Axon Synapse GPI16 Manual de usuario
____________________________________________
GPI16
Universal GPI Card with 10 GPI inputs
and 16 GPI outputs
Lange Wagenstraat 55
NL-5126 BB Gilze
The Netherlands
Phone: +31 161 850 450
Fax: +31 161 850 499
E-mail: [email protected]
Web: www.axon.tv
TECHNICAL MANUAL
GPI16
Universal GPI Card with 10 GPI inputs
and 16 GPI outputs
1
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
●ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product
frame (SFR18 or SFR04) must be terminated with three-conductor AC mains power cord that includes an
earth ground connection. To prevent shock hazard, all three connections must always be used.
●NEVER use flammable or combustible chemicals for cleaning components.
●NEVER operate this product if any cover is removed.
●NEVER wet the inside of this product with any liquid.
●NEVER pour or spill liquids directly onto this unit.
●NEVER block airflow through ventilation slots.
●NEVER bypass any fuse.
●NEVER replace any fuse with a value or type other than those specified.
●NEVER attempt to repair this product. If a problem occurs, contact your local Axon distributor.
●NEVER expose this product to extremely high or low temperatures.
●NEVER operate this product in an explosive atmosphere.
Warranty: Axon warrants their products according to the warranty policy as described in the general terms.
That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not
removed.
Copyright © 2001 – 2006 AXON Digital Design B.V.
Date created: 07-01-02
Date last revised: 11-11-06
Axon, the Axon logo and Synapse are trademarks of Axon Digital Design B.V.
This product complies with the requirements of the product family standards for audio, video, audio-visual
entertainment lighting control apparatus for professional use as mentioned below.
EN60950
EN55103-1: 1996
EN55103-2: 1996
Safety
Emission
Immunity
Axon Digital Design GPI16
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) This device may cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
2
Table of Contents
Chapter 1 Introduction to Synapse 3
An introduction to Synapse 3
Local Control Panel 3
Remote Control Capabilities 3
Chapter 2 Unpacking and Placement 4
Unpacking 4
Locating the card 4
Chapter 3 A Quick Start 5
When powering-up 5
Default settings 5
Changing parameters and settings 5
Front Panel Control 5
Example of changing parameter using
Front Panel control
6
Synapse Setup Software 7
Menu Structure Example 7
Chapter 4 The GPI16 card 8
Introduction 8
Key Features 8
Chapter 5 Settings Menu 9
Chapter 6 Status Menu 12
Chapter 7 Events 13
Chapter 8 LED Indication 15
Chapter 9 Connection Details 16
Chapter 10 Block Schematic 17
Chapter 11 Connector Panel 18
3
1 Introduction to Synapse
An Introduction to
Synapse Synapse is a modular system designed for the broadcast industry.
High density, intuitive operation and high quality processing are key
features of this system. Synapse offers a full range of converters and
processing modules. Please visit the AXON Digital Design Website
at www.axon.tv to obtain the latest information on our new products
and updates.
Local Control Panel The local control panel gives access to all adjustable parameters and
provides status information for any of the cards in the Synapse frame,
including the Synapse rack controller. The local control panel is also
used to back-up and restore card settings. Please refer to the RRC18,
RRC10 and RRC04 manuals for a detailed description of the local
control panel, the way to set-up remote control over IP and for frame
related settings and status information.
Remote Control
Capabilities The remote control options are explained in the rack controller
(RRC18/RRC10/RRC04/RRS18/RRS04) manual. The method of
connection to a computer using Ethernet is described in the RRC
manual.
! CHECK-OUT: “SYNAPSE SET-UP” SOFTWARE WILL
INCREASE SYSTEM FLEXIBILITY OF ONE OR MORE
SYNAPSE FRAMES
Although not required to Setup a Synapse frame, you are strongly
advised to use a remote personal computer or laptop PC with the
Synapse Setup software as this increases the ease of use and
understanding of the modules.
4
2Unpacking and Placement
Unpacking The Axon Synapse card must be unpacked in an anti-static
environment. Care must be taken NOT to touch components on the
card – always handle the card carefully by the edges. The card must
be stored and shipped in anti-static packaging. Ensuring that these
precautions are followed will prevent premature failure from
components mounted on the board.
Locating the card The Synapse card can be placed vertically in an SFR18 frame or
horizontally in an SFR04 frame. Locate the two guide slots to be
used, slide in the mounted circuit board, and push it firmly to locate
the connectors.
Correct insertion of card is essential as a card that is not located
properly may show valid indicators, but does not function correctly.
