Axis AXIS 215 PTZ-E Manual de usuario

ENGLISH

INSTALLATION GUIDE

AXIS 215 PTZ-E Network Camera

Safety Information

Follow these instructions to complete

the installation of the AXIS 215 PTZ-E network

camera.

Warning!

High voltage - the electrical connection must be

made by an authorized electrician. Please observe

relevant national and local regulations for the

installation.

Safety Rules

• Only qualified technical personnel must install

this device.

• Disconnect the power supply before any tech-

nical work on the appliance.

• Do not use old or worn out power supply

cables.

• Never make changes or connections that are

not shown in this handbook; improper use of

the appliance may cause serious hazard and

may damage the product.

• Use original spare parts. Non-original spare

parts could cause fire, electrical discharge, or

other hazards.

• Before installing the device, check the sup-

plied material to make sure it corresponds

with the order specification.

• Please retain this manual for future reference.

AXIS 215 PTZ-E Installation Guide Page 3

ENGLISH

AXIS 215 PTZ-E Network Camera

Installation Guide

This product is an out-of-the-box PTZ camera comprising the AXIS 215 PTZ network camera pre-

mounted in a weather-proof housing. The AXIS 215 PTZ-E network camera can be used in both

indoor and outdoor installations. This guide provides instructions for installing this product.

For all other aspects of using the product, please see the Installation Guide for the AXIS 215 PTZ

network camera included in this package, and the user’s manual for the AXIS 215 PTZ network

camera available from www.axis.com/techsup

Installation steps

1. Check the package contents against the Package contents list below.

2. Overview. See page 4.

3. Before installation. See page 4.

4. Installation. See page 5.

5. Technical specifications. See page 6.

Package contents

Item Models/variants/notes

AXIS 215 PTZ-E Network

Camera

Three allen keys 2mm, 3mm, and 5 mm

1.5 national pipe thread

(NPT) adaptor

Drill template

Printed materials AXIS 215 PTZ-E Network Camera Installation Guide (this document)

AXIS 215 PTZ Network Camera Installation Guide

Axis warranty document

Important!

This product must be used in

compliance with local laws and

regulations.

Page 4 AXIS 215 PTZ-E Installation Guide

Overview

Before installation

Before Installation, it is important to remove all protective packing material from the camera

according to the steps below. Do not start the camera until all protective packing has been

removed, or the camera will be damaged.

1. Place the AXIS 215 PTZ-E network camera on a clean, solid surface.

2. Loosen the four screws holding the dome (using the 3-mm allen key). Make sure the o-ring on

the screw is in place.

3. Carefully unwrap the AXIS 215 PTZ-E Network Camera.

4. Carefully remove the packing between the housing and sunshield. See drawing.

5. Make sure that the dome is clean on the inside and that the o-ring around it is in place.

6. Attach the dome and tighten the four screws firmly.

screws attached to

wall bracket

screws attached

to sunshield

screws for dome

packing between housing

and sunshield

AXIS 215 PTZ-E Installation Guide Page 5

ENGLISH

Installation

Wall mounting

1. Using the drill template provided, drill four holes on the wall.

2. Place the AXIS 215 PTZ-E network camera to the wall and attach it using four screws

appropriate to the wall material.

Ceiling mount

1. Remove the wall bracket by unscrewing the four screws attached to it, using the 5-mm allen

key provided.

2. Remove the sunshield (optional) by unscrewing the three screws attached to it, using the 2-mm

allen key provided.

3. Screw the NPT adaptor onto a pole in the ceiling.

4. Attach the AXIS 215 PTZ-E network camera to the NPT adaptor using the four large screws.

Connecting the cables

1. Connect the 5m-power cable to a power connector (100-240VAC, 1.2A, 50/60Hz) using the

three wires - L, N, and GND.

2. Connect the camera to the network using the 5m CAT5E network cable.

Please refer to the Assign an IP address chapter in the AXIS 215 PTZ installation guide to assign an

IP address to the camera.

Note - Appropriate protection is required for the power and Ethernet cable in the case of out-

door installation.

