GalaxyNW12

3D stereo, networkcentric, 12,000 lumens, WUXGA, threechip DLP projector

Barco’s Galaxy NW12 is the world’s first

active 3D stereo projector with a native

WUXGA (1920x1200) resolution. It’s the

perfect choice for any single or

multiprojectorcollaborativedisplaysystem.

Maximaleaseofuse

ThankstoitsfullcompatibilitywithBarco’sXDSControlCentersoftwaresuite,

theGalaxyNW12offersdirectaccesstoalllocalandnetworkedsourcesina

familiarWindowsdesktop.Youcandisplayyoursourcesinmultiplewindows

thatcanberesized,draggedandmadetooverlapanywhereonthescreen,in

anycombinationof2Dand3D.

Supreme stereoscopic quality With its strong 12,000 lumens light output,

Barco’s Galaxy NW12 was designed to operate in bright environments. Its

nativestereoscopiccapabilities,whichincludebothpassiveandactiveInfitec,

renderitaperfectchoiceforapplicationsthatrequirestereoscopicimagesof

thehighestdetail.

Maintenancefreedesign

TheGalaxyNW12isdesignedwithoneofthelowestnoiselevelsinitsclass,

and a guaranteed long system lifetime due to its fully sealed, liquidcooled

optical engine. This not only prevents dust from entering the projector’s

interior, it also eliminates routine maintenance procedures and strongly

reducespotentialsystemdowntime.

GalaxyNW12

3D stereo, networkcentric, 12,000 lumens, WUXGA, threechip DLP projector

Optimizedforsystemintegration

Barco’s Galaxy NW12 is optimized for multiprojector system integration

throughvariousfeatures:

• Edge blending technology creates one continuous image without blurry

overlapzoneswhereprojectionsconverge.

•DynaColorandlinkedconstantlightoutput(CLO)ensurethesamelight

andcolorlevelsacrosstheentirescreen.

• Warping (geometry correction) enables accurate projection from different

anglesandacrosssphericalorcurvedsurfaces.

Productspecifications GalaxyNW12

Lightoutput 12,000lumens

Contrastratio upto2,000:1

Resolution WUXGA(1920x1200px)

Chiptype ThreechipDLP

Lamp 2kWxenonlamp

Lampwarranty 750hrswarranted

Weight 70kg(154.2lbs)

Dimensions(WxLxH) 590x913x345mm(23.22x35.94x13.58")

LensShift Horizontalupto/+65%Verticalupto/+110%

Standardinputs TwinduallinkDVI

3stereosyncinputs(miniDIN)

OptionalInputs Twofreelayers(seeoptions)

CommunicationPort RS232(onD9)

10/100Mb/sEthernet(onRJ45)

Data Analogsourceswithapixelclockofupto270MHz

DVIsourceswithapixelclockofupto300MHz(includingWUXGA120Hz)

Safety ETL60950andEN60950

CEcompliant

CCCcompliant

ACpower 220V240V

Max.powerconsumption 2,800Watt/9,560BTU

Generatedon:25Jan2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
