Baumatic BCS460SS-AUS Manual de usuario

BCS460SS-AUS

46cm Combi Steamer

Touch Control Oven.

User Manual for your Baumatic

BCS460SS-AUS

46 cm combi steamer touch

control oven with personalised

recipes.

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 08/08/11

Contents

Environmental note 5

Important safety information 6 – 8

Specifications 9 – 12

Product and aperture dimensions 9 - 10

Coolingfan 10

Product specifications 10

Standardaccessories 10

Electricaldetails 10

Description of the oven and accessories 11-12

Controlpanel 12

Usingyouroven 12-23

Before first use 12

Initial start up and setting the time of day 13

Ovenburnoff 13-14

Setting the minute minder 14

Setting the duration function 15

Setting the start and end time function 16-17

Oven function and temperature selection 17

Ovenfunctions 18-19

Waterhardness 19

Cookingwithsteam 20

Adding hot air + steam cooking mode 20-21

Cookingguidelines 21

Warnings 21-22

Accessories 22-23

Cookingcharts 23-32

Memorising cooking programmes 26

Recalling saved cooking programmes 26-27

Deleting saved cooking programmes 27

Cooking with the food probe 27-29

Menu options 29-30

Recipes 30

Settings 30-32

Lockingthekeypad 32

The oven light 32

Cleaning and maintenance 33-39

Oven cavity cleaning cycle 34

Boilerdescaling 35-36

Boilerwash 36

Removing the side racks 37

Replacing the oven bulb 37-38

Removing the oven door for cleaning 38-39

Installation 40-43

Electricalconnection 40

Installing the oven into the kitchen cabinet 41

Positioningtheappliance 41

Ventilationrequirements 42

Installing the drip catcher 43

My appliance isn’t working correctly 44-46

Errorcodeschart 44

Contact details 47

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Retailer where you

purchased your unit from.

General Information

oThis appliance is designed for domestic household use and can

be built into a standard kitchen cabinet or housing unit.

oIMPORTANT: You must not install the appliance in a location

where the ambient temperature will fall below 5°C.

oIMPORTANT: The adjacent furniture or housing and all

materials used in the installation must be able to withstand a

minimum temperature of 85°C above the ambient temperature

of the room it is located in, whilst in use.

oCertain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouration at

temperatures below the guidelines given above.

oAny damage caused by the appliance being installed in

contravention of this temperature limit, or by placing adjacent

cabinet materials closer than 4mm to the appliance, will be the

liability of the owner.

oFor use in leisure accommodation vehicles, please refer to

the appropriate information given in the installation instructions

for this appliance.

oThe use of this appliance for any other purpose or in any other

environment without the express agreement of Baumatic Ltd.

will invalidate any warranty or liability claim.

oYour new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of Guarantee. The foregoing does not

affect your statutory rights.

oRepairs may only be carried out by Baumatic Service

Engineers or their authorised service agent.

Warning and safety instructions

oThis appliance complies with all current European safety

legislation. Baumatic do wish to emphasise that this compliance

does not remove the fact that the appliance surfaces will

become hot during use and retain heat after operation.

Child Safety

oBaumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowed

to touch the appliance at any time.

oIf it is necessary for younger family members to be in the

kitchen, please ensure that they are kept under close supervision

at all times.

General Safety

oDo not place heavy objects on the oven door or lean on the

oven door when it is open, as this can cause damage to the oven

door hinges.

oDo not leave heated oil or fat unattended, as this is a fire risk.

oDo not place pans or baking trays directly on the base of the

oven cavity, or line it with aluminium foil.

oDo not allow electrical fittings or cables to come into contact

with areas on the appliance that get hot.

oDo not use the appliance to heat the room it is located in or to

dry clothing.

oDo not install the appliance next to curtains or soft furnishings.

oDo not attempt to lift or move cooking appliances by using the

oven door or handle, as this may cause damage to the appliance

or result in injury to the person lifting the appliance.

Cleaning

oCleaning of the oven should be carried out on a regular basis.

oGreat care should be taken whilst using this appliance and when

following the cleaning procedure.

oIMPORTANT: The appliance must be disconnected from the

mains before following the cleaning procedure.

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions.

oBaumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a result of improper

use or installation of this appliance.

oHeat, steam and moisture will be created during use of the

appliance, take care to avoid injury and ensure that the room is

adequately ventilated. If the appliance is going to be used for

prolonged periods of time, then additional ventilation may be

required.

oPlease consult with your qualified installer if you are in any doubt

about the amount of ventilation that you will require.

Declaration of conformity

This appliance complies with the following European Directives:

-2006/95/EC regarding “low voltage”

-2004/108/EC regarding “electromagnetic disturbances”

-Regulation (EC) N° 1935/2004 regarding “materials in contact

with food”

oThe above directives comply with 93/68/EEC regarding CE

marking.

oThe manufacturer declares that the oven is built using certified

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

must be used by a trained person for domestic purposes only.

Specifications

Product dimensions

Height: 460 mm

Width: 597 mm

Depth: 544

Aperture dimensions

Height: 460 mm (built under) / 445 mm (built in)

Width: 560 mm

Depth: 560 mm

Cooling fan

oA tangential cooling fan is fitted inside of this appliance, to make

the internal temperature of the oven stable and the external

surface temperature lower.

Product specifications

oEnergy efficiency class: A

oGross oven capacity: 31 litres

oNet oven capacity: 27 litres

oTouch control operation

oMulti language text display (English, French, Italian, Spanish,

Portuguese, Czech, Dutch, Danish, Russian and German)

o50 preset recipes

oElectronically controlled thermostat

oCooling fan

oSafety lock

oTriple-glazed removable door

Standard accessories

o1 x Removable side racks

oSafety shelf

o2 x Inox perforated deep trays

oFood probe

Electrical details

Rated Voltage: 220 - 240 Vac 50 - 60 Hz

Supply Connection: 13 A (double pole switched fused

outlet with 3mm contact gap

Max Rated Inputs: 2.2 kW

Mains Supply Lead: 3 x 1.5mm²

Oven Light Bulb: 25 W/ E14 300°C screw type

pygmy
