BayTech RPC-2 Manual de usuario
OWNER’S MANUAL
_________________
BAYTECH
REMOTE POWER CONTROL UNIT
FOR MODELS
RPC-2
RPC-2A
RPC-2 MD01
RPC-2 RDR
RPC-3
RPC-3A
RPC-5
BayTech Manual Publication #U140E125-03
July 1998
ii
Copyright 1998 by Bay Technical Associates, Inc.
BayTech, Telplex, LaserShare, Print Master and TRAN-X are
registered trademarks of Bay Technical Associates, Inc.
IBM, IBM PC, IBM PC/AT, IBM PC/XT are products and registered
trademarks of International Business Machines Corporation.
Hewlett-Packard LaserJet is a product and registered trademark of the
Hewlett-Packard Company.
PROCOMM PLUS is a product and registered trademark of Datastorm
Technologies, Inc.
RPC SERIES OWNER’S MANUAL
ABOUT THIS OWNER’S MANUAL
________________________________________________________________________________
iii
ABOUT THIS OWNER’S MANUAL
This document provides information required for installing and operating
your Bay Tech equipment. It should allow the user to connect, power
up, and access an applications menu where peripheral equipment can be
controlled. We recommend reading this manual carefully, while placing
special emphasis on correct cabling and configuration. If you have any
problems with your installation, please contact a BayTech Applications
Engineer at 228-467-8231, call toll free from anywhere in the United
States using 1-800-523-2702 or contact us at our Web Site,
www.baytechdcd.com.
BayTech manufactures many remote site management products, data
switches, data collection multiplexers, remote power controllers, and
peripheral print sharers. If you would like information on any of these
products, please contact BayTech Customer Service at the numbers
previously listed.
Conventions used in this manual include:
CAUTION: This term is used to denote any condition that could
possibly result in physical harm to personnel or damage to
equipment.
IMPORTANT: This term is used to denote conditions that could
result in the loss of communications or to highlight the proper
functioning of equipment.
NOTE: This term is used to denote items of interest to the user.
<cr>: Carriage Return or ENTER
RPC SERIES OWNER’S MANUAL
ABOUT THIS OWNER’S MANUAL
________________________________________________________________________________
iv
The information in this document is subject to change without notice. The
statements, configurations, technical data, and recommendations in this
document are believed to be accurate and reliable, but are presented
without express or implied warranty. Users must take full responsibility
for their applications of any products specified in this document. The
information in this document is proprietary to Bay Technical Associates,
Inc.
In the interest of improving internal design, operational function, and/or
reliability, Bay Technical Associates, Inc reserves the right to make
changes to the products described in this document without notice.
Bay Technical Associates, Inc does not assume any liability that may
occur due to the use or application of the product(s) or circuit layout(s)
described herein.
This manual replaces BayTech Publication U140E125-02.
We welcome any comments you may have about our products, and we
hope that you will continue to look to BayTech for your data
communication needs.
v
RPC-2 AND RPC-2A QUICK START.........................................................................2
RPC-2 MD01 AND RPC-2 RDR QUICK START.......................................................5
RPC-3, RPC-3A, AND RPC-5 QUICK START...........................................................8
UNPACKING..............................................................................................................12
PREPARING THE INSTALLATION SITE...............................................................12
POWER..................................................................................................................13
POWER ON/OFF STATE......................................................................................14
POWER UP SEQUENCE ......................................................................................14
CIRCUIT BREAKER.............................................................................................14
RPC-2 AND RPC-2A..................................................................................................19
LOCAL ACCESS USING THE EIA-232 SERIAL CONNECTION.....................19
OPERATION..........................................................................................................20
ACCESSING MAIN MENU.............................................................................21
CONTROLLING RECEPTACLES...................................................................21
CONFIGURATION ...............................................................................................22
CHANGE PASSWORD....................................................................................23
DISABLING A PASSWORD............................................................................24
CHANGE OUTLET NAME..............................................................................24
ENABLE/DISABLE CONFIRMATION ..........................................................25
ENABLE/DISABLE STATUS MENU.............................................................26
RPC-2 MD01 AND RPC-2 RDR................................................................................27
LOCAL ACCESS USING THE EIA-232 PORT...................................................27
REMOTE ACCESS USING MODEM CONNECTIONS .....................................28
OPERATION..........................................................................................................29
ACCESSING MAIN MENU.............................................................................29
CONTROLLING RECEPTACLES...................................................................30
ACCESSING MAIN MENU VIA MODEM.....................................................31
CONFIGURATION ...............................................................................................32
CHANGE PASSWORD....................................................................................33
DISABLING A PASSWORD............................................................................34
vi
CHANGE OUTLET NAME..............................................................................34
RPC-3, RPC-3A, AND RPC-5....................................................................................36
LOCAL ACCESS USING THE EIA-232 PORT...................................................37
REMOTE ACCESS USING THE NETWORK PORT..........................................37
OPERATION..........................................................................................................38
ACCESSING MAIN MENU.............................................................................39
OUTLET CONTROL........................................................................................40
MANAGE USERS.............................................................................................42
ADD USER ................................................................................................................43
DELETE USER..........................................................................................................43
CHANGE PASSWORD.............................................................................................44
CHANGE OUTLET LIST..........................................................................................46
CONFIGURATION ...............................................................................................47
IP ADDRESS.....................................................................................................47
SUBNET MASK ...............................................................................................48
GATEWAY .......................................................................................................48
UNIT ID.............................................................................................................49
ACCESS ............................................................................................................49
OUTLETS..........................................................................................................50
OUTLET STATUS DISPLAY...................................................................................51
COMMAND CONFIRMATION................................................................................51
OUTLET POWER-UP DELAY.................................................................................51
NAME OUTLETS......................................................................................................52
DISPLAY OUTLET USER........................................................................................54
UNIT STATUS.......................................................................................................54
SYSTEM STATUS............................................................................................55
NETWORK INTERFACE.................................................................................55
LOGGED USERS..............................................................................................56
OUTLET STATUS............................................................................................57
RESET UNIT .........................................................................................................57
COMMAND SUMMARY .....................................................................................57
EQUIPMENT SETUP.................................................................................................60
!
