AXIS Camera Station

Installation Guide

AXIS Camera Station Installation Guide Page 3

ENGLISH

AXIS Camera Station

Installation Guide

Minimum recommended requirements

Install AXIS Camera Station on a stand-alone computer dedicated

mainly for running this application

Hardware:

• Intel Pentium 4 with 2 GHz processor

•CD-drive

•512MBRAM

• Hard disk: 1 GB available space for installation

• NTFS file system

• XGA (1024 x 768) or higher resolution monitor

• AGP Graphic card, Direct Draw (for MPEG-2/4) with 32 MB or more memory

• 100 MB Ethernet with a static IP address

System:

• Microsoft Vista Business, Microsoft Windows XP Professional SP2,

2000 (SP4) 2003 Server (SP1), Internet Explorer Version 6.0 or later, DirectX

9.0c or later (for MPEG 2/4)

• TCP/IP support

• Internet Information Server (IIS) - for Web client

• Microsoft .NET 2.0 runtime environment (included in installation package)

Minimum recommended requirements for a full 25 camera

system:

• Dual XEON 3 Ghz, 1024 MB RAM, Multiple SCSI disks

• 1000 Mbit Ethernet backbone

Page 4 AXIS Camera Station Installation Guide

Overview

This document will help you install AXIS Camera Station and

configure it for your Axis Network Cameras and Axis Video

Servers. A brief introduction to the functionality of the software is

covered here, see the online Help or the AXIS Camera Station User’s

Manual for a detailed description. The User’s Manual is available on

the CD and on www.axis.com

AXIS Camera Station is a complete monitoring and recording

system for use with Axis Network Cameras and Video Servers.

The application's main window provides quick and easy access to

all connected and configured cameras, recordings, inputs and

outputs used in the system. A background service in Windows,

AXIS Camera Station will start automatically upon system start-up

and continue running even after the user logs out.

Configuration

All dialogs that allow control and configuration of all aspects of the

AXIS Camera Station system are found under Options in the menu.

Remote clients

For remote clients you can use “AXIS Camera Station Client”

described on page 21 or “AXIS Camera Station Web Application”

described on page 23.

AXIS Camera Station Installation Guide Page 5

ENGLISH

Network Configuration

AXIS Camera Station can record and play back video from

cameras that are connected over a LAN (Local Area Network) or

over a WAN (Wide Area Network).

LAN

The cameras can be connected directly to the server running AXIS

Camera Station using an Ethernet network.

Internet (WAN)

To access AXIS Camera Station from the Internet and get live

images from the cameras you must open a set of IP addresses and

port numbers in your firewall configuration.

See Network Configuration in AXIS Camera Station user’s manual.

Page 6 AXIS Camera Station Installation Guide

See the User’s Manual for details, available on the CD and on www.axis.com

AXIS Camera Station Installation Guide Page 7

ENGLISH

Install AXIS Camera Station Software

Install AXIS Camera Station on the dedicated stand-alone PC from

where you wish to run the main administration of your cameras

and video servers.

1. Insert the CD in the CD drive. If the installation CD does not

auto-start, click autorun.exe in the CD’s root folder.

2. From the CD’s interface, click Software and then AXIS

Camera Station

3. Select the preferred language to install.

Note:

You may be prompted to install .NET Framework. Simply follow the Installation

Wizard’s instruction.

4. Next, you will be asked where you wish to install the

program. If nothing is specified the program is normally

installed in C:\Program Files\Axis Communications\AXIS

Camera Station.

5. Click your way through the Installation Wizard.

Note:

If running Windows XP, you will need to permit the firewall to accept incoming

requests from AXIS Camera Station Client when prompted.

Page 8 AXIS Camera Station Installation Guide

6. When the installation is finished, open AXIS Camera Station

from Start > All Programs or click the program icon on

your desktop:

AXIS Camera Station Installation Guide Page 9

ENGLISH

AXIS Camera Station Activation

The first time you start the program you will be asked to register

your license.

Activate the software with your License Key

The License Key can be used for only one current installation.

Once registered, it cannot be used again. Do not request the access

code to activate the software until AXIS Camera Station is

installed on the target computer.

The License Key is your proof of purchase, keep it in a safe place

for future reference.

Important!

When entering the License Key and Access Code, remember that they are both case

sensitive.

License

A base license is required to run AXIS Camera Station and allows

for a specified number of cameras to be used with the program.

Licenses for additional cameras can be installed under Options >

General Settings > License, see AXIS Camera Station User’s

Manual for more information.

Licenses for the AXIS Image Enhancer component can also be

installed if you want to improve the image quality in poor

visibility conditions, such as fog, smoke, rain and snow.

Page 10 AXIS Camera Station Installation Guide

There are two types of upgrade licenses available for purchase at

your local Axis reseller:

•Additional camera license.

•Software upgrade license. You can upgrade AXIS

Camera Station for a limited time from www.axis.com

and then extend the license.

Licenses and the time period remaining are displayed in the

software interface. MyAxis (www.axis.com/reg/) shows your

registered licenses and activation dates.

Fast Internet connection:

If AXIS Camera Station is installed on a computer with fast Internet

access you can register automatically. Your license information is

sent directly to the Axis Web server.

1. Select Licensed Version and click on the OK button.