INPUT

100-240VAC

LNGND

brown blue yellow-green

Page 6 AXIS 215 PTZ-E Installation Guide

Technical Specifications

Camera Model • AXIS 215 PTZ-E: 50 Hz (PAL)

• AXIS 215 PTZ-E: 60 Hz (NTSC)

Image sensor 1/4” interlaced CCD

Lens 3.8 – 46 mm, F1.6 – F2.7, automatic day/night, autofocus

Angle of view, horizontal: 4.4° – 51.6°

Minimum

illumination

Color: 1 lux at 30IRE, F1.6

B/W: 0.3 lux at 30IRE, F1.6

Shutter time NTSC: 1/50000 – 4/3 s

PAL: 1/50000 – 8/5 s

Pan/Tilt/Zoom 20 preset positions

Auto-flip, E-flip

±170° (360° via Auto-flip) pan range, 180°/s pan speed

180° tilt range, 140°/s tilt speed

12x optical, 4x digital zoom

Control queue, image freeze, sequence mode

Support Windows compatible joysticks

Designed for operator control

Video Video

compression

MPEG-4 Part 2 (ISO/IEC 14496-2)

Motion JPEG

Resolutions 704x480 to 176x120 (NTSC)

704x576 to 176x144 (PAL)

Framerate

MPEG-4

Up to 30/25 (NTSC/PAL) in 2CIF/CIF/QCIF

Up to 26/22 (NTSC/PAL) in 4CIF/2CIFExp

Frame rate

Motion JPEG

Up to 30/25 (NTSC/PAL) in all resolutions

Video streaming Simultaneous MPEG-4 and Motion JPEG

Controllable frame rate and bandwidth

VBR/CBR MPEG-4

ISMA compatible

Image settings Compression, color, brightness, sharpness, white balance, exposure

control, backlight compensation, day/night

Rotation 0 – 180º

Aspect ratio correction

Text and image overlay

De-interlace (4CIF resolution)

Network Security Password protection, IP address filtering, HTTPS encryption,

IEEE 802.1X network access control

Supported

protocols

IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,

UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP,

TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS

AXIS 215 PTZ-E Installation Guide Page 7

ENGLISH

System

integration

Application

Programming

Interface

Open API for software integration, including VAPIX®

from Axis Communications available at www.axis.com

Intelligent

video

Video motion detection

Alarm triggers Intelligent video

Alarm events File upload via FTP, HTTP and email

Notification via email, HTTP and TCP

Video buffer 9 MB pre-and post alarm

General Casing IP66-rated, rugged aluminum casing with clear dome bubble

Processors and

memory

ETRAX FS, ARTPEC-2, 32 MB RAM, 8 MB Flash

Power 100 - 230 V AC: 1.1 A at 110 V AC, 0.6 A at 230 V AC

Pre-installed 5 m (16.4 ft.) power cable without mains plug

Connectors RJ-45 for 10BASE-T/100BASE-TX

Pre-installed 5 m (16.4 ft.) Cat-5e cable

Operating

conditions

-20 to 40 °C (-4 to 104 °F)

2 built-in heaters, 3 built-in fans

Approvals EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3,

EN 60950-1, FCC Part 15 Subpart B Class B, ICES-003 Class B,

C-tick AS/NZS 3548

Power supply: UL, CSA, CE

Weight 4.8 kg (10.6 lb.) incl. cables, excl. wall bracket and sunshield

6.1 kg (13.4 lb.) incl. cables, wall bracket and sunshield

Optional

accessories

Corner mount, pole mount, AXIS 295 Video Surveillance Joystick,

AXIS T90A illuminators

Included

accessories

1.5" NPT adapter, Installation Guide, CD with User's Manual,

recording software, installation and management tools, Windows

decoder 1-user license

Page 8 AXIS 215 PTZ-E Installation Guide

AXIS 215 PTZ-E Installation Guide - Appendix A Page 9

ENGLISH

Appendix A

Installing audio and I/O cables

AXIS 215 PTZ-E Network Camera is delivered without hardware support for audio and I/O. However

it is possible to install cables for these.

Important!

• Installing the cables for audio and I/O must be done only by an authorized technician.

• Installing audio and I/O cables will nullify the IP-66 rating and AXIS 215 PTZ-E Network

Camera will no longer be suitable for outdoor use.

Follow these steps to install the audio and I/O cables:

1. Remove the wall bracket.

2. Remove the sunshield.

cut and remove the rubber gasket.

Caution: Make sure not to damage the cables

3. Unscrew the cable gland;

while removing the rubber gasket. The rubber

gasket is now no longer usable, and the IP-66 rating

is no longer valid.

Page 10 AXIS 215 PTZ-E Installation Guide

7. Pull the I/O or audio cable

through the casing and cable gland

to the camera connection.

For more information on how to

connect I/O and audio, please refer

to the AXIS 215 PTZ Network

Camera’s user manual delivered

with this pack.

9. Work backwards from step 6 to

re-assemble the parts.

4. Remove the top by

unscrewing 3 screws.

5. Remove the

loosening

dome by

the 4 screws.

6. Remove the black (fan-and-

heater) ring by unscrewing

4 screws.
