Baxi Platinum Combi HE A Manual de referencia

Introducing the Platinum Combi HE Aboiler

www.baxi.co.uk

We understand that when you buy a new

boiler, it is a considerable investment.

If you’re looking for significant savings on

your heating bills, look no further than the

Baxi Platinum Combi HE A.

So ask your installer to fit you a Baxi boiler.

Aboiler that won’t

let you down or

cost the earth

Why choose Baxi?

Even if your existing boiler is still working well, replacing it could

make perfect sense.Afully functioning, regularly serviced boiler

that’s 10 years old could cost you around £225* more in annual fuel

bills than a new model.

The new Baxi Platinum Combi HE A is over 91% efficient** which

means that it offers significant savings on your fuel bills and will

lower your home’s carbon emissions, making it an economically

and environmentally sound choice. It’s also Energy Saving Trust

Recommended and comes with a five year parts and labour

warranty as standard. Fitting a Baxi boiler is all about giving yourself

peace of mind.

The Baxi Platinum Combi HE Aalso has a stylish contemporary look

that suits all surroundings and has easy to use controls with a built

in timer fitted as standard.

Afirm favourite with homeowners and installers alike, Baxi is one

of Europe’s largest and longest established boiler manufacturers.

We began producing boilers over 150 years ago – that’s before

the motor car or electric light – so we know a thing or two about

quality heating. We’re very proud of our long heritage of quality and

innovation and that we continue to manufacture here in the UK.

Baxi boilers are designed to operate at maximum efficiency

throughout their lifetime, giving you a lifetime of reliability and

cost savings. They also reduce carbon emissions which helps the

environment too.

www.baxi.co.uk

For all enquiries please call 0844 871 1525 or email: [email protected]

* Compared with a SEDBUK 2005 >90% rated high efficiency boiler.

Source: Energy Savings Trust, www.est.org.uk

** SEDBUK 2005

Combi boilers provide central heating and

give you plenty of instant hot water as soon

as you turn on the hot tap. This means

they’re economical to run, as hot water is

only produced when you need it. What’s

more, there’s no need for a tank in the loft

or a hot water storage cylinder... perfect if

space is at premium.

Why choose

a combi boiler?

For all enquiries please call 0844 871 1525 or email: [email protected] www.baxi.co.uk

Why choose the Baxi Platinum Combi HE A?

With its reliability, five year warranty and

ease of installation, the Baxi Platinum Combi

HE Ahas become a popular choice with

householders and installers alike.

Whether your home has five radiators or

25, there is a Baxi Platinum Combi HE A

boiler capable of heating them. Each one is

designed to look good wherever it’s installed

and has easy to use controls.

The boiler is highly efficient to help you save

energy and reduce fuel bills. It has been

designed so it is straightforward to install

and easy to service and maintain, helping you

save even more money throughout the entire

life of the boiler.

Why choose the

Baxi Platinum Combi HE A

Baxi Platinum Combi HE Aboiler

Class leading hot water flow rates for

increased comfort and convenience

User friendly controls with clear, easy

to read display

Awide range of outputs to suit all

heating and hot water requirements

Five year parts and labour warranty

for added peace of mind

Energy Saving Trust Recommended

Support from our service division

heateam

We’re behind you

all the way

Once your new boiler has been installed, you

can look forward to many years of heating

and hot water comfort. Our award-winning

customer service division, heateam, will be on

hand throughout the lifetime of your boiler to

ensure it is running at maximum efficiency and

saving you money year on year.

With 270 Gas Safe registered engineers and

our customer contact centre open 363 days a

year you can rest assured that we’ll always be

there for you.

For all enquiries please call 0844 871 1525 or email: [email protected] www.baxi.co.uk

Accessories and controls

Need an installer?

Additional heating and hot water controls

can improve the overall performance of

your heating system by as much as 13%*,

dramatically reducing the amount of fuel

you use – and the amount you pay.

For more information please speak to your

installer as they will be able to advise you

on the controls that are right for you.

If you need an installer to fit your new

Baxi boiler, we can help.

Visit www.baxi.co.uk

or call 0844 871 1525

* EuP Directive drafts

Technical specifications and clearances

Baxi Platinum Combi HE ASeries:

Wall mounted high efficiency combination boilers Platinum Combi HE A

24kW Platinum Combi HE A

28kW Platinum Combi HE A

33kW Platinum Combi HE A

40kW

Performance

Heat Output CH Non Condensing kW Max

(70oMean) kW Min 20

6.8 24

8.7 28

9.4 32

9.6

Heat Output CH Condensing kW Max

(40oMean) kW Min 21

7.4 25.9

9.5 30.3

10.2 34.3

12.1

Heat Output Domestic Hot Water kW Max 24 28 33 40

Maximum Domestic Hot Water Flow Rate l/min @ 35oC Rise 9.8 11.5 13.5 16.4

SEDBUK 2005 Seasonal Efficiency NG/LPG % 91.1 91.1 91.1 91.1

SEDBUK 2009 Seasonal Efficiency NG/LPG % 89.0 89.0 88.9 88.9

NOx Class 5555

200mm Min*

780mm

450mm

200mm Min

(300mm Min if

using 80/125mm

ueing system)

5mm Min 5mm Min

5mm Min

450mm Min

For Servicing

Purposes

In Operation

At least 1.5°

345mm

Made in the UK

FOR ALL ENQUIRIES, PLEASE CALL

0844 871 1525

EMAIL: INFO@BAXI.CO.UK

VISIT: WWW.BAXI.CO.UK

OPEN MONDAY - FRIDAY, 8AM - 6PM

SATURDAYS & BANK HOLIDAYS, 8.30AM - 2PM

WEARE CLOSED ON CHRISTMAS DAY & NEW YEAR'SDAY

TOBOOK ATRAINING COURSE PLEASE CALL 0845 600 7402

OPEN MONDAY - THURSDAY, 8.30AM - 5PM

FRIDAY, 8.30AM - 4.30PM

OR VISIT WWW.BDRTHERMEATRAINING.CO.UK

PLEASE NOTE CALLS MAY BE MONITORED OR RECORDED

BAXI, BROOKS HOUSE, COVENTRY ROAD, WARWICK CV34 4LL

WWW.BAXI.CO.UK 365074-07

THIS BROCHURE IS PRINTED ON PAPER SOURCED FROM WELL MANAGED FORESTS AND OTHER

CONTROLLED SOURCES. THIS BROCHURE IS PRINTED USING VEGETABLE BASED

INKS. PLEASE RECYCLE THIS BROCHURE WHEN YOU HAVE FINISHED WITH IT.

BAXI POLICY IS ONE OF CONTINUAL IMPROVEMENT AND DEVELOPMENT. THE

RIGHT TO CHANGE SPECIFICATION AND APPEARANCE WITHOUT PRIOR NOTICE IS

RESERVED. THE REPRODUCTION OF COLOURS IS AS ACCURATE AS PHOTOGRAPHIC

AND PRINTING PROCESSES ALLOW. THE CONSUMER'SSTATUTORY RIGHTS ARE NOT

AFFECTED. E&OE