!"
#$ !
#% !&
vii
#$ !
#$ &'
#$ &"
# (
RPC SERIES OWNER’S MANUAL
INTRODUCTION TO THE RPC SERIES
________________________________________________________________________________
1
INTRODUCTION TO THE REMOTE
POWER CONTROL SWITCH (RPC)
The BayTech RPC-Series is a full-featured AC power management
solution that provides an easy way to control power of remote equipment.
From your office or from anywhere, the RPC will TURN ON, TURN
OFF, OR REBOOT remote equipment.
There are six different RPC models. Four models operate at 115 VAC, 15
Amp. Two models operate at 230 VAC, 10 Amp.
115 VAC, 50/60 Hz, 15 Amp
RPC-2: Six receptacles and an EIA-232 connection.
RPC-2 MD01: Six receptacles, EIA-232 connection, and a
2400 bps Modem.
RPC-2 RDR: Six receptacles, EIA-232 connection, and
Ring Detect Reset.
RPC-3: Eight receptacles, Ethernet and EIA-232
connections.
RPC-5: Four receptacles (15 amps per receptacle),
Ethernet and EIA-232 connections.
230 VAC, 50/60 Hz, 10 Amp
RPC-2A: Six receptacles and an EIA-232 connection.
RPC-3A: Eight receptacles, Ethernet, and EIA-232
connections.
RPC SERIES OWNER’S MANUAL
RPC SERIES QUICK START (RPC-2 AND RPC-2A)
________________________________________________________________________________
2
RPC SERIES QUICK START
“Quick Start” is designed for users familiar with BayTech products who
need a fast setup and familiarization. Detailed information on each of the
functions and steps of operation and configuration may be found
beginning at pages 19, 27, and 36 of this manual. Each “Quick Start” will
discuss similar models.
RPC-2 AND RPC-2A QUICK START
EIA-232 serial Using the 9FRJ45PC-1 adapter and the
connection RJ08X007 cable, connect the serial port of
your computer to the RJ-45 port labeled
“EIA-232.”
Load serial port communications software.
Set serial communications parameters to
9600 bps, 8 data bits, 1 stop bit, and no
parity.
OPERATION
Accessing Main Menu Power on the RPC unit. The following status
menu appears:
RPC-2 Series
(C) 1997 by BayTech
F2.07
Circuit Breaker : On
1) . . . OUTLET 1 : Off
2) . . . OUTLET 2 : Off
3) . . . OUTLET 3 : Off
4) . . . OUTLET 4 : Off
5) . . . OUTLET 5 : Off
6) . . . OUTLET 6 : Off
RPC >
RPC SERIES OWNER’S MANUAL
RPC SERIES QUICK START (RPC-2 AND RPC-2A)
________________________________________________________________________________
3
If the status menu fails to appear, ensure
the correct cables and adapters are being
used and that they are connected properly.
Also, verify the serial communication
parameters are correctly configured.
Controlling Receptacles To set or change the status of the
receptacles, enter one of the following
commands: ON n, OFF n, REBOOT n,
where “n” is the outlet number you want to
command. Entering an outlet number of
“0” sends the command to all outlets.
Reboot only works on outlets which are in
the “ON” condition.
CONFIGURATION Type “CONFIG” from the RPC> prompt.
The following menu appears:
For the RPC-2:
RPC >CONFIG
1) . . . Change Password
2) . . . Change Outlet Name
Enter Request:
Or for the RPC-2A:
RPC > CONFIG
1) . . . Change Password
2) . . . Change Outlet Name
3) . . . Enable/Disable Confirmation
4) . . . Enable/Disable Status Menu
X) . . . Exit
Enter Request:
Este manual sirve para los siguientes modelos
6
Tabla de contenidos
Otros manuales de Unidad de control de BayTech
Manuales populares de Unidad de control de otras marcas
Festo
Festo Compact Performance CP-FB6-E Manual de lista de piezas
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manual de usuario
JS Automation
JS Automation MPC3034A Manual de usuario
JAUDT
JAUDT SW GII 6406 Series Guía rápida
Spektrum
Spektrum Air Module System Manual de usuario
BOC Edwards
BOC Edwards Q Series Manual de usuario
