AXIOMTEK NA-100 Instrucciones de montaje
NA-100
Hardware Installation Guide
For service person only
ii
Disclaimers
The information in this manual has been carefully checked and is believed to be accurate.
AXIOMTEK Co., Ltd. assumes no responsibility for any infringements of patents or other rights of
third parties, which may result from its use.
AXIOMTEK assumes no responsibility for any inaccuracies that may be contained in this document.
AXIOMTEK makes no commitment to update or to keep current the information contained in this
manual.
AXIOMTEK reserves the right to make improvements to this document and/or product at any time
and without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the
prior written permission of AXIOMTEK Co., Ltd.
Copyright 2006 by AXIOMTEK Co., Ltd.
All rights reserved.
Version A1 December 2006
Printed in Taiwan
iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. If not installed and used
in accordance with proper instructions, this equipment might generate or radiate radio
frequency energy and cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.
iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the NA-100 before making any installation. Be sure
both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the NA-100 is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards
are sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
9Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help to discharge any static electricity on your
body.
9When handling boards and components, wear a wrist-grounding strap, available from
most electronic component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
Other brand names and trademarks are the properties of their respective owners.
v
Table of Contents
Disclaimers...................................................................................ii
FCC Compliance.........................................................................iii
C h a p t e r 1........................................................................................1
1.1 General Description....................................................1
1.2 Standard Features......................................................2
1.3 System Specifications.................................................3
1.3.1 Hardware............................................................3
1.4 Dimensions.................................................................5
1.5 Front Panel Outlets.....................................................6
1.6 Rear Panel Outlets .....................................................9
C h a p t e r 2 .................................................................................. 10
2.1 Preinstallation Checklist .......................................... 10
2.2 Setting up the appliance...........................................11
2.2.1 Removing and Replacing the Top Cover.........11
2.2.2 Installing a memory module (DIMM)................11
2.2.3 Installing aATA66/100/133 hard drive .............11
2.2.4 Connectors & Jumpers ....................................11
2.2.5 Installing Display Interface.............................. 16
2.2.6 Installing Serial Port Interface......................... 16
2.2.7 Installing Keyboard and PS/2 Mouse
Connectors....................................................................... 17
2.2.8 Installing USB Connector (Optional)............... 18
2.2.9 Enabling LAN by-pass feature........................ 18
C h a p t e r 3..................................................................................... 20
3.1 BIOS Introduction .................................................... 20
3.2 BIOS Setup.............................................................. 20
vi
3.3 Standard CMOS Setup............................................ 21
3.4 Advanced BIOS Features........................................ 24
3.5 Advanced Chipset Features.................................... 27
3.6 Integrated Peripherals............................................. 28
3.7 Power Management Setup...................................... 29
3.8 PNP/PCI Configuration............................................ 30
3.9 PC Health Status ..................................................... 32
3.10 Load Optimized Defaults......................................... 33
3.11 Set Supervisor/User Password................................ 33
3.12 Save & Exit Setup.................................................... 35
3.13 Quit Without Saving................................................. 37
A p p e n d i x A............................................................................... 38
NA-100 Hardware Installation Guide
Introduction 1
C h a p t e r 1
Introduction
This chapter contains the general information and the detailed
specifications of the NA-100 series Network Appliance server.
Chapter 1 includes the following sections:
General Description Mechanical Dimensions
Features I/O Outlets
System Specifications
1.1 General Description
NA-100 Front View
The NA-100 was designed for network software solution providers those
have data secure, voice over IP, video streaming, network bandwidth
controller and another cost effective with entry networking appliance
requirements across this stable and reliable multiple LAN device.
It is 1U desktop with FAN less design form factor. There can be
deployed up to four LAN ports combinations for customer selection in
the maximum for application. They also can support optional feature as
LAN by-pass which can isolate the defective segments.
NA-100 series has pretty good enclosure management interface to be
implemented in the factory default. It can support P.O.S.T (Power On
NA-100 Hardware Installation Guide
2 Introduction
Self Test) feature through hyper-terminal by console port. And clear LED
indicators is available for status tracking by customer.
And it has room space for one 2.5” hard drive deployment. Customer
can implement system log and monitoring functions through this
hardware specification. With its innovative mechanical and electrical
design, the NA-100 series provides one mini-PCI expansion slot for VPN
encryption / decryption adapter board and another type of Mini-PCI adapter
card enabling. It cans enhancement network security process
performance and off loads the CPU loading.
The NA-100 series is for network secure in the SOHO (Small Office and
Home Office) market.
1.2 Standard Features
zAMD Goede LX800 with 500MHz clock rate
zSupports four Ethernet ports
zSupports LAN bypass (optional) and BIOS redirected to
COM port features
zCompletely fanless in 1U type of desktop system design.
zSupports accelerate IPsec and incorporates security
engines through Mini PCI socket
zSupports RS-232, 2 USB ports and CF
zSuitable for network appliances: VPN, Network Bandwidth
Controller, SSL/TLS, Firewall, etc,.
NA-100 Hardware Installation Guide
Introduction 3
1.3 System Specifications
1.3.1 Hardware
zForm Factor:
1U desktop w/FAN less design
zCapacity:
It is from 0 to 250GB and beyond, depending on the 2.5” hard disk
drive capacity.
zPower Supply:
External power adapter 12V, 5A (60W)
zHard Drive:
Spacing for 1 IDE HDD (2.5”)
zFront Connector:
1 x Console port
zFront Panel LED:
LED for HDDs
LED for LAN Link/activity
LED for Power
zRear Connector:
4 x RJ-45 ports
2xUSBports
1 X DC-in power connector
zProcessor:
AMDGoedeLX800 processor
NA-100 Hardware Installation Guide
4 Introduction
zBIOS:
Award 4MB Flash BIOS Plug & Play
zMain Memory:
Two DDR333 SODIMM memory slots which all can be up to
512MB in the maximum
zIDE Interface:
Support one ATA 66/100 EIDE channels (44-pins)
zSerial Port:
One DB9 connector, other one is Pin reserved
zEthernet:
Totally has four LAN port connections are available.
zExpansion:
One Mini-PCI slot is for security encryption card or specialize
functions expansion
zCompact-FlashTM:
One IDE interface CompactFlashTM socket for embedded use
zDimensions:
214mm (W) x 44mm (H) x 150.8mm (D)
zOperation environment:
Air temperature: 0° C – 40°C (50°F – 104°F)
Humidity: 5% – 95%
zStorage environment:
Air temperature: -20° C – 70°C
Humidity: 5% – 95%
