Behringer V-Amp 2 Manual de usuario

Version 1.1 March 2002

Technical Specifications

ENGLISH

V-AMP®

V-AMP 2

V-AMPV-AMP

V-AMP

V-AMP®

Virtual guitar amplifier with tube simulation and digital multi-effects processor

VAuthentic virtual guitar preamp with 32 amp and 15 speaker simulation models

VDedicated selectors for amp models, speaker cabinets and digital effects

VTransparent user interface with direct display of all essential settings

V32 simulations of popular guitar amps, ranging from clean to crunch to tube distortion sounds

V15 speaker simulations directly selectable and freely combinable with any amp model

V24-bit high-resolution stereo multi-effects processor with first-class algorithms like chorus, flanging,

phasing, rotary, auto-wah, echo, delay, compressor and various effects combinations

VAdditional effects parameters now directly accessible on the unit

VNew preamp bypass function allows use as a stereo effects unit without amp model

V125 presets, including 50 original artist presets, organized in 25 banks for easy editing

VDedicated reverb control adds 1 of 9 stereo reverb types to any amp, speaker or effects setting

VSeparate wah-wah effect can be controlled manually or via MIDI and is available in addition to any other

effects combination

VEffective 3-band EQ with amp model dependent characteristics

VNew presence control adjusts a high-frequency filter, simulating the negative feedback of tube amps

VExtremely low-noise—S/N ratio now 90 dB

VAdjustable stereo aux input for line-level signals (CD, drum box, sound card, MIDI backing etc.)

VStereo line output with virtual speaker simulation for recording and live applications

VFive new, practical configuration modes for various studio and live applications, some with additional

global 3-band EQ

VMaster volume control and stereo headphones output

VExtensive MIDI implementation allows complete real-time remote control and automation, data transfer

and access to additional parameters

VBuilt-in auto-chromatic tuner

VTap-tempo function allows real-time adjustment of effects speed parameter

VProfessional noise reduction system on board

VGig bag and dual footswitch for preset selection and tuner control included

VThe V-AMP is protected by US patents No. D444,169 and D444,493

VManufactured under ISO9000 certified management system

V-AMP 2

SPECIFICATIONS

AUDIO INPUTS

Guitarinput 1/4" mono phone jack, unbalanced

Input impedance approx. 1 MΩ

Aux inputs 1/4" stereo connector, balanced

Input impedance approx. 50 kΩ

AUDIO OUTPUTS

Line outputs 1/4" stereo connector, balanced

Output impedance approx. 2 kΩ

S/N ratio 90 dB @ preamp bypass

Headphones 1/4" stereo phone jack

MIDI INTERFACE

Type 5-pos. DIN jacks IN / OUT

DIGITAL PROCESSING

Converters 24-Bit Delta-Sigma, 64/128 oversampling

Sampling rate 31.250 kHz

DSP 100 Mips

Delay time max. 1,933 ms

DISPLAY

Type 2-digit numeric LED

POWER SUPPLY

Power consumption 13 W

DIMENSIONS/WEIGHT

Dimensions (H x W x D) approx. 2 1/2" (63 mm) x 9 1/4" (236 mm) x 7 1/8" (180 mm)

Weight approx. 1.2 kg

BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made, if necessary, without prior

notice. The specifications and appearance of the equipment may therefore differ from those listed or illustrated.

V-AMP 2

The information contained in this manual is subject to change without notice. No part of this manual may be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any

purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.

All the registered trademarks, names of musicians and groups are the property of their respective owners

and are in no way associated with BEHRINGER.

BEHRINGERandV-AMPareregisteredtrademarks.BEHRINGERInstrumentAmplificationisaDivisionofBEHRINGER.

BEHRINGERSpezielle StudiotechnikGmbH,Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany

Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
