Axis P12 Series Manual de usuario

AXISP12ThermalNetworkCameraSeries

AXISP1280–EThermalNetworkCamera

AXISP1290–EThermalNetworkCamera

UserManual

AXISP12ThermalNetworkCameraSeries

TableofContents

ProductoverviewAXISP1280-E...............................3

ProductoverviewAXISP1290-E...............................4

Sensorunits...............................................6

Connectsensorunits.............................................6

Findthedeviceonthenetwork................................7

Accessthedevice...............................................7

Securepasswords...............................................7

Additionalsettings..........................................8

Webpageoverview..............................................8

Imagequalit...................................................10

Privacmasks..................................................10

Overlas.......................................................1 1

Streamingandstorage...........................................1 1

Events........................................................15

Applications....................................................16

roubleshooting............................................17

Resettofactordefaultsettings...................................17

Checkthecurrentrmware.......................................17

Upgradethermware............................................17

Technicalissues,cluesandsolutions................................18

Performanceconsiderations.......................................19

Specications..............................................20

SDcardslot....................................................20

Buttons.......................................................20

Connectors....................................................20

AXISP12ThermalNetworkCameraSeries

ProductoverviewAXISP120-E

AXISP12MkIIMainUnit

1StatusLED

2Controlbutton

3RJ12connector

4Netorkconnector(PoE)

5SDcardslot(microSDcard)

AXISFA1080ThermalSensorunit

1Sensorunit

2RJ12connector

AXISP12ThermalNetworkCameraSeries

ProductoverviewAXISP1290-E

AXISP12ThermalMainUnit

1StatusLED

2Controlbutton

3RJ12connector

4Netorkconnector(PoE)

5SDcardslot(microSDcard)

AXISP12ThermalNetworkCameraSeries

ProductoverviewAXISP1290-E

AXISFA4090–EThermalSensorunit

1Domecover

2Lockring

3Sensorunit

4RJ12connector

5Hardceilingmount(useasrequired)

AXISP12ThermalNetworkCameraSeries

Sensorunits

Connetsensorunits

Whenouconnectasensorunittoamainunit,werecommendthatoumaketheconnectionbeforeoupowerupthemainunit.If

oudisconnectasensorunitandconnectadifferentone,itmabenecessartorestartthemainunit.

Shortenthesensorunitable

Note

Thiscablecanonlbeshortened,notextendedormodiedinanotherwa.

Thesensorunitisdeliveredwithacable.Toshortenthecablefollowthesesteps:

1.Cutthecabletothedesiredlength.Measurefromthesensorunit.

2.Striptheplasticoutercoatingfromtheendofthecable.

3.Peelbacktheshield.

4.Flattenthecoloredwiresintheorderdescribedbelow.

1Brown

2White/brown

3Notused

4Notused

5White/blue

6Blue

NO NO

NOTICE TICE

TICE

Makesurethatthewiresstainthecorrectorderandthatthecableshieldmakesgoodcontactwiththeconnectorshield.

5.Insertthewiresallthewaintoashielded6P6CRJ12connector.

6.Useacrimpingtooltofastentheconnectortothecable.

AXISP12ThermalNetworkCameraSeries

Findthedeviceonthenetwork

TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilitorAXISDeviceManager.Both

applicationsarefreeandcanbedownloadedfromaxis.com/support.

FormoreinformationabouthowtondandassignIPaddresses,seethedocumentHotoassignanIPaddressandaccessyour

deviceonthedevicepageataxis.com.

Aessthedevie

1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.

IfouhaveaMaccomputer(OSX),gotoSafari,clickBonjourandselectthedevicefromthedrop-downlist.Toadd

Bonjourasabrowserbookmark,gotoSafari>Preferences.

IfoudonotknowtheIPaddress,useAXISIPUtilitorAXISDeviceManagertondthedeviceonthenetwork.

2.Entertheusernameandpassword.Ifouaccessthedeviceforthersttime,oumustsettherootpassword.SeeSeta

nepassordfortherootaccountonpage7.

3.Theliveviewpageopensinourbrowser.

Seurepasswords

Important

Axisdevicessendtheinitiallsetpasswordincleartextoverthenetwork.Toprotectourdeviceaftertherstlogin,set

upasecureandencrptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimarprotectionforourdataandservices.Axisdevicesdonotimposeapasswordpolicasthe

mabeusedinvarioustpesofinstallations.

Toprotectourdatawestronglrecommendthatou:

•Useapasswordwithatleast8characters,preferablcreatedbapasswordgenerator.

•Don’texposethepassword.

•Changethepasswordatarecurringinterval,atleastonceaear.

Setanewpasswordfortherootaount

Important

Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactordefaultsettings.

1.Tpeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepassordsonpage7.

2.Retpethepasswordtoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

AXISP12ThermalNetworkCameraSeries

Additionalsettings

Webpageoverview

1Liveviecontrolbar

2Livevie

3Productname

4Userinformation,colorthemes,andhelp

5Videocontrolbar

6Settingstoggle

AXISP12ThermalNetworkCameraSeries

Additionalsettings

7Settingstabs

Needmorehelp?

Youcanaccessthebuilt-inhelpfromthedevice’swebpage.Thehelpprovidesmoredetailedinformationonthedevice’sfeaturesand

theirsettings.

AXISP12ThermalNetworkCameraSeries

Additionalsettings

Imagequality

Monitorlongandnarrowareas

Usecorridorformattobetterutilizethefulleldofviewinalongandnarrowarea,forexampleastaircase,hallwa,road,ortunnel.

1.Dependingonourdevice,turnthecameraorthe3-axislensinthecamera90°or270°.

2.Ifthedevicedoesn’trotatetheviewautomaticall,logintothewebpageandgotoSettings>System>Orientation.

3.Click.

4.Rotatetheview90°or270°.

Findoutmoreataxis.com/axis-corridor-format.

Colorpalettes

Colorpalettesappliedtothermalimageshelpthehumaneedistinguishimagedetails.Thecolorsinthepalettearearticiall

createdpseudocolorsthatemphasizetemperaturedifferences.

Theproducthasseveralcolorpalettestochoosefrom.Ifanoperatorwatchesthevideostream,oucanchooseanofthepalettes.If

thevideostreamisonlusedbapplications,selectthewhite-hotpalette.

Privaymasks

Aprivacmaskisauser-denedareathatpreventsusersfromviewingapartofthemonitoredarea.Inthevideostream,privac

masksappearasblocksofsolidcolor.

You’llseetheprivacmaskonallsnapshots,recordedvideo,andlivestreams.

YoucanusetheVAPIX®applicationprogramminginterface(API)toturnofftheprivacmasks.

Important

Ifouusemultipleprivacmasksitmaaffecttheproduct’sperformance.

Hidepartsoftheimagewithprivaymasks

Youcancreateoneorseveralprivacmaskstohidepartsoftheimage.

1.GotoSettings>Privacymask.

2.ClickNew.
