Balance KH 5522 Manual de usuario
DIGITAL BATHROOM SCALE
Operating Instructions
CYFROWA WAGA ŁAZIENKOWA
Instrukcja obsługi
DIGITÁLIS FÜRDŐSZOBAMÉRLEG
Használati utasítás
DIGITALNA OSEBNA TEHTNICA
Navodila za upravljanje
OSOBNÍ DIGITÁLNÍ VÁHA
Návod k obsluze
DIGITAL BATHROOM SCALE
DIGITÁLNA OSOBNÁ VÁHA
Návod na obsluhu
DIGITALNA OSOBNA VAGA
Upute za upotrebu
DIGITALE PERSONEN-WAAGE
Bedienungsanleitung
KH 5522 KH 5523
CV_KH5522_23_V23384_LB4 17.07.2008 9:03 Uhr Seite 2
4
KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH5522/23-07/08-V1
CV_KH5522_23_V23384_LB4 17.07.2008 9:02 Uhr Seite 1
KH 5522/23
wr
e
q
CV_KH5522_23_V23384_LB4 17.07.2008 9:03 Uhr Seite 4
- 3 -
CONTENT PAGE
Safety Instructions 4
Technical Data 4
Device Description 4
Purpose 5
Included in delivery 5
Commissioning 5
Use 6
Warning Displays 6
Replacing the Batteries 7
Use and Storage 7
Cleaning 8
Troubleshooting 8
Disposal 8
Warranty & Service 9
Importer 9
Read the operating instructions carefully before using the appliance for the first time and preserve this
booklet for later reference. Hand over the manual to anyone, whom you pass on the appliance to.
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 3
- 4 -
DIGITAL BATHROOM
SCALE
Safety Instructions
Hazard!
Ensure that no liquid gets into the scale or into the
display. This can cause an electrical shock hazard!
Do not allow individuals (including children) to use
the appliance whose physical, sensorial or mental
abilities or lack of experience and knowledge hin-
der their safe usage of it if they have not previously
been supervised or instructed in its correct usage.
Tell children about the appliance and its potential
dangers so that they do not play with it.
Warning!
Do not place the scale in the direct vicinity of heat
sources. Scale and display may only be operated
at temperatures between 10° and 40°C. At higher
or lower temperatures malfunctions or permanent
damage can occur.
Do not charge the scale with weight in excess of
180 kg / 396 lb! This can irreparably damage the
scale
Caution!
Old batteries can leak battery acid. In the event of
the batteries leaking acids, wear protective gloves.
Clean the battery compartment with a dry cloth.
Remove the batteries if you will not be using the sca-
le for a longer period of time.
Please note!
Avoid electrostatic charging and discharging. Elec-
trostatic charging or discharging can cause incor-
rect displays or suddenly switch-off the scale.
No liability/guarantee is assumed for damages
caused by…
• opening the scale housing
• repair work that is not performed by qualified
personnel
• improper user of the scale
Technical Data
Maximum load bearing
capacity: 180 kg/396 lb
Tolerance Range: +/- (1% + 0.1kg/0.2lb)
(at 30 kg - 180 kg )
Minimum measurable
weight: 3 kg/6.6 lb
Selectable measurement
units: kg/lb
Scaling: 0.1 kg/0.2 lb
Operating temperature: 10 °C - 40 °C
Display for low battery power
Overload display
Fault display
Battery operation: 2 x CR2032 / 3V
(Lithium batteries)
Device Description
qDisplay
wBattery compartment
eSafety glass
rSelector switch (kg / lb)
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 4
- 5 -
Purpose
These digital glass scale is exclusively intended
• as personal scale
• for use in private households
Included in delivery
Digital glass scale
2 x CR2032 / 3V lithium batteries
Operating instructions
Before using the appliance for the first time, check
to ensure that the contents are complete and
undamaged.
Commissioning
1. Remove the cover of the battery compartment.
Remove the insulation strip from the battery com-
partment and insert the batteries back into the
battery compartment with the correct polarity.
2. Place the cover back on the battery compart-
ment and press it down until you hear it snap
into place.
3. Set the desired unit of weight (kg or lb) by
pressing the selector switch.
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 5
- 6 -
• Place your glass scale on a flat, solid surface.
Please ensure that both the floor where the
weigh scales are set up and the surface of the
weigh scales are not wet to ensure that
nobody slips.
Please note!
