Axis Q6010-E Manual de usuario

Q6010-ENetworkCamera

RepaintingInstructions

Q6010-ENetworkCamera

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

Q6010-ENetworkCamera

Repainttheproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Q6010-ENetworkCamera

Repainttheproduct

Disassembly

T30

1Coverring

2Domering

1.Loosenthefourscrewsandremovethecoverring.

2.Removethefourscrewsfromthecoverring.

3.Slowlylifttheinneredgeofthedomering.Becarefulnottoscratchordentthedomering.

4.Carefullylifttheinneredgeallwayroundtoreleasethedomering.

Q6010-ENetworkCamera

Repainttheproduct

Repainting

1.Maskthedomeringincludingtheedge.

2.Placethedomeringonthecameraunit.Makesuretheedgeofthetopcovercanbepainted.

3.Masktheholderhookandallholes.

4.Makesureallnecessarypreparationsofthecameraunitandthecoverringhavebeenmade.SeePreparationsonpage3.

Note

TheSDlidshouldnotberemovedduringrepainting,orelsetheSDlidgasketwillbedamaged.

Q6010-ENetworkCamera

Repainttheproduct

5.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

6.Letthepaintdry.

7.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

8.Whenthepaintisdry,removethemasking.

Q6010-ENetworkCamera

Repainttheproduct

Reassembly

T30

2.0 N m

(1.48 lb ft)

1.Reassemblethedomering.

2.Reassemblethecoverring(4screws).

RepaintingInstructionsVer.M1.5

Q6010-ENetworkCameraDate:July2020

©AxisCommunicationsAB,2020PartNo.T10154781
