BDCOM S3756F

Hardware Installation Manual

Table of Contents

- I -

Table of Contents

Table of Contents................................................................................................................................ I

Chapter 1 BDCOM S3756F Switch...................................................................................................1

1.1 Appearance Description for Standard Configuration............................................................1

1.2 BDCOM S3756F Systematic Characteristic Parameters.....................................................2

1.3 ROHS Description................................................................................................................ 4

Chapter 2 Installation Preparation.....................................................................................................5

2.1 Caution of Usage ................................................................................................................. 5

2.2 Safety Advice .......................................................................................................................5

2.2.1 Safety Principles ........................................................................................................ 5

2.2.2 Safety Notices............................................................................................................ 5

2.2.3 Safety Principles for Live Working.............................................................................6

2.2.4 Electrostatic Discharge Damage Prevention ............................................................. 7

2.3 Requirements for Common Locations ................................................................................. 7

2.3.1 Environment...............................................................................................................7

2.3.2 Location Configuration Prevention.............................................................................7

2.3.3 Cabinet Configuration................................................................................................8

2.3.4 Power Requirements .................................................................................................8

Power Requirements ..........................................................................................................8

2.4 Installation Tools and Device................................................................................................ 8

Chapter 3 Installing the S3756F Switch..........................................................................................10

3.1 Installation Flow of BDCOM S3756F .................................................................................10

3.2 Installing the Machine Box of the Switch ........................................................................... 10

3.2.1 Installing the Machine Box on the Desk...................................................................10

3.2.2 Installing the Machine Box on the Cabinet .............................................................. 11

3.3 Connecting the Port ........................................................................................................... 11

Table of Contents

- II -

3.3.1 Connecting the Console Port................................................................................... 11

3.3.2 Connecting 10G Ethernet SFP+ Ports..................................................................... 13

3.3.3 Connecting Gigabit Ethernet TX Ports.....................................................................14

3.3.4 Connecting Gigabit SFP Ports.................................................................................15

1.4 Checking after Installation..................................................................................................15

Chapter 4 Maintaining Switch..........................................................................................................17

4.1 Opening the Machine Box..................................................................................................17

4.2 Closing Machine Box .........................................................................................................18

Chapter 5 Hardware Fault Analysis................................................................................................. 19

5.1 Fault Separation.................................................................................................................19

5.1.1 Faults Relative with Power and Cooling System.....................................................19

5.1.2 Faults Relative with Port, Cable and Connection ....................................................19

5.2 Indicator Description ..........................................................................................................20

BDCOM S3756F Hardware Installation Manual

- 1 -

Chapter 1 BDCOM S3756F Switch

The section describes the characteristics and parameters of BDCOM S3756F and gives an

overview of BDCOM S3756F.

1.1 Appearance Description for Standard Configuration

The built-in ports of BDCOM S3756F are: 4 gigabit combo ports, 44 gigabit Ethernet optical

ports, 8 10G Ethernet SFP+ ports, 1 Console port. See table 1-1.

Table 1-1 Attributes of the built-in port

Port

Attribute

Gigabit-Ethernet TX port

RJ45 port, LINK/ACT indicators

Gigabit-Ethernet SFP port

SFP interface: with LINK/ACT indicators

10G Ethernet SFP+ ports

SFP+ interface: with LINK/ACT indicators

Console port

A rate of 9600bps, mini USB.

Figure 1-1 The front template of the BDCOM S3756F switch

Table 1-2 Parts at the front template of BDCOM S3756F switch

No.

Abbrev.

Name

Description

4 gigabit Ethernet TX ports

COMBO port, UTP (RJ45) interface

48 gigabit Ethernet optical

ports

SFP interface, 1-4 are combo ports

Console

Console port

Manages the switch locally.

SYS

System indicator

If the indicator is always on, the system is

normally started up.

BDCOM S3756F Hardware Installation Manual

- 2 -

If the indicator flickers, the system works

normally.

