BD FACSCanto II Manual de usuario

BD FACSCanto II Flow Cytometer

Quick Reference Guide

This guide contains instructions for both BD FACSCanto™ clinical and

BD FACSDiva™ software. Follow only those sections that apply to the

software you are running.

Starting Up

1Turn on the cytometer main power.

2Start up the computer, launch the software, and

3Make sure the software is connected to the cytometer; if needed,

connect manually (choose Cytometer or Instrument > Connect).

4Check fluid levels in the Status or Instrument window.

Empty the waste or replace fluid containers, if needed.

5If automatic cleaning is disabled, run the fluidics startup procedure.

6Check the flow cell for air bubbles; if needed, run the de-gas flow cell

procedure.

7Check that laser warmup has finished.

To prevent fluid overflow, make sure there is no tube on the sample

injection tube (SIT) during fluidics startup.

BD FACSCanto clinical software

BD FACSDiva software

BD FACSCanto clinical software

Daily Setup: BD FACSCanto Clinical Software

Set up the cytometer with BD FACSCanto clinical software, even if you will

optimize and run samples using BD FACSDiva software.

1Prepare BD FACS™ 7-color setup beads.

2Run the cytometer setup procedure for the bead lot you prepared.

Follow the Cytometer Setup Wizard to complete setup. When

prompted, install the tube containing the setup beads, or the rack

containing the beads tube and optimization samples.

3If you are running samples manually, unload the tube when prompted.

•Hold the tube while moving the aspirator arm to the left.

•Remove the tube from the SIT.

•Release the aspirator arm and wait for cleaning to finish.

4(Optional) When setup is complete, view and print the Setup Report.

5Click to optimize the settings, or click .

6Review the Levey-Jennings report for trends in the setup data.

Optimizing Instrument Settings: BD FACSCanto Clinical Software

Before you record data for a sample, optimize the detector voltages,

spectral overlap, and threshold settings for the sample type and

fluorochrome to be run.

1Follow the prompts on the screen to proceed with optimization.

•Click Yes to save results.

•Choose the panel type and the X and Y parameters, and click

•If you are using the Loader for optimization, click .

•Click at the Cytometer Setup Optimization screen.

•If you are running tubes manually, install the first optimization tube

when prompted, and click .

•Click .

2Optimize settings, if needed.

•To adjust the optimization gate, click , make the

needed adjustments, and then click .

•To adjust detectors, thresholds, or spectral overlap settings, click on

the corresponding tab and use controls to adjust the settings.

3If there are more tubes for that panel type, click , and then

Otherwise, click , and then view and print the Setup

Report for optimized settings.

4Click , remove the tube (if prompted), and then click .

Optimizing Instrument Settings: BD FACSDiva Software

Before you record data for a sample, optimize the PMT voltages, compensation,

and threshold settings for the sample type and fluorochrome.

1Verify the instrument configuration.

2Create an experiment.

3Select the experiment-level settings, and change, add, or delete

parameters as needed.

4Apply setup results.

•Right-click the experiment-level settings, and choose Apply Setup.

•Select a setup, and click Apply.

5Create compensation controls; click OK to remove the setup link.

•If needed, edit labels for the Compensation Controls.

6Optimize instrument settings using an unstained control sample.

•Place the current tube pointer next to the unstained control tube,

install the tube, and click .

•Adjust FSC and SSC voltages, and the FSC threshold, if needed.

•On the Unstained Control worksheet, adjust the P1 gate, and apply

gate changes to the remaining compensation controls.

•Set the fluorescence histograms to show grids for each log decade.

•Optimize the voltages to place the negative population for each

fluorescent parameter within its first log decade.

7Click ; remove the unstained control tube when

recording is finished.

8Record data for each single-stained control.

9Adjust the gates around the positive populations on the histogram for

each stained control tube.

10 Calculate compensation, and name the resulting setup.

Running Samples: BD FACSCanto Clinical Software

1Prepare a worklist.

2Install the first sample tube (manual acquisition) or the Loader rack

(automated acquisition), and click .

3When asked if you want to save the worklist, click No.

4(Loader option only) Click to run tubes manually.

