Beamz LCB99 LED BAR Manual de usuario

LCB99 LED BAR

150.711 V1

On the label on the backside of the unit is indicated on this type of power supply must be connected. Check that the mains voltage corresponds to this, all

other voltages than specified, the light effect can be irreparably damaged. The product must also be directly connected to the mains and may be used. No

dimmer or adjustable power supply.

Always connect the unit to a protected circuit (circuit breaker or fuse). Make sure the unit has an appropriate electrical ground to

avoid the risk of electrocution or fire.

The unit may be set up on a stable and even surface. By means of the fixing facilities of the baseplate, the unit can also be mounted upside down to a truss,

see below picture. For fixing, certified clamps with correct save working load are required. According to the figure, the quick lock bolts of the omega

brackets are placed into the openings provided in the base plate and turned clockwise until they lock (to the stop). The mounting place must be of

sufficient stability and be able to support a weight of 10 times of the unit’s weight. Secure the unit with a safety cable so that it cannot fall down.

When carrying out any installation, always comply European and national guidelines concerning rigging, truss and all other safety issues. Always let the

installation checked out by an authorized dealer !

If you are using a standard DMX controller, you can connect the DMX output of the controller directly to the DMX input of the first unit in a DMX chain.

Always connect the output of one unit with the input of the next unit until all units are connected.

At the last unit, you must close the DMX line with a terminating resistor. Take an XLR connector and solder a 120 Ohm resistor

between signal (-) and signal (+) and connect it to the DMX output of the last unit in the line.

A001-Axxx

Auto-run mode

Au1-32

Pre program

FF01-99

Program with hopping effect

CC01-99

Program with fade effect

EE01-99

Program with jump effect

F000-255

Strobe from slow to fast

r000-255

Red manual adjustment

g000-255

Green manual adjustment

b000-255

Blue manual adjustment

u000-255

White manual adjustment

I000-255

UV manual adjustment

Auto

Auto run

SOUD

uoL1-9

Sound sensitivity adjustment

bAon / bAof

Sound mode on/off

Master dimmer

000-255

Dimming 0-100%

Colour

000-255

Red, 0-100%

000-255

Green, 0-100%

000-255

Blue, 0-100%

000-255

White, 0-100%

000-255

UV, 0-100%

Strobe

000-009

No function

010-255

Strobe, slow to fast ( CH1 must be on and select the colour CH2 till CH6)

Mode

000-010

No function

011-070

Program with hopping effect

071-130

Program with fade effect

131-190

Program with pulse effect

191-255

Sound mode
