Bafo BF-8000 Manual de usuario
Wireless Bluetooth
USB Dongle
User’s Guide
1
Table of Content
CHAPTER 1 INTRODUCTION.................................................................................................. 5
INTRODUCTION TO BLUETOOTH...................................................................................... 5
INTRODUCTION TO THE WIRELESS BLUETOOTH USB DONGLE................................. 5
CHAPTER 2 CONTENTS OF PACKAGE................................................................................. 7
CHAPTER 3 INSTALLING BLUETOOTH SOFTWARE........................................................... 8
3.1 UNINSTALLING PREVIOUS VERSION OF BLUETOOTH SOFTWARE............................................. 8
3.2 INSTALLING THE BLUETOOTH SOFTWARE (FIRST-TIME INSTALLATION) .................................. 10
3.3 START USING BLUETOOTH ............................................................................................... 15
CHAPTER 4 SETUP DIAGNOSTICS................................................................................. 19
4.1 HARDWARE DIAGRAM ...................................................................................................... 19
4.2 VERIFYING HARDWARE AND SOFTWARE INSTALLATION ...................................................... 19
CHAPTER 5 INTRODUCTION TO BLUETOOTH SOFTWARE............................................. 21
5.1 INTRODUCTION TO BLUETOOTH SOFTWARE ........................................................ 21
5.2 BLUETOOTH DEVICE IDENTITY ................................................................................ 22
5.3 BLUETOOTH TRAY ...................................................................................................... 22
5.4 ACCESS MY BLUETOOTH PLACES ........................................................................... 23
5.5 ICONS USED FOR BLUETOOTH DEVICES AND SERVICES.................................... 23
CHAPTER 6 BASIC OPERATIONS ....................................................................................... 28
6.1 START OR STOP BLUETOOTH................................................................................... 28
6.2 CREATE A CONNECTION FROM THE BLUETOOTH ICON IN THE SYSTEM TRAY 28
6.3 CREATE A CONNECTION USING THE BLUETOOTH SETUP WIZARD.................... 29
6.4 CREATE A CONNECTION FROM BLUETOOTH EXPLORER .................................... 30
6.5 FIND BLUETOOTH DEVICES ...................................................................................... 32
6.5.1 Periodic Search for Devices .................................................................................. 32
6.6 FIND A SERVICE .......................................................................................................... 33
6.7 BLUETOOTH CONNECTION STATUS ........................................................................ 35
6.8 SEND TO BLUETOOTH ............................................................................................... 37
6.9 PAIRING BLUETOOTH DEVICES AND ACCESS THE INTERNET ............................ 38
CHAPTER 7 CONFIGURATION PANEL ............................................................................... 43
7.1 ACCESS THE BLUETOOTH CONFIGURATION PANEL............................................. 43
7.2 GENERAL CONFIGURATION SETTINGS................................................................... 44
7.3 ACCESSIBILITY SETTINGS......................................................................................... 45
2
7.4 DISCOVERY SETTINGS .............................................................................................. 48
7.5 BLUETOOTH LOCAL SERVICES ................................................................................ 50
7.5.1 Audio Gateway....................................................................................................... 51
7.5.2 Bluetooth Serial Port.............................................................................................. 52
7.5.3 Dial-up Networking Service ................................................................................... 53
7.5.4 Fax Service............................................................................................................ 54
7.5.5 File Transfer Service.............................................................................................. 55
7.5.6 Headset Service..................................................................................................... 57
7.5.7 Network Access..................................................................................................... 58
7.5.8 PIM Item Transfer.................................................................................................. 64
7.5.9 PIM Synchronization.............................................................................................. 67
7.5.10 NOTIFICATION.................................................................................................... 69
7.6 BLUETOOTH CLIENT APPLICATIONS OVERVIEW................................................... 71
7.6.1 Audio Gateway....................................................................................................... 72
7.6.2 Bluetooth Serial Port.............................................................................................. 73
7.6.3 Dial-up Networking................................................................................................. 75
7.6.4 Fax......................................................................................................................... 76
7.6.5 Headset.................................................................................................................. 77
7.6.6 File Transfer........................................................................................................... 79
7.6.7 Network Access..................................................................................................... 81
7.6.8 PIM Synchronization.............................................................................................. 82
7.6.9 PIM Item Transfer.................................................................................................. 84
7.6.10 Printer ..................................................................................................................86
7.7 HARDWARE SETTINGS .............................................................................................. 88
CHAPTER 8 SECURITY .................................................................................................... 91
8.1 AUTHENTICATION ....................................................................................................... 91
8.2 AUTHORIZATION ......................................................................................................... 91
8.3 ENCRYPTION............................................................................................................... 91
8.4 LINK KEY ...................................................................................................................... 91
8.5 PAIRING DEVICES ....................................................................................................... 91
8.6 PASSKEY...................................................................................................................... 94
8.7 SECURE CONNECTION .............................................................................................. 94
8.8 SECURITY REQUEST DIALOG BOX .......................................................................... 94
CHAPTER 9 ............................................................................................................................ 95
TROUBLESHOOTING ............................................................................................................ 95
3
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential Installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
1) To comply with FCC RF exposure compliance requirements, a separation distance of at
least 20 cm must be maintained between the antenna of this device and all persons.