REMARK: On power up all LEDs will light for a few seconds, this is
the time it takes to initialise the card.
5
3A Quick Start
When Powering-up On powering up the Synapse frame, the card set will use basic data
and default initialisation settings. All LEDs will light during this
process. After initialisation, several LEDs will remain lit – the exact
number and configuration is dependant upon the number of inputs
connected and the status of the inputs.
Default settings In the default condition, the GPI16 acts as a universal GPI input &
Output card for the Synapse SFR18/SFR04 frame.
Changing settings
and parameters The front panel controls or the Synapse Set-Up Software can be used
to change settings. An overview of the settings can be found in
chapter 5, 6 and 7 of this manual.
Front Panel Control Front Panel Display and Cursor
Settings are displayed and changed as follows;
Use the cursor ‘arrows’ on the front panel to select the menu and
parameter to be displayed and/or changed.
Press ►
To go forward through the menu structure.
Press ◄
To go back through the menu structure.
Press ▲
To move up within a menu or increase the value of a parameter.
Press ▼
To move down through a menu or decrease the value of a parameter.
REMARK: Whilst editing a setting, pressing ►twice will reset the
value to its default.
[
No Alarms]
6
Example of
changing
parameters using
front panel control
With the display as shown below
Pressing the ►selects the SFS10 in frame slot 01.
The display changes to indicate that the SFS10 has been selected. In
this example the Settings menu item is indicated.
Pressing the ►selects the menu item shown, in this example
Settings.
(Pressing ▲or ▼will change to a different menu eg Status,
Events).
The display changes to indicate that the SFS10 Settings menu
item SDI-Format has been selected and shows that it current
setting is Auto.
Pressing the ►selects the settings item shown, in this example SDI-
Format.
(Pressing ▲or ▼will change to a different setting, eg Mode, H-
Delay).
The display changes to indicate that the SFS10 Edit Setting
menu item SDI-Format has been selected.
To edit the setting of the menu item press ▲or ▼.
All menu items can be monitored and/or changed in this way.
Changing a setting has an immediate effect.
RRC18 [Select Card]
>S01=SFS10
SFS10 [Select Menu]
>Settings
SFS10 [Settings]
>SDI
-
F
ormat=Auto
SFS10 [Edit
Setting]
7
Synapse Setup
Software
Synapse Setup Software can be used to change the settings of
Synapse modules from a PC, either locally or remotely. The software
enables communication based on TCP/IP between the Setup PC and
Synapse frames/modules.
Each Synapse frame is addressed through its rack controller’s unique
IP address, giving access to each module, its menus and adjustment
items. The Synapse Setup software has access to data contained
within the Synapse module and displays it on a GUI. The software
has an intuitive structure following that of the module that it is
controlling.
Having selected the desired Frame and Module from the GUI
Synapse Network View, select the menu item that you wish to open.
Opening the menu item gives a complete list of available properties
with their associated Value.
For example to change a setting e.g. SDI-Format, select SDI-Format
form the list of settings by ‘double clicking’ to open a dialogue box.
The dialogue box allows parameters to be changed or set to default
value. On completion close the dialogue box.
Menu Structure
Example
Slot Module Item Parameter Setting
▲
▲
S02 Identity
▲▲
S01 SFS10 ►Settings ►SDI-
Format
►Auto
▼▼▼▼
S00 RRC18 Status Mode 625
▼▼▼
Events Ref-Input 525
▼
H-Delay
▼
▼
REMARK: Further information about Front Panel Control and
Synapse Setup Software can be obtained from the RRC18 and
RRC04 operational manuals.
8
4 The GPI16 Card
Introduction The AXON GPI16 card is a universal Synapse GPI I/O
(Input/Output) card. The card is capable of forcing GPI output
triggering based on events that are generated by cards located in the
same rack. (E.g. An alarm/event generated by any specific card in
frame. This alarm/event is put on the bus. The GPI16 card will
monitor the internal bus for events and close a relay in case of an
event.)
The GPI16 can also be used as a slave card for Synapse functions, the
8x1 switcher or the VWI10 card for example. In these applications it
is possible to control functions directly in to a Master, e.g. GPI based
channel selection of the 8x1 switcher SDX08.
Back planes The GPI16 can be used with the BPL06 backplane.
Miscellaneous The GPI16 cards fit into the Axon SFR18 or SFR04 rack.
LEDs on the front of the board indicate the presence of electrical
input signals & Processor Errors.
The GPI16 can be controlled by Axon Synapse Set-Up Software.
