B-Tech BT899XL-FD Manual de instrucciones
B-TECH AV MOUNTS
www.btechavmounts.com
PLEASE KEEP THIS FOR FUTURE REFERENCE
BT899XL-FD
FIXED DROP PROJECTOR CEILING MOUNT
WITH MICRO-ADJUSTMENT
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
CONTENTS
INSTALLATION TOOLS REQUIRED
FEATURES
Crosshead
screwdriver
Drill 10mm masonry bit
or 6mm wood bit
Pencil
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................15
B-Tech Contact Details.....................................................................................................................16
13mm
spanner or socket
Ɣ Ceiling mount designed for projectors up to 25kg (55lbs)
Ɣ +/-13° tilt adjustment, +/-6° roll adjustment and 360° swivel
Ɣ Optional micro-adjustment for perfect alignment of projected images
Ɣ Unique ‘Carousel’ mounting plate for universal compatibility
Ɣ Maximum distance between any two fixing points 493mm
Ɣ Suitable for angled/cathedral ceilings
Ɣ Includes Ø50mm extension pole
Ɣ Suitable for projectors using M2.5, M3, M4, M5 and M6 fixings
Ɣ Theft deterrent security screws provided as standard
(excludes M2.5 and M3 fixings)
Ɣ Integrated cable management for a smart installation
Ɣ All mounting hardware & fixings included
Registered Design Nºs: 001713306-0004 / 002741256-0008
ß
ß
360°
ß
ß
25kg
BT899XL-FD
PARTS LIST
4
Suitable for loads
up to 25kg
10
24
19 11
23
22
20
26
27
25
28
29
18
21
9
30
31
12
13
16
17
15
14
5
4
3
6
8
1
7
2
Micro-adjustment assembled
5
PLEASE KEEP THIS FOR FUTURE REFERENCE
33
34
32
DE
A
FG H I
LK
J
BC
A
M2.5 x 25mm SCREW
4
B
M3 x 12mm SCREW
4
C
M3 x 25mm SCREW
4
D
M4 x 12mm SCREW
4
E
M4 x 25mm SCREW
4
F
M5 x 12mm SCREW
4
G
M5 x 25mm SCEW
4
H
M6 x 12mm SCREW
4
I
M6 x 25mm SCREW
4
J
ID6.5 T12mm SPACER
4
K
M3 METAL WASHER
4
L
M4 METAL WASHER
4
A1
M8 OD18 T1.5mm WASHER
4
A2
M8 x 50mm COACH SCREW
4
A3
Nº 10 x 50mm WALL PLUG
4
FIXING KIT
INTERFACE KIT
ITEM QTY
A1 A3
A2
ITEM PART NAME QTY
1
2
3
1
LESUORAC
4
4
5
4
4
6
4
7
1
8
4
9
01
1
TUN COLYN 8M
11
WERCS YTIRUCES
mm21 x 6M
21
31
41
61
51
17
18
25
19
20
2
TEKCA
RB TNEMTSUJDA ORCIM
2
WER
CS YTIRUCES mm03 x 4M
2
TUN COLYN 4
M
82
29
34
33
03
32
1
MOUNTING PLATE
1
ETALP GNINIOJ
1
ETALP LEVIWS
21
1
3mm HEX KEY
22
23
26
27
4mm SECURITY KEY 1
24
5mm SECURITY KEY 2
1
M8 WASHER
Ø50mm COLLAR
CEILING PLATE
1
4
M8 x 12mm SCREW
4
EXTENSION POLE 1
4
M8 LOCK WASHER
M8 x 65mm SAFETY BOLT
M8 SPRING WASHER
1
1
POLE ADAPTOR 1
2
WERCS BURG mm6 x 01M
1
T
LOB YTEFAS mm06 x 8M
M6 x 20mm GRUB SCREW 1
MOUNTING SCREW
8
M6 T1mm METAL WASHER
M6 T1.2mm METAL WASHER
6
M8 x 16mm HEX SCREW
M6 x 8mm SCREW
M8 T2mm PLASTIC WASHER
1
SHORT LEG
LONG LEG
31
M4 T1mm METAL WASHER
2
M4 T1.6mm PLASTIC WASHER
2
6
INSTALLATION INSTRUCTIONS
1
2
Ø50mm POLE
Assemble Pole to Collar
i. Slide item 2 onto item 8.
ii. Fix item 2 to item 8 using items 6 and 7.
7
6
34
22
iii. Tighten the grub screws evenly
on item 2 using item 33.
33
GRUB SCREW
8
8
7
1
54
3
34
2
Mount Pole and Collar to Ceiling Plate
Set the required tilt angle when fitting item 2 to item 1,
using items 3, 4 & 5.
Tighten with item 34.
2
The tilt angle can
also be adjusted
once mounted to
the ceiling or wall
5
34
5
4
3
34
5
4
2
8
3
1
8
3
Mounting the Ceiling Plate to Ceiling / Wall
10mm
Leave 10mm gap
for next step
CEILING
Twist
Twist
i. Pre-drill holes for ceiling fixings.
ii. Assemble two fixing screws in place, corner to corner leaving a 10mm gap
between the screw head and ceiling.
iii. Hook item 1 onto the fixing screws and twist into position.
B-Tech highly recommends
this product be installed by a suitably qualified person.
The installer must be satisfied that the types of fixings used are suitable for the type of ceiling the product is to be mounted to.
Care must be taken as to where this product is located, as some ceilings and walls are not suitable for installation.
When drilling holes, knowledge must be obtained to avoid contact with any electrical cables and/or gas and water pipes contained
within the ceiling or walls.
IMPORTANT
Ceiling plate dimensions
are available on page 15
1
A1
9
iv. Assemble the remaining two fixings to secure the ceiling plate.
A1
10
Connect item 8 to item 10 using item 9.
4Attach Mounting Plate to Pole
24
32
10
10
31
30
34
9
8
9
