2.6 Spare parts for Socket Adapter
Outside thread M36 x 1,5
Hex socket head screw (for A17):
Cylinder screw with hexagon socket
3. Indication/Contraindication
Indication:
•Amputation of lower extremities
Contraindication:
•not known
4. Side effects
There are no known side effects.
Order No. Description Article No.
E A02 Lamination Dummy made of special rubber 4 114 019 01 00 000
Order No. Material Article No.
E A04 Steel 4 114 110 00 00 000
Order No. Model Len ht Packa in Unit Article No.
M28 12 Steel M8 x 12 10 4 226 050 00 00 012
M28 16 Steel M8 x 16 10 4 226 050 00 00 016
E A11 12 Steel with waterproof
coating
M8 x 12 4 4 113 018 11 20 612
Order No. Model Len ht Packa in Unit Article No.
M33 Steel M5 x 18 10 4 226 030 05 00 018
E A12 20 Steel with waterproof
coating
M5 x 20 1 4 113 018 12 20 520
5. General safety instructions
•This medical product is designed for: single patient, multiple use.
•Fitting/service of this medical device is only allowed by a certificated orthopedic
professional.
•Improper modification or application to the product is not allowed. In case of non
observance, the function of the product may be impaired, so that product liability
is excluded.
•Only approved screws may be used.
•The maximum weight loads are listed under “2. Technical Data”. Additional loads
must be taken into account when calculating the weight.
•In case of insufficient laminate reinforcement, the Socket Adaptor A6, A8, A9, A15
could break out from the prosthetic socket.
•Pay attention to sufficient form fit (A8).
6. Installation
6.1 A6, A8, A9, A15 Socket Adapter
•Bending of the Socket Adapter A6 an A9 could result in crackings in the titanium.
•Seal the male pyramid and the distal holes with plastilina.
•Before placing the socket adaptor put some layers of reinforcement material over
the plaster model.
•Then position socket adaptor on the model and tie off the following layers of
reinforcement in the groove of the adapter with carbon fibre roving.
•Fix the enclosed Lamination Dummy E A02 on the socket adaptor.
•The Lamination Dummy E A02 covers and protects the pyramid during lamination
procedure and provides a precisely fitting brim of the laminate.
•During hardening process of A8 and A9 the laminate in the area of the adapter
must be cooled.
•After lamination expose the attachment side and holes of the adaptor. Do not
damage the socket adaptor.
