JS5001

5 INCH HEAVY DUTY LED MONITOR

INSTRUCTION MANUAL

SPECIFICATIONS

- TFT Panel: New Grade A LCD

LED Backlight

- LCD Size: 125mm (5-Inch) Diagonal

- Display Format: 16:9

- Resolution: 800 x 480

- Brightness: < 450 CD/M2

- Viewing Angles: 90 Deg. Left/Right/Up/Down

- Video System: Auto PAL/NTSC Select

- Video Connections: 2 x 4-Pin (Female)

- Reverse Trigger: Input Assignable

- Camera View: Input Override in Reverse Mode

- Monitor View: Normal/Mirror Image Select

- Guidelines: Selectable

- Audio: On Board Speaker

- Main Menu: Brightness/Contrast/Colour/Volume/Reset/

Slideshow/Language/Reverse Priority & Delay

- Casing Material: 100°C Heat/Flame Proof (UL94V-0) ABS Material

- Power Input: 10-32V DC (Negative Ground)

- Dimensions: 136W x 102H x 25D mm (excluding brackets)

- Included: Stand Mount, U-Shape Mount, Remote Control,

Power Cable Assembly, Sunshade

Optional: Glass Mount Bracket (BKT101)

2

Thank you for choosing this versatile AXIS monitor!

Please take time to read through the simple instructions below.

CAUTIONS:

• Securely install the monitor in a location that will not hinder driver vision

or control.

• Keep the monitor away from moisture and heat sources

• Clean the display with a soft dry cloth. Do not use chemical cleaners.

MONITOR FUNCTIONS:

1. Remote Control Receiver

2. Decrease Button

3. Increase Button

4. Power On/O󰀨

5. Menu Button

6. Camera Selection (to change between cameras)

REMOTE CONTROL:

• Aim directly at the reception window

• Replace battery (CR2025) if the range reduces or will not operate.

(1) Mute

(2) Power

(3) AV

(4) Menu

(5) Decrease

(6) Increase

(7) Orientation

[Up/Down/Left/Right]

P.P

MENU

A V

(to adjust settings in Menu)

}

2 3 4 5 6

Built-In

Speaker

1

5

7

2

6

3

4

3

CONNECTIONS:

ACCESSORIES:

9 Pin Male4 Pin Female Video V1

4 Pin Female Video V2

16:9/4:3

12

34

56

7

8

9

10

1. Mute button

2. Power On/Off

3. AV

4. Menu

5. Decrease Button

6. Increase Button

7. Switch

8. Time switch

9. Display selection

Green - Reverse Trigger

Black - Ground

Brown - Dimmer Control

Red - 12 - 24V

Note: Cam 2 has reverse trigger control.

4-Pin Locking Socket (Female) Connection 4-Pin Locking Plug (Male) Connection

Denition: Connector Front View Denition: Connector Front View

VIDEO AUDIO

GROUNDPOWER

15m Lead

Leads &

Adaptors

Bracket Remote ControlU-shape MountSunshade

CONNECTIONS

ACCESSORIES

4

Press the Mbutton on the monitor or the MENU button on the remote

to open the menu. Press the M/MENU button repeatedly to scroll

through the di󰀨erent options. Press the left or right arrow to adjust the

settings.

(Note: Most of the settings only aect the camera currently being viewed. Press the

CAM button on the monitor or the AV button on the remote to change between camera

1 and camera 2.)

Brightness Adjust the brightness of the camera currently

being viewed.

Contrast Adjust the contrast of the camera currently

being viewed.

Colour Adjust the colour of the camera currently

being viewed.

Volume Adjust the volume of the camera currently

being viewed.

Display Adjust the aspect ratio (16:9 recommended).

Reversing Priority Select which camera is displayed when the

reverse trigger is engaged.

Reversing Delay Adjust the time delay between the vehicle

going into reverse and the reverse camera

being displayed.

Auto Slideshow The monitor will automatically change which

camera is displayed every 5 seconds.

TCON Flip the image of the camera currently being

viewed horizontally and/or vertically.

Guideline Displays guidelines when the reverse trigger

is engaged.

Language Set menu language.

Reset Reset to default settings.

Monitor Menu Instructions
