Axis Q6100-E Manual de usuario

Q6100-ENetworkCamera

RepaintingInstructions

Q6100-ENetworkCamera

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

Q6100-ENetworkCamera

Repainttheproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Q6100-ENetworkCamera

Repainttheproduct

Disassembly

1Coverring

2Domering

Q6100-ENetworkCamera

Repainttheproduct

1.Loosenthefourscrewsfromthedomeringandremovethecoverring.

2.Removethefourscrewsfromthedomering.

3.Slowlylifttheinneredgeofthedomering.Becarefulnottoscratchordentthedome.

4.Carefullylifttheinneredgeallwayroundtoreleasethedomering.

5.Removethesixscrewsfromtheringandremovetheringfromthedome.

Repainting

1.Maskthedomeincludingtheedgeandthethreemicrophonemeshes.

2.Placethedomeonthecameraunit.Makesuretheedgeofthetopcovercanbepainted.

3.Placetheringontopofthemaskeddome.

Q6100-ENetworkCamera

Repainttheproduct

4.Masktheholderhookandallholes.

5.Makesureallnecessarypreparationsofthecameraunitandthecoverringhavebeenmade.SeePreparationsonpage3.

Note

TheSDlidshouldnotberemovedduringrepainting,orelsetheSDlidgasketwillbedamaged.

6.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

7.Letthepaintdry.

8.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

9.Whenthepaintisdry,removethemasking.

Q6100-ENetworkCamera

Repainttheproduct

Reassembly

1.Reassemblethedomerings(6screws,0.7Nm).

2.Reassemblethecoverring(4screws).

Q6100-ENetworkCamera

Repainttheproduct

3.Attachthedomeassemblytothecamera(2Nm).

RepaintingInstructionsVer.M1.5

Q6100-ENetworkCameraDate:August2020

©AxisCommunicationsAB,2020PartNo.T10154780
