RepaintingInstructions

AXISP14CameraSeries

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

AXISP14CameraSeries

Repainttheproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

isassembly

1Backplate

2Bottombasecover

3Cameraunit

4Holer

5Weathershiel

6Li

AXISP14CameraSeries

Repainttheproduct

1.Removethebottombasecover.

2.Removethelidfromthebottombasecover.

3.Removetheweathershield.

4.Removetheholderfromtheweathershield.

7Lockscrew

8Screw

9Armcover

10Pin

5.Removethelockscrew,thescrewsandthearmcover.

6.Removethepin.

AXISP14CameraSeries

Repainttheproduct

Masking

1.Makesureallnecessarypreparationsofthecameraunithasbeenmade.SeePreparationsonpage3.

2.Maskallscrewandscrewholes.

3.Masktheentiretopsurfaceofthebottombasecover.

4.Masktheentirebottomsurfaceofthebottombasecover.

5.Maskthebackofthelid.

6.Masktheundersideoftheweathershield.

7.Masktheholder.

8.Masktheinsideofthearmcover.

9.Maskeverythingbetweenthefootandtheballjoint.

10.Masktheslotsfortheweathershield.

11.Maskthefrontofthecamera.

Repainting

1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

2.Letthepaintdry.

3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

4.Whenthepaintisdry,removethemasking.

AXISP14CameraSeries

Repainttheproduct

Reassembly

1.Placethepinintherecessinthearm.

2.Attachthearmcover,thefourscrewsandthelockscrew.Donottightenthelockscrew.Tightenthefourscrewswith1

Nm(0.7lbft)tighteningtorue.

3.Attachtheweathershield.

4.Reassemblethecamera.Tightenthescrewswith1.2Nm(0.9lbft)tighteningtorue.

RepaintingInstructionsVer.M1.2

AXISP14CameraSeriesDate:June2021

©AxisCommunicationsAB,2021PartNo.T10168119