The glass scale contains sensitive electronic compo-
nents and must therefore not be installed
• close to heat sources
• in environments that are exposed to extreme
humidity
Use
Attention: Never burden the scales one-sidedly. Al-
ways step onto the scales in the middle and with
both feet. If you do not, the digital glass scale could
tip to one side and be irreparably damaged.
Additionally, there is the risk of falling over!
1. Tap your foot lightly on the centre of the scale
until “HI” appears on the LCD display.
2. Stand with both feet on the scale once “0.0”
appears on the LCD display. Stand calmly and
without shifting your weight.
3. During weighing, the “kg/lb” LCD display flas-
hes and the displayed value rises until your
weight has been determined.
4. The “kg/lb” display now stops flashing and your
weight is displayed in grades of 0.1 kg/0.2 lb.
Attention: never jump on to the scale as this may
cause damage.
Warning Displays
“0_Ld” appears in the LCD display if the weight ex-
ceeds the maximum weighing capacity of 180
kg/396 lb. Step off the scale immediately as you
may otherwise cause damage.
Replace the batteries if “Lo” appears in the display.
The scale is unable to measure the weight if “Err”
appears in the display. Step off the scale in this
case, wait for a few seconds and then try again.
Make sure you stand calmly and do not interrupt
the weighing process.
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 6
- 7 -
Replacing the Batteries
1. Remove the lid on the battery compartment.
2. Remove the old batteries from the battery
compartment. Insert two new batteries of type
CR2032 into the battery compartment. Be sure
to orient the batteries with the correct polarity.
3. Place the cover back on the battery compart-
ment and press it down until you hear it snap
into place.
Use and Storage
• Please take note that the measurement results of
different scales may differ slightly.
• Avoid using the batteries unnecessarily. Therefo-
re, do not store any items on the scale if it is not
being used. Remove the batteries if you will not
use the scale for a longer period.
• Keep the scale in a clean and dry environment.
• Avoid electrostatic charging.
• Your glass scale represent a sensitive electronic
instrument. As such, high-frequency devices may
sometimes cause disturbance when used in the
immediate vicinity (e.g. mobile telephones, CB
radio stations, remote controls and microwave
ovens).
If there are faults such as irregular or faulty displays
in the LCD display, remove the scale from the source
of disturbance or deactivate the source of disturban-
ce when you are using the product.
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 7
- 8 -
Cleaning
Only use neutral detergent and a soft cloth to clean
the glass scale.
Troubleshooting
Do not attempt to dismantle the scale to repair any
defects yourself. You may otherwise damage the
sensitive electronic components.
Only qualified service personnel are authorised to
repair the glass scale!
No liability will be accepted for damage resulting
from improper use and/or opening of the
appliance!
In the event of faulty operation or if the display is in-
correct, please check the following conditions:
• Are the batteries positioned within the battery
compartment with the correct polarity?
• Is the selector switch (kg/lb) set to the correct
position?
Perform a reset on the scale:
• To do this, remove the batteries from the battery
compartment.
• Wait a few seconds, then insert the batteries
back into the battery compartment.
If these measures do not correct the problem, plea-
se contact the appropriate service partner for your
country.
Disposal
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the European guideline
2002/96/EC.
Dispose of the appliance through an approved dis-
posal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Battery disposal!
Batteries may not be disposed of with normal
domestic waste. All consumers are statutorily obli-
ged to dispose of batteries at the collection point in
their community/district or with the original supplier.
The purpose of this obligation is to ensure that
batteries can be disposed of in an environmentally
friendly manner. Only dispose of batteries when
they are fully discharged.
Dispose of all packaging materials in an
environmentally friendly manner.
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 8
- 9 -
Warranty & Service
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been
manu-factured with care and meticulously examined
before delivery. Please retain your receipt as proof
of purchase. In the case of a warranty claim, please
make contact by telephone with our service depart-
ment. Only in this way can a post-free despatch for
your goods be assured.
The warranty covers only claims for material and
maufacturing defects, not for wearing parts or for
damage to fragile components. This product is for
private use only and is not intended for commercial
use.
The warranty is void in the case of abusive and im-
proper handling, use of force and internal tampe-
ring not carried out by our authorized service
branch. Your statutory rights are not restricted in
any way by this warranty.
DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.: 0870/787-6177
Fax: 0870/787-6168
e-mail: support.uk@kompernass.com
Irish Connection
Harbour view
Howth
Co. Dublin
Tel: 00353 (0) 87 99 62 077
Fax: 00353 18398056
e-mail: support.ie@kompernass.com
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_KH5522_23_V23384_LB4 11.08.2008 10:04 Uhr Seite 9
