AXIOMTEK P6217W Manual de usuario

P6217W

21.5” FHD TFT Monitor

User’s Manual

Disclaimers

This manual has been carefully checked and believed to contain accurate information.

Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third

party’s rights, and any liability arising from such use.

Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,

completeness or usefulness of any information in this document. Axiomtek does not make any

commitment to update the information in this manual.

Axiomtek reserves the right to change or revise this document and/or product at any time

without notice.

No part of this document may be reproduced, stored in a retrieval system, or transmitted, in

any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,

without the prior written permission of Axiomtek Co., Ltd.

CAUTION

If you replace wrong batteries, it causes the danger of explosion. It is recommended by the

manufacturer that you follow the manufacturer’s instructions to only replace the same or

equivalent type of battery, and dispose of used ones.

Nov 2016, Version A1

Printed in Taiwan

iii

Safety Precautions

Before getting started, read the following important cautions.

1. Be sure to ground yourself to prevent static charge when installing the internal

components. Use a grounding wrist strap and place all electronic components in any

static-shielded devices. Most electronic components are sensitive to static electrical

charge.

2. Disconnect the power cords from the P6217W Series before making any installation. Be

sure both the system and the external devices are turned OFF. Sudden surge of power

could ruin sensitive components. Make sure the P6217W Series is properly grounded.

3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only

a trained technician is allowed to do so. Integrated circuits on computer boards are

sensitive to static electricity. To avoid damaging chips from electrostatic discharge,

observe the following precautions:

Before handling a board or integrated circuit, touch an unpainted portion of the

system unit chassis for a few seconds. This will help to discharge any static

electricity on your body.

When handling boards and components, wear a wrist-grounding strap, available

from most electronic component stores.

Trademarks Acknowledgments

Axiomtek is a trademark of Axiomtek Co., Ltd.

Windows®is a trademark of Microsoft Corporation.

IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.

Intel®and Pentium®are trademarks of Intel Corporation.

AMI is trademark of American Megatrend Inc.

Other brand names and trademarks are the properties and registered brands of their

respective owners.

Table of Contents

Disclaimers.....................................................................................................ii

Safety Precautions........................................................................................iii

Chapter 1 Introduction............................................. 1

1.1 General Description............................................................................1

1.2 Features...............................................................................................2

1.3 Specifications......................................................................................2

1.4 Dimensions and Outlines ...................................................................3

1.5 I/O Outlets............................................................................................4

1.6 Packing List.........................................................................................5

Chapter 2 System Setup .......................................... 7

2.1 System Configuration.........................................................................7

2.2 Panel Mounting ...................................................................................8

2.3 Wall Mounting......................................................................................8

2.4 VESA Mounting ...................................................................................9

2.5 System Jumper Setting ....................................................................10

Appendix A Supported Input Timing Modes ............. 11

Appendix B OSD Operation........................................ 13

Function Description of OSD Menu............................................................13

P6217W User’s Manual

Introduction 1

Chapter 1

Introduction

This chapter contains general information and detailed specifications of the P6217W. Chapter

1 includes the following sections:

General Description

Features

Specifications

Dimensions and Outlines

I/O Outlets

Package List

1.1 General Description

The P6217W, an industrial 21.5 inches view area LCD Monitor comes with slim, light and

reliable features to replace traditional bulky CRT for Industrial application. Its unique flat design

is fit for panel mounting, VESA mounting, Wall mounting and Rack mounting. The display

interface offers DVI-D, HDMI and VGA for different input source from PC system or multimedia

system that let you upgrade the display don’t change anything from your system. Besides, for

varied HMI field, you can choose one of resistive touch or glass interface to meet your

application. In addition, this monitor has more comfort, safety, and environmental protection for

humanized & health consideration those would be the benefit that users can get.

This LCD monitor builds in color active matrix thin-film-transistor (TFT) liquid crystal display to

provide superior display performance. A maximum resolution of 1920x1080 is ideal for

displaying complex graphics and high definition images. Other outstanding designs that

enhance this LCD monitor’s performance are Plug & Play compatibility, and OSD (On Screen

Display) controls, especially OSD, it made you ease adjustment on screen image.

P6217W User’s Manual

2 Introduction

1.2 Features

High contrast color 21.5”FHD TFT LCD display support resolution up to 1920x1080

Flat design with NEMA4/IP65-compliant

Suits with resistive touch or glass

High Brightness and Ultra-wide viewing angle with anti-glare features.

Power management system conforms to VESA DPMS standard

Advanced OSD control for picture quality adjustment

Supports VESA ARMs, Desktop Stand Rear, Panel, Wall and Rack mounting

1.3 Specifications

21.5”FHD(1920x1080) LCD with LED backlight

Projected capacitive touch or glass

Front bezel design with NEMA4/IP65

Control: OSD (On Screen Display) control pad on the side

Mounting: Support Panel mount, VESA arm mount and Wall mount (optional)

Net Weight

P6217WPC: 6.42KG

Dimension (Main Body Size)

P6217WPC: 547.09X399.05X53 mm

Operation Temperature

0℃to 45℃

Relative Humidity

20% to 90% @ 40℃, Non-Condensing

Power input

Screw-type external AC or 12V/24VDC-in

Max power consumption: 20W

NOTE: 1. All specifications and images are subject to change without notice.

2. If vibration is over 1GHz, LCD will have twinkle that is a normal phenomenon.

When the vibration of system goes back 1GHz, the twinkle would disappear.

P6217W User’s Manual

Introduction 3

1.4 Dimensions and Outlines

The following diagrams show the dimensions and outlines of P6217W

P6217WPC:

P6217W User’s Manual

4 Introduction

1.5 I/O Outlets

Please refer to the following illustration for I/O locations of the P6217W.

Function

Exit/Auto Adjust

Screw type or

Phoenix type power input

Menu (Enter function)

HDMI

SEL-

DVI-D

SEL+

VGA

Power LED

Audio Port

Power Switch

Touch port (RS232 or USB)

7 8 9 10 11 12

1 2 3 4 5 6

P6217W User’s Manual

Introduction 5

1.6 Packing List

When you receive the P6217W, the bundled package should contain the following items:

P6217W unit x 1

VGA cable x1

USB cable or RS-232 cable x1 (for touch version only )

Adaptor x1 (for AC version only)

Panel mount kit x 16 (optional)

HDMI cable x1(optional)

DVI cable x1 (optional)

Wall mount bracket x1 (optional)

If you cannot find the package or any items are missing, please contact Axiomtek distributors

immediately.

P6217W User’s Manual

6 Introduction

This page is intentionally left blank.