5(Optional) To optimize settings during initial acquisition, click ,

and then .

Adjust settings, and click to resume.

6For manual acquisition, remove the sample tube when prompted and

install the next tube; repeat until data for all tubes has been recorded.

7Inspect the lab report for each sample on the worklist.

Double-click the Status field to see a sample’s report.

Running Samples: BD FACSDiva Software

1Create a new specimen and tubes; rename them appropriately.

2Create a global worksheet and rename it.

3Use Experiment Layout to define tube labels and enter events to record.

4On the global worksheet, create appropriate plots.

5Install the first tube onto the cytometer; acquire data for the

corresponding tube in the Browser.

6While data is being acquired, draw a gate around the population of

interest; set the other plots to show data from this population.

7Click ; remove the tube when recording is finished.

8Install the next tube.

9Repeat until data has been recorded for all tubes.

Shutting Down: BD FACSCanto Clinical Software

1Create a worklist with a two-tube panel; enter Clean as the Sample ID.

2Click ; when asked to save the worklist, click No.

3(Loader option only) Click to run tubes manually.

4When prompted, install a tube containing ≤3 mL of BD™ FACSClean

solution or 10% bleach.

5Click . Wait 5 minutes, and then click .

6When prompted, unload the tube.

7Install a tube with ≤3 mL of DI water; repeat steps 5 and 6.

8Choose File > Exit, and select Run fluidics shutdown and exit.

9When fluidics shutdown completes, turn off the power.

Shutting Down: BD FACSDiva Software

1Install a tube with ≤3 mL of BD FACSClean solution or 10% bleach,

and click .

2After 5 minutes, click and remove the tube.

3Repeat steps 1 and 2 with DI water.

4Run fluidics shutdown.

5Turn off the instrument main power.

To prevent fluid overflow, do not leave a tube on the SIT during fluidics

shutdown.

To prevent fluid overflow, do not leave a tube on the SIT during fluidics

shutdown.

BD, the BD logo, BD FACS, BD FACSDiva, and BD FACSCanto are trademarks of Becton, Dickinson and Company.

http://bdbiosciences.com/

BD Biosciences

2350 Qume Drive

San Jose, CA 95131-1807

USA

Tel (877) 232-8995

Fax (408) 954-2347

Mexico

Tel (52) 55-5999-8296

Fax (52) 55-5999-8288

Japan

Nippon Becton Dickinson

Tel 0120-8555-90

Canada

Tel (888) 259-0187

Fax (905) 542-9391

(905) 542-8028

[email protected]

Asia Pacific

Fax (65) 6-860-1590

Tel (65) 6-861-0633

Brazil

Tel (55) 11-5185-9995/9941

Fax (55) 11-5185-9895

BENEX Limited

Bay K 1 a/d

Shannon Industrial Estate

Shannon, County Clare

Tel (353) 61-472920

Fax (353) 61-472546

Ireland

Company, Ltd.

Europe

Tel (32) 53-720211

Fax (32) 53-720450

REPEC

IVD

For In Vitro Diagnostic Use

BD FACSCanto Clinical Software Toolbars

BD FACSDiva Software Toolbars

Standard toolbar Worklist toolbar

logout new acq.

worklist

new anal.

worklist

open

worklist

save print run pause stop skip stop

recording

optimize

Workspace toolbar Browser toolbar

Save

Browser

Plate Inspector Acq. Dashboard

Instrument Worksheet Biexp. Editor

New Folder New Plate

New Expt

New Specimen

New Tube

New Inst

New Global

Settings

Worksheet

Number

of Wells

Worksheets

View

Select

Dot

Plot

Contour

Plot

Histogram

Worksheet toolbar

Zoom

Out

Increase

Plot Size

Decrease

Plot Size

Autopolygon

Gate

Snap-To

Gate

Polygon

Gate

Rectangle

Gate

Quadrant

Gate

Interval

Gate

Autointerval

Gate

Snap-To

Interval

Gate

Arrow

Line

Text

Align

Left

Align

Right

Align

Top

Align

Bottom

Distribute

Horizontally

Distribute

Vertically

Make

Same

Size

640772
