Azeron CYBORG Manual de usuario
Manual
Page | 1
| Manual
Contents
TABLE OF CONTENTS................................................................................................................. 1
INTRODUCTION ......................................................................................................................... 2
1. FEATURES .......................................................................................................................... 3
PACKAGE CONTENTS ................................................................................................................ 3
2. DEVICE LAYOUT................................................................................................................. 4
3. ADJUST YOUR AZERON KEYPAD....................................................................................... 5
4. INSTALLING SOFTWARE.................................................................................................... 7
5. HOW TO USE AZERON SOFTWARE................................................................................. 15
5.1. CALIBRATING THUMBSTICK......................................................................................... 15
5.2. INTERFACE OVERVIEW................................................................................................. 16
5.3. BUTTON SETUP ............................................................................................................ 17
5.3.1. Keyboard mode .................................................................................................... 17
5.3.2. Xinput button and Xinput trigger......................................................................... 18
5.3.3. Mouse mode ......................................................................................................... 18
5.3.4. Joystick button...................................................................................................... 18
5.3.5. Joystick D-pad mode............................................................................................. 19
5.3.6. Toggle analog stick mode ..................................................................................... 19
5.3.7. Macro .................................................................................................................... 20
5.3.8. Button layering ..................................................................................................... 22
5.3.9. No action mode .................................................................................................... 22
5.3.10. Button labels....................................................................................................... 23
5.4. THUMBSTICK SETUP .................................................................................................... 24
5.5 PROFILES ....................................................................................................................... 27
5.6 SETTINGS ...................................................................................................................... 30
6. HOW TO UPDATE FIRMWARE MANUALLY .................................................................... 33
7. TIPS AND TRICKS ............................................................................................................. 35
Page | 2
| Manual
INTRODUCTION
The Azeron gaming keypad is a simple Plug-and-Play controller that sets
up easily with our software. It can function as a joystick or as a keyboard
or in hybrid mode.
The Azeron Cyborg keypad comes with 24 - 29 programmable buttons and
an analog thumbstick for complete control and maneuverability over your
game.
Its ergonomic wrist pad, adjustable key towers and adjustable thumb
module delivers a perfect fit for your arm and minimized fatigue over
extended gameplay.
The main advantage of the Azeron keypad is the ability to move in game
character with one finger –the thumb (either in 360° mode or in WASD
mode, depending what your game supports). All other fingers now can
freely press other buttons while you are moving at the same time. The
buttons are very easy to reach with a little flick of your finger, don’t need
to reach too far and stress your hand.
Page | 3
| Manual
1. FEATURES
22 programmable buttons on towers
7 programmable thumb buttons
A programmable full size analog thumbstick
Adjustable button positions to fit your hand
Stable metal base with antislip silicon pads
Braided cables
2 meter (6.5 feet) braided USB cable
Easy accessible reset button
Omron switches with mechanical durability 10 million keypresses
On-board memory for your favorite keybinds
PACKAGE CONTENTS
Page | 4
| Manual
2. DEVICE LAYOUT
Page | 5
| Manual
3. ADJUST YOUR AZERON KEYPAD
Page | 6
| Manual
By using the included Hex screwdriver, it is possible to adjust key and
thumb module positions for your hand.
You can swap included thumbstick caps just by pulling them off with a
little force:
Page | 7
| Manual
4. INSTALLING SOFTWARE
First you need to check if your computer recognizes Azeron keypad. Plug
in USB cable in PC. Go to Start –Control Panel –Devices and Printers, and
see if under Devices shows up Azeron keypad.
If it doesn’t, and the LED lights are not turning on, make sure the USB
cable is connected to the keypad properly. The USB cable should look like
this when fully plugged in:
Page | 8
| Manual
We are constantly working on new features and improvements, so make
sure to go to our website (https://www.azeron.eu/downloads/) and
download the latest Azeron software.
When shipping out the keypad to you, it has already pre-installed latest firmware. So
by default you don’t need to install that. You need it only in case you have some
problems and need to reinstall the firmware. Go to HOW TO UPDATE FIRMWARE
MANUALLY for step by step guide.
Go to the directory where you downloaded the software, then double
click on Azeron-setup-vX.XX.X to install the software.
Sometimes Windows may prevent installation, because it is a new
software it doesn’t recognize:
Page | 9
| Manual
Just click on the “More info” and then on “Run anyway”.
After that, the software will start to install. When it’s done, there will be
a shortcut icon on Desktop and in the Start menu.
Plug in the USB cable of the keypad in PC and then launch the Azeron
software.
If you are not sure if your PC has the USB3.0 motherboard drivers installed, then we
would suggest to use USB 2.0 port to avoid unpredictable behavior of the keypad
recognition.