PWR

Power indicator

If the switch is powered on, the indicator is

on.

Additionally, BDCOM S3756F has 8 10G optical ports, 1 grounding column, 1 power socket at

its back.

Figure 1-2 The back template of the BDCOM S3756F switch

Table 1-3 Parts at the back template of the BDCOM S3756F switch

No.

Abbrev.

Name

Description

TE1-TE8

10G Ethernet optical ports

SFP+ interface, with LINK/ACT

indicators.

The grounding column

The grounding column must be fine.

AC power socket

AC90～264V

1.2 BDCOM S3756F Systematic Characteristic Parameters

Protocol

standard

Supported standard

IEEE 802.1d Spanning Tree Protocol

IEEE 802.1s multiple spanning trees

IEEE 802.1p Class of Service

IEEE 802.1q tagged VLAN

IEEE 802.3x Flow control

IEEE 802.3z asymmetric flow control

IEEE 802.3ad Link aggregation

IP routing protocol standard

RFC 1058 RIP

RFC 1723 RIP v2

RFC 1583 OSPF v2

BDCOM S3756F Hardware Installation Manual

- 3 -

Network management standard

RFC 1157 SNMP v1/v2

RFC 1213 MIB II

RFC 1757 RMON 1,2,3,9

Hardware

Characteristics

Memory

Flash Memory: 16M Bytes

SDRAM: 512Mbytes;

Standard configuration

4 gigabit COMBO ports

44 gigabit Ethernet SFP ports

8 10G Ethernet SFP+ ports

1 Console port

Dimensions mm (W×D×H)

442.50×350×44

Operating temperature/humidity

-10℃～50℃; 10%～85% non-condensation

Storage temperature/humidity

-40℃～85℃; 5%～95% non-condensation

Power characteristics

Input voltage: AC90～264V, Input frequency:

47～63Hz

Input current:3A (MAX)

Output voltage: 12VDC

Output current: 12.5A(MAX)

Power consumption

80W

Weight

6.2KG

BDCOM S3756F Hardware Installation Manual

- 4 -

1.3 ROHS Description

BDCOM S3756F Hardware Installation Manual

- 5 -

Chapter 2 Installation Preparation

2.1 Caution of Usage

Similar to other electronic products, the semiconductor chip easily gets damaged if you power

on or off abruptly and frequently. To restart up the switch of BDCOM S3756F, you have to open the

power on-off after the power is cut down for three to five seconds.

Avoid severe collision or falling down from the height to protect the parts in the switch.

Use correct outside ports to connect the switch of BDCOM S3756F. Do not put the Ethernet

plug into the console port (RJ45 8-line socket). Similarly, do not put the console cable into the

console port (RJ45 8-line socket).

Note:

1) When you plug or dial the power line, keep the power line horizontal with the power socket.

2) When the lifetime of our products ends, handle them according to national laws and

regulations, or send these products to our company for collective processing.

2.2 Safety Advice

2.2.1 Safety Principles

Keep dustless and clean during or after the installation.

Put the cover at the safe place.

Put tools at the right place where they are not easily falling down.

Put on relatively tight clothes, and fasten the tie or scarf well and roll up the sleeve,

avoiding stumbling the machine box.

Put on the protective glasses if the environment may cause damage to your eyes.

Avoid incorrect operations that may cause damage to human or devices.

2.2.2 Safety Notices

The safety notices mentioned here means that improper operation may lead to body damage.

BDCOM S3756F Hardware Installation Manual

- 6 -

Read the installation guide carefully before you operate the system.

Only professionals are allowed to install or replace the switch.

Pull out the AC power socket and close the direct-current power before operating on

the machine box or working beside the power source.

The final configuration of products must comply with relative national laws and

regulations.

2.2.3 Safety Principles for Live Working

When you work under electricity, following the following principles:

Put off ornaments, such as ring, necklace, watch and bracelet, before you operate

under live working. When metal articles connect the power to the ground, short

circuit happens and components may be damaged.

