Beeper X7R Instrucciones de uso
ALARM SYSTEM
TWO WHEELS
MOTOS & SCOOTERS INSTALLATION
& USE MANUAL
photo no contractual
2
USER MANUAL
Introduction
Thank you for using a product BEEPER for safety and comfort of your vehicle. BEEPER innovations are designed to ensure many years of
tranquility, they are guaranteed for 3 years. Our technical department is at your disposal for further information.
The alarm system BEEPER X7R is an electronic product that may require the skills of an electrician for installation. Even if the installation
is universal and without complexity, we advise you to call a professional electrician to avoid damaging your two wheels.
We want the product BEEPER X7R will bring you pleasure and improve the
safety of your vehicle.
MORE PRODUCTS, MORE INFO www.beeper.fr
Main functions
COMPOSITION
Bi-directional remote (x 1)
Remote mono-directional metallic finish (x 1)
Central waterproof and anti-vibration
Patented built-in shock sensor SHOCKLIFT ™
Micro-powerful 110 dB siren
LED status indication and deterrence
SAFETY FEATURES
Scope of the bike to alert the remote up to 500 m. (open)
Range of remote control motorcycle up to 60 m. (open)
Shock to detect two levels of alert
Anti-bike-jacking innovative (with pushbutton secret)
Cut engine integrated
Detecting anti-tilt and anti-lift SHOCKLIFT ™
2 alert levels when tilted, raised or shock of two wheels
Memory alarm system off
Emergency stop push button system secret
FUNCTIONS OF COMFORT
Secure remote start
Setting 4 sensitivity levels of shock and anti uprising
Memory mode: Back to the last active state of the system if disabling
Panic Mode: Search and location of the two wheels at a distance
3
Silent mode activation (siren nonfunctional)
Beep sound activation and deactivation (voidable if necessary)
Automatic reset after 60 seconds (programmable function)
Reprogramming of new remote for loss
Remote screen LCD backlit LCD multicolor
Additional remote control with 3 buttons, metallic finish
low power consumption
1 year warranty
REMOTE
Energy saving function (ed off the LCD)
Vibrating alarm (can be run in only vibrator)
Visual and audible alarm switch on / off (programmable)
Silent alert mode (warning only on the remote)
LED color and intensity depends on the type of alert status and
Different icons to identify the type of break
Icons on / off the alarm
Icon of vibration
Battery level icon
built-in clock
INSTALLATION
Easy and quick installation
100% Universal, installs on any and all motorcycle scooter
Connector Plug and Play for scooters / motorcycles from China.
4
INSTALLATION MANUAL
Precautions
Thank you observe the following before installing the system:
• This system is designed to be installed on a 2-wheel (motorcycle, scooter, quad, ...) with a 12 volt battery and an electric starter.
• The system runs on 12V DC (12V DC). Be sure the polarity of each wire.
• Check before installation if all elements of the car are working properly such as contact & motor starting, lighting codes, lights and headlights, turn signals, ... Check after
installing all these elements work.
• Do not connect the son by splice / solder without using lugs. The connections may create serious problems with the system and the vehicle also.
• When you connect the system's overall WEIGHT, it is very important that this mass is completely open and stable (no leaks).
• Ensure that every son passing in tight spaces are protected by adhesive tape to avoid excessive twisting and degradation of the plastic wire with risk of bad contacts.
• Ensure that the son of the system and all safety devices are best hidden in the vehicle as possible, never forget that you install a security system.
• Use a digital multimeter to identify each of the polarities of the son, using a test light to locate the wire Tachometer (if necessary).
Connection diagram
5
Red
Orange
Pink
Grey
Blue
Yellow
Yellow
White / Black
Black
to Starter
Case control or
original
Cut the wire bonding
from the CDI
(ECU ignition.) Never
cut the + APC (after
contact)
+12V battery
+12 V after-contact
Cut engine
Cut engine
Remote Start
Right turn
Left turn
Entry box car (-)
Mass
If the two wheels is automatic or has a
drive, connect this wire to a ground if the
two wheels at a mechanical gearbox plug it
into neutral information. If Absence of this
information. Do not connect the blue
remote start.
Fusible 12V
LED
deterrent
pushbutton
Emergency Stop
& Programming
electronic Siren Black
Blue / White
Output - 200 mA for control of a
transponder bypass for remote start.We
recommend that you contact our technical
department for more details
Start command:
. If the original startup is
controlled by a positive (most
common), connect the Red on
White
. If the startup is controlled by a
negative sign
Black on the White
White
Red
Black
Central
antenna
Do not cut
and do not connect
start over
to key
contact / Neiman
Installation of system components
• The plant must be concealed and placed in a location where it will not easily accessible and protected from splashing water and fuel.
• The siren should be placed in an open area for the passage of its maximum but protected from splashing water and fuel.
• The LEDs must be placed if possible all visible on the dashboard of the two wheels.
• The switch must be concealed but accessible by the owner with the two wheels.
• Connections and bundles must be concealed and not easily accessible.
6
Functions of the buttons on the remote
Two-way LCD remote Simple remote mono-directional
7
• Alarm Activation
with audible and
* light.
• Location 2
wheels with signal
sound and light.
• Panic Mode.
