1Unboxing

1.1 In the box

•Argos3D–P23x

•CAT5/7 Ethernet Cable

•Interface Breakout-Board

•Quick Start Guide

•Power Supply

Note

The power supply’s operating temperature is specified from 0 to +40°C. This represents not

the effective working temperature of the Argos3D–P23x sensor!

1.2 Connecting your Argos3D–P23x

1.3 Connector Overview

The Argos3D-P23x uses one common connector for power and interfaces. For test purposes the KIT contains a

breakout-board to have individual access to the interfaces of the Argos3D-P23x.

The break-outboard has three main interfaces:

a. Power Connector

b. Ethernet

c. Argos3D-P23x common connector

Figure 1-1: Argos3D–P23x break-out board front and rear view

6| 15

Quick Start Guide - Argos3D-P23X

Last change: 30 January 2019/Version 2

Note

Please follow the next steps in the right order to get your ‘Argos3D-P23x’ up and running

correctly.

1.3.1 Connecting the break-out board

Please connect the break-out board to the Argos3D-P23x common connector first.

Figure 1-2: Argos3D–P23x common connector

1.3.2 Connecting the power supply

To ensure, that your Argos3D–P23x works correctly, connect the ‘Argos3D’ to a 12-30V DC power supply using

connector (a) and wait for approximately 20 seconds until the camera boots up.

Pin assignment on the power connector (a): Pin #1: +12V to +30V, Pin#2: GND

Note

The power supply connector is protected against wrong polarity but the ‘Argos3D’ will not

work in case you don’t use the correct polarity! If the Argos3D–P23x doesn’t work please

check the power supply polarity first!

7| 15

Quick Start Guide - Argos3D-P23X

Last change: 30 January 2019/Version 2

1.3.3 Connecting the Ethernet Cable

Plug in the Ethernet cable (b) and connect your Argos3D–P23x to your PC.^

Figure 1-3: Argos3D–P23x connected to power and Ethernet

8| 15

Quick Start Guide - Argos3D-P23X

Last change: 30 January 2019/Version 2

2Downloading the Evaluation Software

Please log in to our support website at https://support.bluetechnix.com/ and download the Argos-P23x customer

software package. This package also includes the Bluetechnix ToF-Suite.

2.1 Support website

Select ‚free access‘

Figure 2-1: Download Evaluation Package

9| 15

Quick Start Guide - Argos3D-P23X

Last change: 30 January 2019/Version 2

2.2 Start-up screen

Figure 2-2: Start-up screen

Please select your product Argos3D-P23x.

Please follow the instructions on the website.

10 | 15

Quick Start Guide - Argos3D-P23X

Last change: 30 January 2019/Version 2

2.3 Prepare your Network Interface Card (NIC)

Once you have connected your Argos3D–P23x to a Network Interface Card (NIC) of your PC give this NIC the IP-

Address 192.168.0.1 with a subnet mask of 255.255.255.0.

No driver must be installed on your PC!

The Argos3D–P23x uses IP-Address 192.168.0.10 with subnet mask 255.255.255.0.