Pull out the AC power socket and close the direct-current power before operating on

the machine box or working beside the power source.

When the power is on, do not touch the power.

Correctly connect the device and the power socket.

Only professionals are allowed to operate and maintain the device.

Read the installation guide carefully before the system is powered on.

Note:

1) Check potential dangers, such as the humid floor, ungrounded extensible power line

and tatty power line.

2) Install the emergent on-off at the working room for turning off the power when trouble

happens.

3) Turn off the power on-off of the switch and plug off the power line before installing or

uninstalling the machine box or working beside the power.

4) Do not work alone if potential dangers exist.

5) Cut off the power before checkout.

6) If trouble happens, take the following measures:

A. Cut off the system's power.

B. Alarm.

C. Take proper measures to help persons who are hit by the disaster. Artificial

respiration is needed if necessary.

D. Seek for medical help, or judge the loss and seek for available help.

BDCOM S3756F Hardware Installation Manual

- 7 -

2.2.4 Electrostatic Discharge Damage Prevention

Electrostatic discharge may damage devices and circuits. Improper treatment may cause the

switch to malfunction completely or discontinuously.

Move or locate the devices according to the measures of electrostatic discharge prevention,

ensuring the machine box connects the ground. Another measure is to wear the static-proof hand

ring. If there is no hand ring, use the metal clip with the metal cable to clip the unpainted metal part

of the machine box. In this case, the static is discharged to the ground through the metal cable of

the clip. You can also discharge the static to the ground through your body.

2.3 Requirements for Common Locations

This part describes the requirements for the installation locations.

2.3.1 Environment

The switch can be installed on the desk or the cabinet. The location of the machine box,

cabinet planning and indoor cabling are very important for normal system’s function.

Short distance between devices, bad ventilation and untouchable control plate will cause

maintenance problems, systematic faulty and breakdown.

For location planning and device locating, refer to section 2.3.2 “Location Configuration

Prevention”.

2.3.2 Location Configuration Prevention

The following preventive measures assist you to design the proper environment for the switch.

Make sure that the workshop is well-ventilated, the heat of electrical devices is

well-discharged and sufficient air circulation is provided for device cooling.

Avoid to damage devices by following the electrostatic discharge prevention procedure.

Put the machine box at the place where cool air can blow off the heat inside the machine

box. Make sure the machine box is sealed because the opened machine box will reverse

the cool air flow.

Tabla de contenidos

Otros manuales de Cambiar de Bdcom

Bdcom

Bdcom S3756P Instrucciones de montaje

Bdcom

Bdcom S1216 Instrucciones de montaje

Bdcom

Bdcom S3740 Manual de usuario

Bdcom

Bdcom S2928 Instrucciones de montaje

Bdcom

Bdcom S6508 Manual

Bdcom

Bdcom S1518-16P-330 Manual de usuario

Bdcom

Bdcom S2928F Instrucciones de montaje

Bdcom

Bdcom S2510PB Instrucciones de montaje

Bdcom

Bdcom S2518PB Instrucciones de montaje

Bdcom

Bdcom S2528-B Instrucciones de montaje

Bdcom

Bdcom S5612 Instrucciones de montaje

Bdcom

Bdcom S2510-C Instrucciones de montaje

Bdcom

Bdcom S2528PB Instrucciones de montaje

Bdcom

Bdcom S2928E Instrucciones de montaje

Bdcom

Bdcom S2528GX Instrucciones de montaje

Bdcom

Bdcom S2510-B Instrucciones de montaje

Bdcom

Bdcom S2952P Instrucciones de montaje

Bdcom

Bdcom S5864 Instrucciones de montaje

Bdcom

Bdcom S2956 series Instrucciones de montaje

Bdcom

Bdcom S2210PB Instrucciones de montaje

Bdcom

Bdcom S1010-8P-120 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
