer T-47 Manual de usuario

Behringer

Behringer B-5 Manual de usuario

Behringer

Behringer Monitor Speakers MS16 Manual de usuario

Manuales populares de Micrófono de otras marcas

IK Multimedia

IK Multimedia iRig Stream MIC PRO Manual de usuario

DAPAudio

DAPAudio RM-101 Manual de usuario

AKG

AKG CHM 21 Manual de usuario

Sennheiser

Sennheiser evolution wireless series EM 100 Manual de usuario

Sony

Sony C-48 Manual de usuario

GIGAMEDIA

GIGAMEDIA GGM PAMICUHFG Manual de usuario

Shure

Shure WH30TQG Manual de usuario

auna PRO

auna PRO MIC-900 Manual de usuario

AKG

AKG D 3800 Manual de usuario

Shure

Shure KSM141 Manual de usuario

MAIIN SOUND

MAIIN SOUND IIN style Manual de usuario

Earthworks

Earthworks TC25 Manual de usuario

Sennheiser

Sennheiser evolution D1 Manual de usuario

Alesis

Alesis MicLink Wireless Manual de usuario

DSPPA

DSPPA D6234 Manual de usuario

Monacor

Monacor IMG STAGELINE ECM-300B Manual de usuario

Ansr Audio

Ansr Audio Scan16 Manual de usuario

Shure

Shure MXA710 Series Manual de usuario