2) This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Licensed Software
Bluetooth for Windows (BTW) is the licensed software owned by Widcomm,Inc.
Trademark(s) ™ and Registered Trademark(s) ®
Bluetooth and the Bluetooth logos are trademarks owned by Bluetooth SIG, Inc., U.S.A.
Microsoft, Windows, are registered trademarks of Microsoft Corporation. Other brand and
product names may be registered trademarks or trademarks of their respective holders.
4
Chapter 1
Introduction
INTRODUCTION TO BLUETOOTH
The term “Bluetooth” refers to a worldwide standard for the wireless exchange of data
between two devices.
In order to exchange data, two Bluetooth devices must establish a connection.
Before a connection is established, one device must request a connection with another.
The second device accepts (or rejects) the connection.
The originator of the request is known as the client.
The device that accepts (or rejects) the request is known as the server.
Many Bluetooth devices can act as both client and server.
A client Bluetooth device runs a software program that requests a connection to another
device as part of its normal operation. For example, the program may request a
connection to a remote computer, a printer, or a modem.
Becoming a Bluetooth client normally requires an action by the device operator, such as
an attempt to browse a remote computer, print a file, or dial out on a modem.
Every Bluetooth device that provides a service must be prepared to respond to a connection
request. Bluetooth software is always running in the background on the server, ready to
respond to connection requests.
INTRODUCTION TO THE WIRELESS BLUETOOTH USB
DONGLE
The Bluetooth USB Dongle is specifically designed to plug into an available USB port
connecting to a desktop or laptop. It is the best solution for quick and easy connection and
access to your Ethernet Local Area Network (LAN) and other shared resources without cables
or wires.
We provide both low power (class 2/3) and high power (class 1) Bluetooth USB Dongle. Each
Bluetooth Dongle is bundled with Widcomm Bluetooth Software. The significant difference
between the high power and low power is the transmission range. The transmission range of
class 1 (high power) is up to 50 meters; however, the class 2/3 (low power) is about 10-20
meters. You can choose a suitable Bluetooth USB Dongle depends on your working
5
environment.
The PC configured as the Bluetooth server can support up to 7 Bluetooth client devices with IP
addresses automatically assigned when they connect. The bundled Bluetooth Software also
provides Internet sharing and security access between the server and clients.
After finishing these steps outlined in this manual, you will have the ability to share information,
Network Access and take the full advantage of a “connected” environment.
6
7
Chapter2
Contents of Package
After opening the box, check what’s in the box, and then refer to the Quick Installation Guide
for the fastest way to get up and running with the wireless Bluetooth USB Dongle.
What ships in the box
The following items should be found in the Bluetooth USB Dongle box:
Bluetooth USB Dongle
Utility CD (containing Bluetooth Software and Manual)
Quick Installation Guide
Class 2/3
Low Power
Class 1
High Power
Chapter 3
Installing Bluetooth Software
3.1 Uninstalling previous version of
Bluetooth software
If you are installing the Bluetooth software for the first time, please skip this section.
Any previous versions of the Bluetooth software must be uninstalled before installing an
upgraded version.
Note:
Before start to uninstall the previous version of BTW software, please unplug the wireless
Bluetooth Dongle from computer’s USB port first.
Please uninstall the software by completing these steps:
1)Close any open programs and insert the utility CD into your CD-ROM Drive.
2) The Autorun function should start and will automatically detect that the previous version of
BTW software has been installed on you PC. (If the Autorun function does not automatically
start, please open the Installation CD to find the Setup.exe file and double click the Setup.exe
icon to continue.)
3) The Welcome screen informs that the InstallShield Wizard will guide you to Modify, Repair
or Remove the software. Click on the Next button to continue.
8
4)Click on the Remove button from “Remove the Program” screen.
5) When the files have been removed, you will be presented with a screen informing of its
completion. Click on the Finish button.
9
6). Click on the Yes button to reboot your PC.
You have completely uninstalled the previous version of the Bluetooth software. You may go
further to install the upgrade version as described in the following section.
3.2 Installing the Bluetooth software
(First-time installation)
Note:
Plug in the USB Dongle firmly to an available USB port only when
y
ou are prompted
during the installation process.
10