• How anti carjacking
• Disabling
the alarm signal
sound and light. *
•silent activation
of the alarm (without
beep)
• Location
silent two wheels
(no sound)
• Judgment of the siren
• Setting the Detector
SHOCKLIFT ™
• Remote Start
pressing this button
for 3 seconds
AC *ACTIVATION = 1 tone siren+ 1 blinking flash
*OFF = 2 beeps sirens + 2 flashing lights
• Alarm Activation
with audible and
light.*
• Location 2
wheels with signal
sound and light.
• Panic Mode.
• How anti carjacking
• Disabling
the alarm signal
sound and light. *
Enable silent
of the alarm (without
beep)
• Location
silent two wheels
(no sound)
• Judgment of the siren
• Setting the Detector
SHOCKLIFT ™
*ACTIVATION = 1 tone siren+ 1 blinking flash
*OFF = 2 beeps sirens + 2 flashing lights
System functions
Activation with light & buzzer (1)
When the system is off, press the button uonly once (short press <1 sec.), the siren will beep once, blinkers flashing
a time. The remote will beep one time, the LCD screen on the remote glows green. The system will activate 3 seconds
later. The remote screen will display the icons as shown against (1)
Silent activation (2)
When the system is off, press the only once (short press <1 sec.), blinkers flashing one time. The remote will beep
one time, the LCD screen on the remote glows green. The system will activate 3 seconds later. The remote screen will
display the icons as shown against (2)
Panic mode and / or Location of two wheels (beep & light)
This function is twofold, it can alert mode panic: if someone assaults you while you are near your two wheels. It also
allows to remotely locate the two wheels.
When the system is activated with light and sound signals, press the button once (short press <1 sec.), the siren
will beep for 30 seconds, turn signals flashing for 30 seconds.The remote will beep 3 times,the LCD screen on the remote
glows green.
Localization of light signal with two wheels only
When the system is activated with light and sound signals, press the once (short press <1 sec.), blinkers flashing 6
times. The remote will beep 3 times, the LCD screen on the remote glows green.
8
(1)
(2)
Judgment of the siren
When the siren sounded after the system has detected an attempted break-in, press one of three buttons: or or once (short press <1 sec.), the siren stops and
system returns to the active mode after 3 seconds.
Desactivation (3)
When the system is activated, press the once (short press <1 sec.), turn signals will flash 2 times. The remote will beep
2 times, the LCD screen on the remote turns red.The system will be deactivated immediately.
If the siren sounds, pressing the button to stop the siren and disarm the system simultaneously.
The remote screen will display the icons as shown against (3)
Anti hi-jacking = anti-steering
This function is used to alert and block the two wheels when turning when you are close to the two wheels.
If the owner of two wheels is pointing while driving, press the for 3 seconds while the remote is in range with the two wheels (max. = 50 m. in open field), turn signals
will flash 3 times and the remote beeps three times.
PHASE I -> 10 seconds (the two left wheels), the siren starts to beep sound quickly. During this phase I, it is possible to stop the anti hi-jacking by pressing
PHASE II -> 30 seconds later, the siren starts to ring non-stop and the engine is turned off. Be confirmed in legislation
in your country. To exit the mode while anti hi-jacking, you must press the button 5 times of emergency concealed
(ask your installer to the location)
Adjusting the sensitivity of the detector SHOCKLIFT ™ (4)
The integrated sensor SHOCKLIFT ™ adjusts to 4 levels. Press the button for 3 seconds to select the sensitivity level.
The factory is on level 3. Level 1 = off sensor Level 2 = Low Sensitivity
The screen appears as shown against (4) Level 3 = average sensitivity Level 4 = high sensitivity
9
(3)
(4)
Remote Start (5)
When the alarm is activated, press the for 3 seconds, the system will remote start on 2 wheels. The siren beeps 3 times. Two wheels
of the engine starts, to confirm the correct engine start, the siren sounds 3 beeps again. The remote is flashing icon engine 4 times to
indicate that the motor turns the wheels 2. The screen on the remote LCD shows the icons as shown against (5).The remote control will
be illuminated in red to indicate the engine is running.
After remote start, the engine continues to run for 8 min. then shuts off and the system returns to normal activated alarm.
If you want to stop the engine during this phase of 8 min., Press the , siren and remote bipent 2 times and the remote beeps two
times. The motor stops.
On failure of remote start, possible causes are:
. the battery is too low, you need to replace or recharge your battery,
. the engine is cold and requires activation of the starter for power-up.
Impact detection sensor by SHOCKLIFT ™ (6)
If the system detects a collision, the siren will beep 5 times, turn signals will flash 5 times, the remote beeps for 15 seconds. The remote
vibrates 4 times to recall the shock to the owner of two wheels., The remote screen turns red.
If another shock is detected within 30 seconds, the siren sounded for 30 seconds, turn signals flashing for 30 seconds, the remote beeps
for 15 seconds. The screen on the remote LCD shows the icons as shown against (6)
Inclination detection / Sensor heave SHOCKLIFT ™ (7)
If the system detects an inclination or an uprising, the siren will beep 12 times, turn signals will flash 5 times, the remote beeps for 15
seconds and the display shows 333. The remote vibrates 4 times to remind the owner of detection 2 wheels., The remote screen turns
red.
If a strong or fast inlcinaison is detected, the siren sounded for 30 sec., Turn signals flashing for 30 seconds, the remote beeps for 15
seconds and the display shows 333.. The screen on the remote LCD shows the icons as shown against (7)
10
(5)
(6)
(7)
