AXIS 295 Video Surveillance Joystick

AXIS 295

Video Surveillance Joystick

Installation Guide

AXIS 295 Video Surveillance Joystick

Safety Instructions

This equipment must be installed in strict accordance with the instructions

given in the user documentation. This equipment contains no user-

serviceable components. Unauthorized equipment changes or modifications

will invalidate all applicable regulatory certifications and approvals.

This product is for indoor use only. Be sure to install the product where it

will not be exposed to water or other liquids. For cleaning purposes use damp

tissues with a soft cleaner, do not use aggressive chemicals or abrasives.

Liability - Every care has been taken in the preparation of this manual.

Please inform your local Axis office of any inaccuracies or omissions. Axis

Communications AB cannot be held responsible for any technical or

typographical errors and reserves the right to make changes to the product

and manuals without prior notice. Axis Communications AB makes no

warranty of any kind with regard to the material contained within this

document, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Axis Communications

AB shall not be liable nor responsible for incidental or consequential

damages in connection with the furnishing, performance or use of this

material.

AXIS 295 Video Surveillance Joystick

Description

AXIS 295 is designed for applications developed for video surveillance

systems. The sensitivity allows for fast, flexible and secure operation with

Axis network cameras with pan, tilt and zoom functionality.

The function buttons - 10 on the panel, 2 on the handle - provide flexible

functionality for e.g. selecting surveillance cameras and taking snapshots.

Rotating handle

2 function buttons on top of handle

10 function buttons

USB cable

2m (3.3ft)

AXIS 295 Video Surveillance Joystick

System Requirements

• Windows 2000, Windows XP

• USB Port (USB 2.0 Standard)

Installation

1. Connect the USB plug to a USB port on your computer.

2. Follow the on-screen instructions (if applicable) to install the necessary

drivers.

3. The joystick will appear in the Game Controllers list in the Windows

Control Panel on your computer. Open Start > Control Panel > Game

Controllers.

AXIS 295 Video Surveillance Joystick

Troubleshooting

If you experience problems during the installation, please check the

following:

• Disconnect the USB plug from the computer, wait 10 seconds and

then reconnect.

• Move the USB plug to another available USB port on your

computer.

•Windows - verify that the operating system (Windows 2000/XP)

has identified the joystick under Control Panel > Game Controllers

and follow the troubleshooting steps provided.

Support

Should you require any technical assistance, please contact your Axis

reseller. If your questions cannot be answered immediately, your reseller will

forward your queries through the appropriate channels to ensure a rapid

response.

If you are connected to the Internet, visit the Axis Support at www.axis.com/

techsup where you can:

• download user documentation

• find answers to resolved problems in the FAQ database.

Search by product, category, or phrases

• report problems to Axis support by logging in to your private

support area

AXIS 295 Video Surveillance Joystick

Technical Specifications

Item Specification

Model AXIS 295 Video Surveillance Joystick

Material

Deflection X/Y-Axes: ±18°

Z-Axis: ±40°

Centering X/Y - Axes with central return spring

Z- Axis with spring

Protection degree IP50 / IEC60529

Storage temperature -55°C to +165°C

Operational temperature -25°C to +85°C

Interface USB 2.0 Standard

Power supply via USB interface (5V DC)

Weight 440g

Approvals EN55024:1998

EN55022

FCC Part 15 Subpart B, Class B

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following conditions: (1)

This device may not cause harmful interference, and

(2) this device must accept any interference

received, including interference that may cause

undesired operation. This Class B digital apparatus

complies with Canadian ICES-003.

• Housing: high impact ABS

• Handle: high impact glass reinforced nylon

• Boot: thermoplastic rubber

• Shaft: stainless steel

AXIS 295 Video Surveillance Joystick Installation Guide Rev. 1.0

Copyright © Axis Communications AB, 2006 Part No. 26393
